Do you have a question about the Harmony and is the answer not in the manual?

Questions and answers

Leo Labe
May 1, 2025

my grand videoke will not boot up completely, when it reach half of the loading bar it will re-start loading again

0
1 comments:
Mr. Anderson
May 16, 2025

Your GRAND VIDEOKE Harmony may not be fully booting up and restarting at half of the loading bar due to issues with the SD Card. If the SD Card is inserted while the device is operating, or if incompatible or incorrectly placed files are on the card, it can cause malfunction. Ensure the SD Card was inserted only when the power was off and that files are located in the correct directories (MUSIC, PHOTO, RECORD, VIDEO) using proper formats converted by the “TJ media Encoder.” Remove the SD Card and try booting again to check if the issue is related to the card.

This answer is automatically generated

0
Leo Labe
May 1, 2025

my grand will not boot up completely

0

Related Manuals for GRAND VIDEOKE Harmony

Summary of Contents for GRAND VIDEOKE Harmony

  • Page 1 All manuals and user guides at all-guides.com...
  • Page 2 All manuals and user guides at all-guides.com Ver.3...

  • Page 3: Table Of Contents

    Installation Guide 22-24 - Connecting the microphone to the GRAND VIDEOKE - Connecting the GRAND VIDEOKE to the TV - Connecting the GRAND VIDEOKE to other Sound Systems Additional Menu Function & Con guration Settings 25-26 - Search Menu - Favorite Menu...
  • Page 4 All manuals and user guides at all-guides.com Declaration of Conformity Trade Name : TJ media Model : TKR-361MP Responsible Party : TJ media Co.,Ltd. Address : 23, Hwagok-ro 64-gil, Gangseo-gu, Seoul, Korea Telephone : +82-2-3663-4700 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,...

  • Page 5: Packing Guide

    All manuals and user guides at all-guides.com PACKING GUIDE Upper View 1. Main Unit(Player) 2. Wireless Microphone x 1 3. Wired Microphone X 1 4. Remote Control 5. Song list & Manual & Quick Guide 6. Auto-Volt Power Adaptor 7. MIC Cable 8.
  • Page 6 All manuals and user guides at all-guides.com BASIC FUNCTIONS SONG SELECTION & PLAYBACK METHOD 1 By entering song number directly VOLUME(MUSIC Key in the song number using the alphanumeric keypad, then press METHOD 2 By sorting the song in the list 1) To Open the Song List: Press the Arrow keys or 2) To Sort by Title, Artist, Lyric or Number: Press Press...
  • Page 7 All manuals and user guides at all-guides.com BASIC FUNCTIONS VOLUME(MUSIC, MIC, ECHO) numeric keypad, 1] Volume : Press 2] Type selection(MUSIC, MIC, ECHO) : 3] Adjustment : w keys or er: Press Press . (While playing). press TEMPO Press . (While playing). w keys or er: Press r by typing on the...
  • Page 8 All manuals and user guides at all-guides.com SECONDARY FUNCTIONS FAVORITE SONGS 1] To Add: Select a song, press 2) To Remove: Select a song that has been added, press 3) To Search: Press , then select “FAVORITE”. RECORDING You can record a song in 4 ways: , Select “REC”, Select“RECORDING”, SONG SEARCH, , Select“RECORDING”, SONG SEARCH,...

