Install the Drivers

Windows 7/Vista/Server 2008
Windows XP/Server 2003
LabVIEW Real-Time

Troubleshooting

Adapter Cannot Connect to the Network
© National Instruments Corporation
Follow the installation instructions for your operating system. The adapter
works with the following operating systems:
• Windows 7/Vista/XP/Server 2008/Server 2003
• LabVIEW Real-Time 2010 or higher
Windows automatically detects the new hardware and installs the Ethernet
driver.
Windows automatically detects the new hardware and displays a Found
New Hardware Wizard window. Cancel the Found New Hardware
Wizard and insert the PCI/PXI Gigabit Ethernet Adapters CD. From the
CD, launch the appropriate executable:
or for 64-bit systems. Follow the instructions to install
PROWinx64.exe
the driver for your Ethernet adapter.
LabVIEW Real-Time includes drivers for the Ethernet port on your
PXI-8231 board.
• Make sure the cable is installed properly.
The network cable must be installed properly at both the adapter and
hub. The maximum cable distance is 100 m. If the cable is connected
properly and within the allowed distance, try another cable.
• Check the LEDs on the adapter.
The adapter has two LEDs on the RJ-45 connector. The following table
lists the function of each LED.
ProWin32.exe
3
for 32-bit systems
NI PXI-8231 Installation Guide
