Summary of Contents for GRAND VIDEOKE TKR-371MP

  • Page 2 Ver.3...
  • Page 3 22-24 Installation Guide - Connecting the microphone to the GRAND VIDEOKE - Connecting the GRAND VIDEOKE to the TV - Connecting the GRAND VIDEOKE to other Sound Systems Additional Menu Function & Con guration Settings 25-26 - Search Menu - Favorite Menu...

  • Page 4: Declaration Of Conformity

    Declaration of Conformity Trade Name : TJ media Model : TKR-361MP Responsible Party : TJ media Co.,Ltd. Address : 23, Hwagok-ro 64-gil, Gangseo-gu, Seoul, Korea Telephone : +82-2-3663-4700 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Packing Guide

    PACKING GUIDE Upper View 1. Main Unit(Player) 2. Wireless Microphone x 1 3. Wired Microphone X 1 4. Remote Control 5. Song list & Manual & Quick Guide 6. Auto-Volt Power Adaptor 7. MIC Cable 8. Audio/Video Cable(RCA cable) 9. USB Cable 10.
  • Page 6 BASIC FUNCTIONS SONG SELECTION & PLAYBACK METHOD 1 By entering song number directly VOLUME(MUS Key in the song number using the alphanumeric keypad, then press METHOD 2 By sorting the song in the list 1) To Open the Song List: Press the Arrow keys or 2) To Sort by Title, Artist, Lyric or Number: Press 3) To Select: Press the Arrow keys, then press TEMPO...
  • Page 7 BASIC FUNCTIONS VOLUME(MUSIC, MIC, ECHO) numeric keypad, 1] Volume : Press 2] Type selection(MUSIC, MIC, ECHO) : 3] Adjustment : w keys or er: Press Press . (While playing). press TEMPO Press . (While playing). w keys or er: Press r by typing on the press SECONDARY FUNCTIONS...
  • Page 8 SECONDARY FUNCTIONS FAVORITE SONGS 1] To Add: Select a song, press 2) To Remove: Select a song that has been added, press 3) To Search: Press , then select “FAVORITE”. RECORDING You can record a song in 4 ways: , Select “REC”, Select“RECORDING”, SONG SEARCH, , Select“RECORDING”, SONG SEARCH, 3) SONG LIST,...
  • Page 9 CHANNEL SETTINGS TKR-361MP has eight (8) available channels for the wireless microphone. Please take note that the microphone and the main player should be on the same channel. In case of channel interference (either the microphone cannot be detected by the main player), follow the instructions below for re-channeling. 1) T 2) P [Step1] Change the channel on the main unit by using the...
  • Page 10 CHANNEL SETTINGS hone. [Step2] Set the channel of the microphone using the on the microphone's keypad. tected 1) Turn on the microphone by pressing the button. POWER POWER 2) Press button in order. The microphone LED will be turned on and off twice. 3) Press the same channel number that you set in the main player.
  • Page 11 GRAND VIDEOKE. The GRANDVIDEOKE provides various kinds of Moving Picture Background. (Nature,WorldTour, 3D, MTV, K-POP M/V, K-Drama etc.) The GRANDVIDEOKE provides additional built-in memory space of 64MB, so you can either record songs save pictures to use as background image.
  • Page 12 GRAND VIDEOKE GRAND VIDEOKE in the GRANDVIDEOKE Microphone is used to power on the Microphone. Button/Key Play Standby Search Mode Skip “0” “SPACE”→“0” Move to Music, MIC, Move to Music, Move to Title, Artist, Echo Volume MIC, ECHO Volume Lyrics, Number Search Modes...
  • Page 13 GRAND VIDEOKE GRAND VIDEOKE. GRAND VIDEOKE. GRAND VIDEOKE GRAND VIDEOKE” GRAND VIDEOKE microphone. GRANDVIDEOKE GRAND VIDEOKE GRAND VIDEOKE to the nearest dealer or service center to check for damage and for repair, if necessary. GRAND VIDEOKE. www.grandvideoke.com...

  • Page 14: Quick Guide

    Auto-Volt Power Adaptor Songpack : You can buy additional song packs to add to the built-in song selection of your GRAND VIDEOKE. An additional song packs will allow you to sing with your loved ones and friends. Wired MIC : You can add one more wired microphone.
  • Page 15 Wireless MIC indicator POWER POWER Power indicator Adaptor input Audio output(R/L) Video output DC IN 12V DC IN 12V AUDIO AUDIO VIDEO OUT VIDEO OUT MIC input (for dynamic microphone) MIC 1 MIC 1 MIC 2 MIC 2 Power switch POWER POWER SD card slot...

  • Page 16: Remote Control

    (Remote Control) www.grandvideoke.com...

  • Page 17: Remote Control

    (Remote Control) FUNCTION SUBSTANCES MENU Menu display. USER Select the user video & user MP3. Display the list of RealSound songs. CHORUS Display the list of Chorus songs. MUSIC NOTE Play(Music note display on/o ) Standby(Displays the list of songs with Music Note) FAVORITE Display the list of Favorite songs.

  • Page 18: Remote Control

    (Remote Control) When to change the batteries(2 x AAA Batteries) 1. Please pull up to uncover. www.grandvideoke.com...
  • Page 19 (Microphone) microphone microphone. microphone 1. Please push down and pull up the cover. www.grandvideoke.com...

  • Page 20: Channel Settings

    GRAND VIDEOKE -GRAND VIDEOKE main unit GRAND VIDEOKE Please refer to the Installation Guide. 3. Turn on the main unit. 4. Check if the POWER LED on the front of main unit is turned on. -GRAND VIDEOKE main unit 1. Turn o the main unit.
  • Page 21 GRAND VIDEOKE You can use up to 11 SongTransfer Packs including the 10 STPs copied to the internal memory of the main unit. Song Transfer Pack can also be directly played from the song pack slot. Song Pack Installation 1) Please turn o the main unit.

