- Page 1 MeetingMan TutorPen/ LaserPointer 20m Wireless Mouse User Manual Model: G10-770L www.a4tech.com...
- Page 2 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Federal Communications Commission Requirements The equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to part 15 of the FCC Rules.
- Page 3 Mouse Button Diagram: - 2 -...
- Page 4 1. Hardware Installation 1). Connect the 10-Link receiver Take out the 10-Link receiver from bottom of the mouse and connect it to your computer or Notebook. Notes: 1. If you are using the receiver in a long range meeting room or there is strong wireless conflicts nearby, adopting the receiver with a USB extension cable to keep it away from the computer or any interfering sources.
- Page 5 (Note: The software is applicable to Windows 2000/ XP/ 2003/ Vista/ Windows 7) 2. Software Installation The G10 MeetingMan offers 2 flexible ways to install the driver, Normal Installation and Mobile Execution. The MeetingMan main program has a special feature that it can be executed directly without the need to install the software to Windows system.
- Page 6 (Otherwise, installation is failed and you have to remove the software and re-install.) To remove the driver, follow the steps: Go to START>> PROGRAMS >>A4TECH Software >> "G10 MeetingMan" >> "Uninstall G10 MeetingMan, see figure on the right. Mobile Execution: You may copy and store the Mobile Edition files to your storage device, e.g., a memory stick,...
- Page 7 3. The G10 MeetingMan Main Menu: Mode Name/Select: Default: Name a new mode or Mode Number: Resume to default select modes to use. Select mode settings. number to edit. ① ④ ② ③ Description of Reminder: Enter short description here Mouse Button Definition: for each button setting, which Display current mouse button...
- Page 8 (1) Knowing the G10 MeetingMan Software Before you are getting started to use this product, it is vital to understand the basic principles and design concepts of MeetingMan. For each of MeetingMan’s script file, it will contain 5 different working modes, and each working mode can setup 7 buttons on the mouse with various functionalities.
- Page 9 It displays the current mode number in editing. You may select other . Selected Mode to mode numbers if needed. Edit There are 5 modes you can select to edit; with each mode you can define a number of new button settings. Remember to click “Apply” on the main menu to save the new settings to the receiver before taking effect.
- Page 10 Functionality Listing of Mouse Buttons in Each Working Mode Mouse Button Diagram Mode 1 Mode 2 Mode 3 Mode 4 Mode 3 Mouse Button Office TutorPen Meeting Open file LaserPointer Gaming Meeting Right Button From Current Slide Right Button From current Right Button or Exit Slide slide or Exit Slide...
- Page 11 (2) Button Settings and Relevant Functions Functions Descriptions Figures .Button Click any “button definition area” on the main menu; you will see the function listing Settings as shown on the right. According to your preference, you may select one of them as the button setting.
- Page 12 Example: While in the session of a meeting or teaching, it is embarrassing to keep others waiting due to searching for a document, or look up for a program or a shortcut. With “Open a File” function, you may have better way to resolve this issue.
- Page 13 Office Sets You may setup any one of Office command sets such as: “Zoom In, Zoom Out, Paste Text, Double Click and Treble Click”to the mouse buttons. Zoom In/Out：One click to perform zoom in or zoom out function, applicable to CAD, ACDSee, Windows or text editing programs. Paste Text：One click to perform “Select, Copy &...
- Page 14 TutorPen This TutorPen function is available for mouse button 2,3,4,5, and 6. Usage: Press "Mode Shift " button to switch to Mode 2, then press and hold the mouse 6th button to draw lines. You can double-click on the same button to erase lines you just drew, triple-click on the same button will erase all lines on the screen.
- Page 15 ⑥ Click the Description of Reminder area on the main menu, a reminder screen will Description appear as shown on the right. Enter the reminder description, which will be of Reminder displayed on the right-down corner of your screen as the key setting reminder. .
- Page 16 250 Hz High Game Plays G10 MeetingMan is A4Tech’s latest innovation. According to various applications, the bandwidth is divided into 3 report rate levels: 1X bandwidth: USB report rate is 125Hz, suitable for office and general users, power consumption is the lowest.
- Page 17 (3) Gesture 16-in-1 On the button definition area of Main menu, click “ ” of button or , you will see the “Gesture 16-in-1” on the function listing as shown on the right. Select “Gesture 16-in-1 Setting” from the listing; the setup screen will pop up as shown on the right.
- Page 18 Usage: Press and hold the gesture button to draw any of 16 lines and directions as shown on the right, then release the button. The corresponding commands will be executed immediately, including Keyboard, Mouse, Hyperlink, Office, Text, Multimedia, Internet and Key Setting Reminder, which can be preset and store to your receiver memory.
- Page 19 Original After drawing the line, the column has been enlarged 4. Draw the line in Windows Picture and Fax Viewer. Original After drawing the line, the column has been enlarged - 18 -...
- Page 20 (4) Task Listing of G10 MeetingMan There are 2 ways will display the working mode number when it is shifted: Display 1: When the mode is shifted, the memo screen will be displayed on the screen center to remind current mode number information as shown on the right. Display 2: Meanwhile, the small MeetingMan icon on the system tray will shift with mode numbers .
