Icom IC-M501 Operational Manual page 5

Name Operation
Repress once
CALL
Holding for one sec.
Repress CALL with
holding HI/LOW button
Repress once
DIAL
Holding for 1sec.
Repress DIAL with
holding HI/LOW button
Repress once
SCAN
Holding for 1sec.
Repress SCAN with
holding HI/LOW button
Repress once
HI/LOW
Holding for 1sec.
With Holding HI/LOW
button
Repress once
DUAL
Holding for 1sec.
Repress DUAL with
holding HI/LOW button
Repress once
DIMMER
Holding for 1sec.
Repress DIMMER with
holding HI/LOW button
Repress once
16
Holding for 1 sec.
Repress DISTRESS with
holding HI/LOW button
Turning knob
SELECTOR
Turing Dial knob with
holding HI/LOW button
POWER
Repress
VOLUME
Turing knob
SQUELCH
Turning knob
Turning on the radio with holding CH 16 will select radio setup mode
IC-M501
Silk Print
CALL
DIAL
SCAN Start/Stop normal or priority scan
TAG Tag or un-tag channel for scanning
Clear all tagged channel with holding those buttons
HI/LOW Switch output power between 25W and 1W
DUAL
DIMMER
DIMMER
16
POWER
VOL
SQL
- 5 -
Function and Operation
Recall CALL CH
Reprogramming CALL CH
Editing CH name
Switching to user CH mode
No function
Selecting USA, INT mode
No function
No function
Start/Stop dual or tri watch
No function
No function
Selecting Dimmer level
No function
Turning on/off scrambler
Recall CH16
No function
No function
Selecting CH
No function
Turning on /off the radio
Adjusting receive audio
Adjusting SQL
