Hedge Clipper
Operator's Manual
MODEL
Read rules for safe operation and all instructions carefully. ECHO provides this
Operator's Manual and a Safety Manual. Both must be read and understood for
proper and safe operation.
X7532240300
HC-151
Serial Number 02001001 - 02006800
WARNING
DANGER
X753000120
06/00
Advertisement
Table of Contents
Related Manuals for Echo 02006800
Summary of Contents for Echo 02006800
- Page 1 MODEL HC-151 Serial Number 02001001 - 02006800 WARNING DANGER Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X753000120 X7532240300...
-
Page 2: Table Of Contents
NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operations tips and SAFETY messages. -
Page 3: Manual Safety Symbols And Important Information
Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDER- ING instructions for specific information. -
Page 4: International Symbols
• Check that the blade assembly is firmly attached and in safe operating condition. Dull, loose or damaged blades should not be used. • ECHO, INC. will not be responsible for the failure of cutting devices or accessories which have not been tested and approved by ECHO... -
Page 5: Fuel
IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. Contact your ECHO dealer for ordering information. After Refueling; • Wipe any spilled fuel from the unit. - Page 6 Wear no-slip, heavy duty work gloves to improve your grip on the handles. Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection -- Wear hearing protection. ECHO recommends wearing hearing protec- tion whenever unit is used. Proper Clothing -- Wear snug fitting, durable clothing;...
-
Page 7: Safe Operation
EDGE LIPPER PERATOR ANUAL SAFE OPERATION Determine Operation Area • Do not operate this product indoors or in inadequately ventilated areas. • Review the area to be trimmed. Look for hazards that could contribute to unsafe conditions. • Spectators and fellow workers must be warned, and children and animals prevented from coming nearer than 4.5 m (15 ft.) while the Hedge Clipper is in use. -
Page 8: Extended Operation/Extreme Conditions
EXTENDED OPERATION EXTREME CONDITIONS Vibration and Cold It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sensations followed by loss of color and numbness in the fingers. -
Page 9: Description
The ECHO product you purchased has been factory pre-assembled for your convenience. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. - Page 11 18. SAFETY VIDEO - (Not included with unit) P/N 99922202800 English version only is available at a cost of $5.00 from ECHO, INC. or any authorized ECHO dealer. The video overviews safety precautions and proper operating tech- niques and is supplemental to the Safety Manual. Read and understand the Safety Manual for complete information...
-
Page 12: Specifications
PECIFICATIONS MOD EL H C -151 Length 1040 mm (41.0 in.) Width 240 mm (9.45 in.) Height 200 mm (7.87 in.) Weight, dry 4.8 kg (10.7 lb.) Type of Engine Air cooled, two-stroke, single cylinder, gasoline engine D isplacement 21.2 cc (1.29 cu.in.) Bore 32.2 mm (1.27 in.) Stroke... -
Page 13: Assembly
50:1 oil meets these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD and J.A.S.O. FC certified oil, such as Echo Premium 50:1 Two-stroke Oil, will void the two-stroke engine warranty. (Emission related parts only are covered for two years, regardless of two-stroke oil used, per the statement listed in the California Emission Defect Warranty Explanation.) -
Page 14: Equipment Check
After Refueling; • Wipe any spilled fuel from the unit. • Move at lease 3 m (10 ft.) from refueling location before starting the engine. 3 m (10 ft.) After use; • DO NOT store a unit with fuel in its tank. Leaks can occur. Return unused fuel to an approved fuel storage container. -
Page 15: Operation
EDGE LIPPER PERATOR ANUAL PERATION WARNING DANGER Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions which can cause serious injury or death. • Provide all operators of this equipment with the Operator's Manual and instructions for safe operation. -
Page 16: Starting Warm Engine
The blades should not move at idle. If blades move, readjust carburetor according to "Carburetor Adjustment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. 6. After engine warm up, gradually depress throttle trigger to increase engine RPM to operating speed. -
Page 17: Stopping Engine
WARNING DANGER If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using hedge clipper again. HEDGE TRIMMING NOTE This unit is designed to cut shrubs and hedges with branches no larger than 6 mm (1/4 in.) in diameter. -
Page 18: Maintenance
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOUR- SELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Service Dealer for repairs. -
Page 19: Air Filter
EDGE LIPPER PERATOR ANUAL AIR FILTER Level 1. Tools required: 25 or 50 mm (1 or 2 in.) medium bristle paint brush Parts required: 90008 REPOWER AIR & FUEL FILTER KIT 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. -
Page 20: Spark Plug
WARNING DANGER Catalytic mufflers operate at extremely high temperatures. Muffler area must be kept clean. Do not perform maintenance on the muffler until engine and muffler are completely cool, otherwise serious personal injury may occur. SPARK PLUG Level 2. Tools required: T-wrench, Feeler gauge, Soft metal brush Parts required: 90064 REPOWER Tune-Up Kit 1. -
Page 21: Exhaust System
The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. EXHAUST SYSTEM Spark Arrestor Screen Level 2. -
Page 22: Carburetor Adjustment
Accelerate to full throttle to check for smooth transition from idle to full throttle. If engine stops or stalls after full warm up return the unit to your authorized ECHO dealer for repair. 6. Check HI speed RPM at W.O.T. (Wide Open Throttle). HI speed RPM should be set to specifications found on page 12 "Specifica-... -
Page 23: Lubrication
EDGE LIPPER PERATOR ANUAL LUBRICATION Blades Level 1. Tools required: Clean rag, 25 or 50 mm (1 or 2 in.) medium bristle paint brush Parts Required: 20W Engine Oil (lubrication), 50-50 mixture of kerosene and 20W oil (cleaning). WARNING DANGER Hedge Clipper Blades are very sharp. -
Page 24: Blade Stiffener Remove/Install
Gear Box Assembly Level 1. Tools required: Grease Gun, Clean rag Parts required: Echo Lube 14 oz. (P/N 91015) or Lithium Based Grease. Clean dirt from the grease fitting. Carefully pump grease into fitting. DO NOT force grease. Too much pressure will force grease past seals and cause damage. -
Page 25: Sharpening Blades
1/2 turn to allow free blade move- ment. 5. Lubricate blades. See "Blade Lubrication Instructions," on page 23. IMPORTANT Blades should only be removed and reinstalled by an Authorized ECHO Servicing Dealer, otherwise premature wear or internal damage may occur. -
Page 26: Troubleshooting
No fuel at Fuel strainer clogged Clean Cranks carburetor carburetor Fuel line clogged Clean Carburetor See your ECHO dealer Fuel at No fuel at Carburetor See your ECHO dealer cylinder cylinder Muffler wet Fuel Mixture is too rich Open choke... -
Page 27: Storage
EDGE LIPPER PERATOR ANUAL TORAGE WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage maintenance which includes the following:... -
Page 28: Servicing Information
The card plus proof of purchase provides you the assur- ance that authorized warranty work will be done. It also provides a direct link between you and ECHO if we find it necessary to contact you. ADDITIONAL OR REPLACEMENT MANUALS...
