- Page 1 Item #1003 023 393 Model # YG269C-GM USE AND CARE GUIDE TRICE 56 INCH CEILING FAN Questions, problems, missing parts? Before returning to the store call Home Depot Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-877-527-0313 HOMEDEPOT.COM...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............Operation ..............Pull Chain Operating Instructions .......... Safety Information ............Reverse Switch Operating Instructions ........Warranty ................. Care and Cleaning ............Pre-installation .............. Troubleshooting ............Specifications ................Service Parts ............... Tools Required ................. Hardware Included .............. -
Page 3: Safety Information
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 4: Warranty
This warranty supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty must be paid by the customer. Contact the Customer Service Team at 1-877-527-0313 or visit www.homedepot.com Pre-Installation... -
Page 5: Hardware Included
Collar mounting screw with lock washer (preassembled) Light kit mounting screw (preassembled) Light holder thumbscrew (preassembled) 9 Watt LED bulb (not to scale) Pull chain and fob (not to scale) Plastic plug (not to scale) HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS PACKAGE CONTENTS Part Description Quantity Part Description Quantity Mounting bracket (preassembled) Blade Canopy Blade arm Canopy bottom cover (preassembled) Light kit Hanger ball/downrod assembly Glass shade Fan motor assembly... -
Page 7: Dual Mounting Instructions
Where necessary, each section of the instructions will note the different procedures to follow for the two types of installation. Standard Ceiling Mounting Close-to-Ceiling Mounting HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 8: Installation
Installation MOUNTING OPTIONS MOUNTING OPTIONS NOTE: WARNING: You may need a longer downrod to maintain proper To reduce the risk of fire, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°... -
Page 9: Assembly
(EE) against the wiring inside the hanger ball/downrod assembly (D). □ Insert the cotter pin (FF) through the hole near the end of the clevis pin (EE) until it snaps into the locked position. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 10: Close-To-Ceiling Mounting
Assembly — Close-to-Ceiling Mounting Preparing the canopy Preparing the motor □ □ Remove the mounting bracket (A) from the canopy (B) Remove three of the six collar mounting screws with by loosening the four canopy mounting screw with lock washers (HH) (every other one) from the collar lock washer (BB) on the top of the canopy (B). -
Page 11: Hanging The Fan
(A) socket is properly seated canopy (B). in the groove in the hanger ball (D). This will help to balance the ceiling fan. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. - Page 12 Assembly — Hanging the Fan (continued) Making the electrical connections Ground Black White conductor WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts (except for the ground wire).
- Page 13 (NN). □ Secure the canopy (B) to the mounting bracket (A) with the four canopy mounting screw with lock washer (BB) included with your fan. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
-
Page 14: Attaching The Fan Blades
Assembly — Attaching the Fan Blades Removing the rubber Attaching the blades to the packing mounts blade arms □ The fan motor assembly (E) is shipped with rubber NOTE: Your fan blades are reversible. Select the blade side packing mounts (PP) to prevent movement during finish which best accentuates your decor. - Page 15 (F), or cleaning the fan. Do no insert foreign objects between rotating fan blades (F). □ Align motor holes to blade arms (G) and secure with screws (DD) provided; tighten screws securely. □ Repeat this procedure for the remaining blade arms (G). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
-
Page 16: Installing The Light Kit
Assembly — Installing the Light Kit Attaching the light kit to Mounting the light bulb and the switch housing installing the glass shade □ Install one 9 watt LED bulb (KK) (included). CAUTION: Before starting the installation, disconnect the power by turning off the circuit breaker or removing the fuse □... - Page 17 (H). You can keep the light kit (H) for future use. □ Attach the plastic plug (MM) to the switch housing cover (RR). □ Install the switch housing cover (RR) to the switch housing (QQ) with light kit mounting screws (II) provided. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
-
Page 18: Operation
Operation PULL CHAIN OPERATING INSTRUCTIONS PULL CHAIN OPERATING INSTRUCTIONS Install two pull chains and fobs (LL) onto the pull chains located in the switch housing (QQ) and light kit (H). Turn on the power and check the operation of the fan. The pull chain controls the fan speed as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low, and 4 pulls - Off. -
Page 19: Care And Cleaning
Make sure there is a short distance from the ceiling to the canopy. It should not touch the ceiling. □ Make sure your ceiling box is secure and rubber isolator pads are used between the mounting bracket and outlet box. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. - Page 20 Troubleshooting (continued) Problem Problem Solution Solution □ Verify that all blades and blade bracket screws are secure (most fan wobble problems are caused by loose parts). Once the fan is properly installed, run the ceiling fan for 10 minutes to let the fan self-adjust.
-
Page 21: Service Parts
Collar setscrew (preassembled) Blade arm Collar mounting screw with lock washer (preassembled) Light kit Light kit mounting screw (preassembled) Glass shade Light holder thumbscrew (preassembled) 9 Watt LED bulb Pull chain and fob Plastic plug HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. - Page 22 Questions, problems, missing parts? Before returning to the store call Home Depot Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. YG269C001-A...