  • Page 9: Channel Settings

    All manuals and user guides at all-guides.com CHANNEL SETTINGS TKR-361MP has eight (8) available channels for the wireless microphone. Please take note that the microphone and the main player should be on the same channel. In case of channel interference (either the microphone cannot be detected by the main player), follow the instructions below for re-channeling.
  • Page 10 All manuals and user guides at all-guides.com CHANNEL SETTINGS hone. [Step2] Set the channel of the microphone using the on the microphone's keypad. tected 1) Turn on the microphone by pressing the button. POWER POWER 2) Press button in order. The microphone LED will be turned on and off twice.
  • Page 11 All manuals and user guides at all-guides.com GRAND VIDEOKE. The GRANDVIDEOKE provides various kinds of Moving Picture Background. (Nature,WorldTour, 3D, MTV, K-POP M/V, K-Drama etc.) The GRANDVIDEOKE provides additional built-in memory space of 64MB, so you can either record songs save pictures to use as background image.
  • Page 12 All manuals and user guides at all-guides.com GRAND VIDEOKE GRAND VIDEOKE in the GRANDVIDEOKE Microphone is used to power on the Microphone. Button/Key Play Standby Search Mode Skip “0” “SPACE”→“0” Move to Music, MIC, Move to Music, Move to Title, Artist,...
  • Page 13 All manuals and user guides at all-guides.com GRAND VIDEOKE GRAND VIDEOKE. GRAND VIDEOKE. GRAND VIDEOKE GRAND VIDEOKE” GRAND VIDEOKE microphone. GRANDVIDEOKE GRAND VIDEOKE GRAND VIDEOKE to the nearest dealer or service center to check for damage and for repair, if necessary.
  • Page 14 Auto-Volt Power Adaptor Songpack : You can buy additional song packs to add to the built-in song selection of your GRAND VIDEOKE. An additional song packs will allow you to sing with your loved ones and friends. Wired MIC : You can add one more wired microphone.
  • Page 15 All manuals and user guides at all-guides.com Wireless MIC indicator POWER POWER Power indicator Adaptor input Audio output(R/L) Video output DC IN 12V DC IN 12V AUDIO AUDIO VIDEO OUT VIDEO OUT MIC input (for dynamic microphone) Power switch MIC 1 MIC 1 MIC 2 MIC 2...
  • Page 16 All manuals and user guides at all-guides.com (Remote Control) www.grandvideoke.com...
  • Page 17 All manuals and user guides at all-guides.com (Remote Control) FUNCTION SUBSTANCES MENU Menu display. USER Select the user video & user MP3. Display the list of RealSound songs. CHORUS Display the list of Chorus songs. MUSIC NOTE Play(Music note display on/o ) Standby(Displays the list of songs with Music Note) FAVORITE Display the list of Favorite songs.
  • Page 18 All manuals and user guides at all-guides.com (Remote Control) When to change the batteries(2 x AAA Batteries) 1. Please pull up to uncover. www.grandvideoke.com...
  • Page 19 All manuals and user guides at all-guides.com (Microphone) microphone microphone. microphone 1. Please push down and pull up the cover. www.grandvideoke.com...

  • Page 20: Installation Guide

    All manuals and user guides at all-guides.com GRAND VIDEOKE -GRAND VIDEOKE main unit GRAND VIDEOKE Please refer to the Installation Guide. 3. Turn on the main unit. 4. Check if the POWER LED on the front of main unit is turned on.
  • Page 21 All manuals and user guides at all-guides.com GRAND VIDEOKE You can use up to 11 SongTransfer Packs including the 10 STPs copied to the internal memory of the main unit. Song Transfer Pack can also be directly played from the song pack slot.
  • Page 22 With GRAND VIDEOKE, there are two kinds of second microphone that you can use. Your rst option is to use a GRAND VIDEOKE Microphone with remote control keypads. This type of microphone has the same buttons as the remote control.
  • Page 23 All manuals and user guides at all-guides.com GRAND VIDEOKE to the TV Mainplayer back view DC IN 12V DC IN 12V AUDIO AUDIO VIDEO OUT VIDEO OUT input www.grandvideoke.com...
  • Page 24 All manuals and user guides at all-guides.com GRAND VIDEOKE R-AUDIO-L AUDIO www.grandvideoke.com...
  • Page 25 To enter a menu function, Press The Favorite Songs list contains user selected songs that are stored in the GRAND VIDEOKE’ s memory. This list is retained even after the GRAND VIDEOKE is turned o . To add songs to the favorite list :...
  • Page 26 The Con guration menu enables you to change some of the setting of the like lyrics alignment, and di culty level of the scoring. GRAND VIDEOKE Here is the list of the default values for each con guration option. Button effect...

  • Page 27: Sd Card

    All manuals and user guides at all-guides.com SD Card Caution in using SD Card Please make sure to insert the SD Card before turning on the main player. Do not disconnect the SD Card from the main player while the device in operation. It may cause malfunction of the device or damage on the contents of SD Card.

