Febo Flame CYFPINS01 User Manual

Electric fireplace insert
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ELECTRIC FIREPLACE INSERT USER MANUAL
WARNING
CAUTION
DO NOT RETURN!
Contact our customer service team for help first.
Customer Service Center: 800-385-0608 or aftersales@cye-way.com
User Manual
ITEM NO.: CYFPINS01
FACTORY MODEL NO.: ZHX-32-117
120Vac / 60Hz / 1500W
Read and understand this entire user manual, including all
safety information, before plugging in or using this product.
Failure to do so could result in fire, electric shock, or serious
personal injury.
Keep this user manual for future reference. If you sell or
give this product away, make sure this manual
accompanies this product.
Two people are required to lift this item. It is heavy and will
break if dropped.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CYFPINS01 and is the answer not in the manual?

Questions and answers

Related Manuals for Febo Flame CYFPINS01

Summary of Contents for Febo Flame CYFPINS01

  • Page 1 ELECTRIC FIREPLACE INSERT USER MANUAL User Manual ITEM NO.: CYFPINS01 FACTORY MODEL NO.: ZHX-32-117 120Vac / 60Hz / 1500W Read and understand this entire user manual, including all safety information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious WARNING personal injury.

  • Page 2: Important Safety Instruction

    IMPORTANT SAFETY INSTRUCTION WARNING: Any use of this appliance other than that recommended by the manufacturer in this owners manual may cause fire, burns, electric shock and/or other serious injuries or death. When using electrical appliance, basic precautions should always be followed to avoid the risk of fire, electric shock and injury to persons including the following: 1.
  • Page 3 OPERATING INSTRUCTIONS Read all instructions and warning prior to operating the appliance. Ensure that all controls are in the “OFF” status before plugging the appliance into a properly grounded electrical outlet. This appliance is for use on 120 Volts. The appliance has a 3-prong grounded plug (Figure 1.A). If your electrical outlet has only 2 slots (Figure 1.B), you will have to use an adapter (Figure 1.C) to convert from the 3-prong power cord to a 2-slot receptacle.
  • Page 4 OPERATING INSTRUCTIONS Using the Control Panel: (Locate in Figure 3) I UP B FLAME G FLAME SPEED C HEATER A POWER F TIMER D AMBIENCE J DOWN E HEARTH H CHILD LOCK Figure 3 Power(Figure 3.A): ✦ The POWER button supplies power to all the features of the electric insert. This button must be ON for any of the features to work properly.
  • Page 5 OPERATING INSTRUCTIONS Using the Control Panel: (Locate in Figure 3) ✦ There are 9 adjustable heat levels, including 99°F/37°C, 95°F/35°C, 90°F/32°C, 85°F/29°C, 80°F/27°C, 75°F/24°C, 70°F/21°C, 65°F/18°C, 60°F/16°C. ✦ When press the heater button and the ice blue circle on the digital display screen will be shown and twinkling, press UP or DOWN button to adjust the levels.
  • Page 6 OPERATING INSTRUCTIONS Using the Control Panel: (Locate in Figure 3) Child Lock (Figure 3.H): ✦ The CHILD LOCK button controls the locking feature of the electric insert! ✦ Press and hold the Child Lock button for 5 seconds to activate the function. When the Child Lock is on, the digital display screen will display -- , the other features are disabled.

  • Page 7: Using The Remote Control

    USING THE REMOTE CONTROL lnstalling the battery The battery is supplied with the remote control. The first thing to do with the remote control is to remove the plastic sheet insulated the battery.For replacement battery, use lithium-based CR2025 battery. Please follow the sequence below to replace the battery.

  • Page 8: Technical Specifications

    TECHNICAL SPECIFICATIONS 1) Electric Specifications 2) Product Dimensions PAGE 8 OF 12...

  • Page 9: Maintenance

    TECHNICAL SPECIFICATIONS 3) Insert into a cabinet or wood mantel lt is available to install the unit into a wood cabinet or mantel.Also, it would be better to keep the depth at 9.5". The clearance from the top of the unit to the bottom of TV orsomething else sitting on the cabinet should be 8"...

  • Page 10: Troubleshooting

    TROUBLE SHOOTING WARNING: Turn off the appliance, unplug and let cool for at least 10 minutes before attempting to service. Only a qualified professional should attempt to service or repair the appliance. PROBLEM POSSIBLE CAUSE SOLUTION Simulated Flame Effect is dim or not Dimmer control button is set too Push flame button to increase present...

  • Page 11: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY PLEASE DO NOT RETURN ANY PRODUCTS TO STORE, ANY MISSING PARTS OR HARDWARE OR ASSEMBLY PROBLEMS, PLEASE CONTACT WITH OUR CUSTOMER SERVICE CENTER AT 800-385-0608 WORKING HOURS: MONDAY~FRIDAY, 9:00AM-4:00PM (PACIFIC STANDARD TIME) The following non-transferable limited warranty applies is extended only to the original consumer-purchaser of this International Limited product.
  • Page 12 Thank you for purchasing this product! If you have questions about assembly or operation of this product, or missing parts, or if the product is damaged, please E-mail us at: aftersales@cye-way.com Or call 800-385-0608 PAGE 12 OF 12...