  • Page 22: Remote Control

    With GRAND VIDEOKE, there are two kinds of second microphone that you can use. Your rst option is to use a GRAND VIDEOKE Microphone with remote control keypads. This type of microphone has the same buttons as the remote control.
  • Page 23 GRAND VIDEOKE to the TV Mainplayer back view DC IN 12V DC IN 12V AUDIO AUDIO VIDEO OUT VIDEO OUT input www.grandvideoke.com...
  • Page 24 GRAND VIDEOKE R-AUDIO-L AUDIO www.grandvideoke.com...
  • Page 25 To enter a menu function, Press The Favorite Songs list contains user selected songs that are stored in the GRAND VIDEOKE’ s memory. This list is retained even after the GRAND VIDEOKE is turned o . To add songs to the favorite list :...

  • Page 26: Con Guration Menu

    The Con guration menu enables you to change some of the setting of the like lyrics alignment, and di culty level of the scoring. GRAND VIDEOKE Here is the list of the default values for each con guration option. Button effect...

  • Page 27: Caution In Using Sd Card

    SD Card Caution in using SD Card Please make sure to insert the SD Card before turning on the main player. Do not disconnect the SD Card from the main player while the device in operation. It may cause malfunction of the device or damage on the contents of SD Card. The directories of [MUSIC], [PHOTO], [RECORD], [VIDEO] will be created when you rst insert the SD Card to the main player.

  • Page 28: What Is Tj Media Encoder

    Encoder What is TJ media Encoder? TJ media Encoder is a converting program that provides users a way to convert their moving pictures or image les to the suitable format for TKR-361MP. System Requirements Operating System : Windows XP SP2 or later, Windows Vista Processor : Intel Pentium 4 or AMD 866MHz or later Memory : 512MB or later HDD : 1GB or later...

  • Page 29: Tj Media Encoder Installation

    Encoder TJ media Encoder Installation Connect the TKR-361MP with PC using USB cable and turn on the power. Directory named“TKR-361 UM”will be created. Open the “TKR-361 UM”folder and double click the “TJMediaEncoder.exe” to execute installation. Installation progress [ 1. Program Setup Start] [ 2.Select Destination Location] www.grandvideoke.com...

  • Page 30: How To Install Tj Media Encoder Program

    Encoder How to install TJ media Encoder Program Please insert the device which has the TJ media encoder program into the PC. Please enter the device folder and install the program. Installation progress 2. Select Destination Location. www.grandvideoke.com...
  • Page 31 Encoder 3.Select Start Menu Folder. 4.Select Additional Tasks. 5.Ready to Install. 6.Setup Finished. www.grandvideoke.com...
  • Page 32 Encoder Converting moving pictures Double click the TJ media encoder icon to start the program. Click [Video]. Click [File Add] to load a le that you want to convert. Click [SD]. www.grandvideoke.com...
  • Page 33 Encoder Converting moving pictures Click [Option] if you want the converted les saved with another le name and or in di erent location. Click [Convert] to execute converting. After converting is nished, you can check the le in the saving folder. (Initial saving folder : My Documents →TJ media) www.grandvideoke.com...
  • Page 34 Encoder Converting Image les StartTJ media encoder and click [IMAGE]. Click [File Add] to load an image le that you want to convert. Click [SD]. www.grandvideoke.com...
  • Page 35 Encoder Converting Image les Click [Option] to save as an another le name and or in di erent location. You can also spin the direction of the image. Click [Convert] to execute converting. SD CARD manufacturers SanDisk Transcend Kingston cd-r king RiDATA 1GB, 2GB, 4GB, 8GB, 16GB, 32GB KINGMAX...

  • Page 36: Music Note

    Music Note While playing, on the remote control, press the [MUSIC NOTE] "Music Note" is displayed. While stand by, on the remote control, press the [MUSIC NOTE] "Music Note list" is displayed. While music note is displaying, you can change lyrics mode by pressing [MUSIC NOTE] button on the remote control.

  • Page 37: Pc Connection

    GRAND VIDEOKE port. You can download the recorded songs from the device to your PC, or upload some image Þles from your PC to the main player. PC connection ‘TKR-361 UM’ GRAND VIDEOKE Windows XP, 7 O/S. www.grandvideoke.com...

  • Page 38: Using Your Photos As Background Image

    UM folder. ‘PHOTO’ to resize main player on. GRAND VIDEOKE Press “BGV”button to select “MY.P”and your photos will be shown. 1MB. 7. You can add approximately 110 images to the main player based on the size of each image at 350KB.
  • Page 39 GRAND VIDEOKE GRAND VIDEOKE. GRAND VIDEOKE a. Press the {+} MIC volume button on the remote to increase the volume of the mic. GRAND VIDEOKE switch GRAND VIDEOKE. GRAND VIDEOKE www.grandvideoke.com...
  • Page 40 Enter the menu then [Con g], then enter [TV Set-Up] then select either NTSC or PAL. TEMPO and KEY www.grandvideoke.com...

  • Page 41: Product Speci Cation

    Product Speci cation Main Player Output 2Vrms Audio Frequency 20Hz ~ 20kHz Output 75Ω 1.0Vp-p Video Input AC100~240V (50~60Hz) Adaptor Output DC12V, 0.5A ~ 1A Input DC12V, 0.5A ~ 1A Consumption 4.6W Main Station Weight(g) 284g Dimension(WxHxD) 148x77.5x135 (mm) Wireless Microphone Microphone Type Analog Wireless Microphone RF Frequency / RF Type...