  • Page 28: What Is Tj Media Encoder

    All manuals and user guides at all-guides.com Encoder What is TJ media Encoder? TJ media Encoder is a converting program that provides users a way to convert their moving pictures or image les to the suitable format for TKR-361MP. System Requirements Operating System : Windows XP SP2 or later, Windows Vista Processor : Intel Pentium 4 or AMD 866MHz or later Memory : 512MB or later...

  • Page 29: Tj Media Encoder Installation

    All manuals and user guides at all-guides.com Encoder TJ media Encoder Installation Connect the TKR-361MP with PC using USB cable and turn on the power. Directory named“TKR-361 UM”will be created. Open the “TKR-361 UM”folder and double click the “TJMediaEncoder.exe” to execute installation. Installation progress [ 1.

  • Page 30: How To Install Tj Media Encoder Program

    All manuals and user guides at all-guides.com Encoder How to install TJ media Encoder Program Please insert the device which has the TJ media encoder program into the PC. Please enter the device folder and install the program. Installation progress 2.
  • Page 31 All manuals and user guides at all-guides.com Encoder 3.Select Start Menu Folder. 4.Select Additional Tasks. 5.Ready to Install. 6.Setup Finished. www.grandvideoke.com...
  • Page 32 All manuals and user guides at all-guides.com Encoder Converting moving pictures Double click the TJ media encoder icon to start the program. Click [Video]. Click [File Add] to load a le that you want to convert. Click [SD]. www.grandvideoke.com...
  • Page 33 All manuals and user guides at all-guides.com Encoder Converting moving pictures Click [Option] if you want the converted les saved with another le name and or in di erent location. Click [Convert] to execute converting. After converting is nished, you can check the le in the saving folder. (Initial saving folder : My Documents →TJ media) www.grandvideoke.com...
  • Page 34 All manuals and user guides at all-guides.com Encoder Converting Image les StartTJ media encoder and click [IMAGE]. Click [File Add] to load an image le that you want to convert. Click [SD]. www.grandvideoke.com...
  • Page 35 All manuals and user guides at all-guides.com Encoder Converting Image les Click [Option] to save as an another le name and or in di erent location. You can also spin the direction of the image. Click [Convert] to execute converting. SD CARD manufacturers SanDisk Transcend...

  • Page 36: Music Note

    All manuals and user guides at all-guides.com Music Note While playing, on the remote control, press the [MUSIC NOTE] "Music Note" is displayed. While stand by, on the remote control, press the [MUSIC NOTE] "Music Note list" is displayed. While music note is displaying, you can change lyrics mode by pressing [MUSIC NOTE] button on the remote control.

  • Page 37: Pc Connection

    All manuals and user guides at all-guides.com GRAND VIDEOKE port. You can download the recorded songs from the device to your PC, or upload some image Þles from your PC to the main player. PC connection ‘TKR-361 UM’ GRAND VIDEOKE Windows XP, 7 O/S.

  • Page 38: Using Your Photos As Background Image

    UM folder. ‘PHOTO’ to resize main player on. GRAND VIDEOKE Press “BGV”button to select “MY.P”and your photos will be shown. 1MB. 7. You can add approximately 110 images to the main player based on the size of each image at 350KB.
  • Page 39 All manuals and user guides at all-guides.com GRAND VIDEOKE GRAND VIDEOKE. GRAND VIDEOKE a. Press the {+} MIC volume button on the remote to increase the volume of the mic. GRAND VIDEOKE switch GRAND VIDEOKE. GRAND VIDEOKE www.grandvideoke.com...
  • Page 40 All manuals and user guides at all-guides.com Enter the menu then [Con g], then enter [TV Set-Up] then select either NTSC or PAL. TEMPO and KEY www.grandvideoke.com...

  • Page 41: Product Speci Cation

    All manuals and user guides at all-guides.com Product Speci cation Main Player Output 2Vrms Audio Frequency 20Hz ~ 20kHz Video Output 75Ω 1.0Vp-p Input AC100~240V (50~60Hz) Adaptor Output DC12V, 0.5A ~ 1A Input DC12V, 0.5A ~ 1A Consumption 4.6W Main Station Weight(g) 284g Dimension(WxHxD)
