airquee Catch it Quick Game Additional Operating Instructions

Table of Contents

Download this manual

IMPORTANT

AS THE OWNER/OPERATOR IT IS YOUR RESPONSIBILITY TO WRITE AND CARRY

OUT YOUR OWN RISK ASSESSMENTS BEFORE ATTEMPTING TO USE THIS

PRODUCT.

** The following instructions are on addition to the main operation manual

supplied which should be read before the installation and setup of this unit**

** Please also see the reference regarding electrical safety on page 8 of this

document.

Installation instructions for 'Catch it Quick Game'

1 x Arch

6 x diamonds

1 x

magnetic

tube

1 x control box

6 x sticks

Page 1 of 6

Table of Contents

Do you have a question about the Catch it Quick Game and is the answer not in the manual?

Page 1 ** Please also see the reference regarding electrical safety on page 8 of this document. Installation instructions for ‘Catch it Quick Game’ 1 x Arch 6 x diamonds...
Page 2 1. The first step is unpacking the unit, you should have received the following items:  The sealed arch  Sticks (6 pieces)  Diamonds (6 pieces)  Control box  Magnetic tube  Electric cable  Anchors (4 pieces) ...
Page 3 5. The magnetic tube is connected to the control box with a cable, so you need to be careful only to place it in a way that will not tangle anyone around the game. 6. The cable need to be fixed with Velcro onto the arch as seen in the pictures below: 7.
Page 4 ASSEMBLY OF THE CONTROL SYSTEM: Remove the two screws from the part B and after this place part B into part C as seen in the picture below: Insert the control box into into the top part of part B as seen bellow, do not forget to screw and tighten the two screws into part B : -see images: Page 4 of 6...
Page 5 Do not forget to connect the magnetic tube to the control box – see images: The control box is the only thing that needs to be plugged in.  The red light turns on only when the control box is plugged in and it is under power.
Page 6 In accordance with HSE guidelines all 240v equipment should be protected with an RCD (Residual Current Device) having a maximum trip current of 30 mA. RCD’s are available from Airquee or your electrical store. Page 6 of 6...
