OVERVIEW

1.0
This card provides an easy way of interfacing your inputs and outputs from you parallel
port. It provides terminals for the connections and conditions the signals for use in CNC
applications.

FEATURES

2.0
• IEEE 1284 Standard compatible.
• PULL-UP or PULL-DOWN selection for inputs.
• Buffered inputs and outputs.
• Bidirectional pins 2-9.
• Output pins 1, 2, 3, 4, 5, 6, 7, 8, 9, 14, 16, 17. Or 1, 14, 16, 17.
• Input pins 10, 11, 12, 13, 15. Or 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 15.
• Input and output pins with close by ground or +5vdc connections
.
• Input pins 10, 11, 12, 13, 15.
• Input and output pins with close by ground or +5vdc connections
• External Enable Pin (EN).
• Works directly with popular CNC hardware and software.
• All TTL 5VDC signals.
• Screw-On connections for all terminals.
• Status LEDs for enable.
