Installing and Removing the Battery

Installing the Battery
Load a fully charged Battery Pack LP-E5 into the camera.
Removing the Battery
Do not further push open the battery compartment cover when it is already
open. Doing so may damage its hinge.
26
Open the battery compartment
1
cover.
Slide the lever as shown by the arrow
and open the cover.
Insert the battery.
2
Insert the end with the battery
contacts.
Insert the battery until it locks in
place.
Close the cover.
3
Press the cover until it snaps shut.
Open the cover and remove the
battery.
Press the battery lock lever as shown
by the arrow and remove the battery.
To prevent shorting, be sure to attach
the protective cover to the battery.
