Echo HC-151 Operator's Manual

Hedhe clipper
Hide thumbs Also See for HC-151:
Table of Contents

Advertisement

Quick Links

Download this manual
Hedge Clipper
Operator's Manual
MODEL
Read rules for safe operation and all instructions carefully. ECHO provides this
Operator's Manual and a Safety Manual. Both must be read and understood for
proper and safe operation.
X7532247801
HC-151
WARNING
X753003281
01/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HC-151 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo HC-151

Summary of Contents for Echo HC-151

  • Page 1 Hedge Clipper Operator's Manual MODEL HC-151 WARNING Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X753003281 X7532247801 01/08...

  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and SAFETY messages.

  • Page 3: Safety

    EDGE LIPPER PERATOR ANUAL AFETY MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you.

  • Page 4: Personal Condition And Safety Equipment

    Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Extended Operation/Extreme Conditions It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may be brought about by exposure to vibration and cold.
  • Page 5 EDGE LIPPER PERATOR ANUAL Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).

  • Page 6: Equipment Check

    Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual.

  • Page 7: Description

    Locate the safety decals on your unit. Make sure the decals are legible and that you understand and follow the instruc- tions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.
  • Page 8 FRONT HANDLE / GUARD - Comfortable, textured finish provides anti-slip grip for front hand. Guard protects hand from the blades. Warning decals are located on guard. BLADES - Double reciprocating blades mounted to a blade support bar. The blades are double sided, capable of cutting on either side.

  • Page 9: Contents

    PERATOR ANUAL ONTENTS After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. __ 1 - Hedge Clipper Assembly __ 1 - Operator’s Manual...

  • Page 10: Install Blade Stiffener

    INSTALL BLADE STIFFENER 1. Move stop switch to stop position. 2. Disconnect spark plug wire. WARNING Hedge clipper blades are very sharp. Touching them may lead to severe personal injury. Use a socket and extension when adjusting blade bolts or blade locknuts in order to keep hands at a safe distance from sharp blades.

  • Page 11: Operation

    FUEL WARNING Alternative fuels, such as E-20 (20% ethanol), E-85 (85% ethanol) or any fuels not meeting ECHO requirements are NOT approved for use in ECHO 2-stroke gasoline engines. Use of alternative fuels may cause performance problems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not limited to, improper clutch engagement.
  • Page 12 Mixing Instructions 1. Fill an approved fuel container with half of the required amount of gasoline. 2. Add the proper amount of 2-stroke oil to gasoline. 3. Close container and shake to mix oil with gasoline. 4. Add remaining gasoline, close fuel container, and remix. o l l IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions.

  • Page 13: Starting Cold Engine

    Periodic carburetor adjustment may be necessary to assure blades do not move at idle. If blades move, readjust carburetor according to “Carburetor Adjustment” instructions in this manual or see your ECHO Dealer. 6. Throttle Trigger After engine warm-up, grip the handle to depress the throttle trigger lockout, and gradually depress throttle trigger to increase engine RPM to operating speed.

  • Page 14: Starting Warm Engine

    Periodic carburetor adjustment may be necessary to assure blades do not move at idle. If blades move, readjust carburetor according to “Carburetor Adjustment” instructions in this manual or see your ECHO Dealer. 1. Stop Switch Move stop switch (A) away from the STOP position.

  • Page 15: Hedge Trimming

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs.

  • Page 16: Maintenance Intervals

    MAINTENANCE INTERVALS n i l t I - t l i t l i n i l l f f s t l l l i ® y l l . y t...

  • Page 17: Air Filter

    EDGE LIPPER PERATOR ANUAL AIR FILTER Level 1. Tools required: 25 or 50 mm (1 or 2 in.) cleaning brush Parts required: 90008 REPOWER AIR & FUEL FILTER KIT 1. Close choke (Cold Start Position [ ]). This prevents dirt from entering the carburetor throat when the air filter is removed.

  • Page 18: Spark Plug

    SPARK PLUG Level 2. Tools required: T-wrench, Feeler gauge, Soft metal brush Parts required: REPOWER Tune-Up Kit P/N 90074 IMPORTANT Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada) otherwise severe engine damage may occur. 1. Remove spark plug and check for fouling, worn and rounded center electrode.
  • Page 19 EDGE LIPPER PERATOR ANUAL 1. Remove spark plug lead and spark plug. 2. Remove (4) starter cover hex socket bolts and starter. 3. Remove bottom right (A) and bottom left (B) hex socket bolts from cylinder cover. 4. Remove heat shield bolt (C) from the muffler cover. 5.

  • Page 20: Exhaust System

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service.

  • Page 21: Carburetor Adjustment

    1,000 feet above mean sea level (MSL). To maintain proper engine operation above 1,000 feet MSL the carburetor must be adjusted by an authorized ECHO service dealer. IMPORTANT If the engine is adjusted for operation above 1,000 feet MSL, the carburetor must be re-adjusted when operating the engine below 1,000 feet MSL, otherwise severe engine damage can result.

  • Page 22: Lubrication

    6. Wipe excess oil from the blade before putting the unit back in service. Gear Box Assembly Level 1. Tools required: Grease Gun, Clean rag Parts required: ECHO LUBE 14 oz. (P/N 91015) or Lithium Based ® Grease.

  • Page 23: Sharpening Blades

    6mm (.25 in.) Radius 6. Install blade stiffener (see “Blade Stiffener Remove/Install instruc- tions”). º 7. Lubricate blades (see “Lubrication instructions”). IMPORTANT Blades should only be removed and reinstalled by an Authorized ECHO Servicing Dealer, otherwise premature wear or internal damage may occur.

  • Page 24: Blade Adjustment

    IMPORTANT Blades should only be removed and reinstalled by an Authorized ECHO Servicing Dealer, otherwise premature wear or internal damage may occur. 1. Tighten blade bolts until snug, then loosen blade bolts 1/2 turn. 2. Hold blade bolts from turning using 10 mm socket, and tighten blade lock nuts with other 10 mm socket.

  • Page 25: Troubleshooting

    EDGE LIPPER PERATOR ANUAL ROUBLESHOOTING r o t r o t i a r i l l r o t r e l i l y i l y r o t r e l f f u r e l h t i r u t r / n...

  • Page 26: Storage

    TORAGE WARNING During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: 1.

  • Page 27: Specifications

    EDGE LIPPER PERATOR ANUAL PECIFICATIONS MODEL ------------------------------------------ HC-151 Length -------------------------------------------- 1,040 mm (41.0 in.) Width --------------------------------------------- 240 mm (9.45 in.) Height -------------------------------------------- 200 mm (7.87 in.) Weight, dry -------------------------------------- 4.98 kg (11.0 lb.) Type of Engine ---------------------------------- Air cooled, two-stroke, single cylinder, gasoline engine Displacement ------------------------------------ 21.2 cc (1.29 cu.in.)

  • Page 28: Servicing Information

    • Purchasing from your Echo Dealer. • Manuals are available by sending a written request stating the model number and serial number of your Echo unit, part number of the manual, your name and address, and mail to the address below.
