- Page 1 Instruction Manual 32” HD Ready LED TV L32HE13A L32HE13A_IB.indd 1 16/06/2014 18:15...
- Page 2 WE KNOWHOW TO HELP YOU WITH YOUR TV We want you to be able to enjoy your new TV for many years. From getting it home and setting it up, to helping you get the most out of your new purchase. And in the unlikely event your TV lets you down, we can get it working again in no time.
-
Page 3: Table Of Contents
Contents Safety Warnings ....................................5 Preparation ......................................7 Unpacking the TV ..........................................7 Installing / Removing the Base Stand ..................................8 Mounting the TV to a Wall .......................................8 Front / Right Side View and Controls ...................................9 Rear View and Sockets ........................................10 Installing Batteries in the Remote Control ................................11 Remote Control Operation Range ....................................11 Remote Control ..........................................12 Initial Setup ......................................14... - Page 4 Connecting a USB Storage Device ..................................... 39 Viewing Photos ..........................................40 Listening to Music ..........................................41 Viewing Movies ..........................................42 My Text..............................................43 Play Recorded Programme ......................................44 Maintenance .....................................45 Hints and Tips ....................................46 YPbPr Mode ............................................48 PC Mode .............................................. 48 HDMI Mode ............................................
-
Page 5: Safety Warnings
Safety Warnings Safety Warnings Safety • Read all the instructions carefully before using the unit and keep them for future reference. • Always disconnect the unit from the mains supply before connecting / disconnecting other devices or • Retain the manual. If you pass the unit onto a third moving the unit. - Page 6 Service Standby • To reduce the risk of electric shock, do not remove • button on the remote control does not switch off the unit completely. The unit will continue to draw screws. The unit does not contain any user-serviceable parts.
-
Page 7: Preparation
Preparation Thank you for purchasing your new Logik 32” HD Ready LED TV. Your new TV has many features and incorporates the latest technology to enhance your viewing experience. We recommend that you spend some time reading this instruction manual so that you fully understand these features. -
Page 8: Installing / Removing The Base Stand
Installing / Removing the Base Stand The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. -
Page 9: Front / Right Side View And Controls
Front / Right Side View and Controls Item Description Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby POWER LED mode. The LED will illuminate blue and then blink red and blue confirming that a timer recording programme has started in the standby mode. -
Page 10: Rear View And Sockets
Rear View and Sockets HDMI 1 In HDMI 2 In SCART PC-RGB In RF In Audio In Item Description Connects to a High-Definition (HD) signal output device, such as a set-top box, blu-ray HDMI 1 / HDMI 2 / HDMI 3 disc player or AV receiver. -
Page 11: Installing Batteries In The Remote Control
Installing Batteries in the Remote Control 1. Press and lift the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment. -
Page 12: Remote Control
Remote Control Switch the TV between on and standby mode. MUTE Mute and restore your TV sound. 3. 0-9 Number Button • Press to select a programme. (DTV / RADIO mode) 4. -/-- Feature not available. RECALL Return to the previous viewing channel. (DTV mode) 6. - Page 13 19. SLEEP Set the TV sleep timer: OFF / 10 / 20 / … / 180 / 240 min. 20. ASPECT Watch the screen in various formats: Auto / 4:3 / 16:9 / Zoom / Smart Zoom / Subtitle. 21. AUDIO •...
-
Page 14: Initial Setup
Initial Setup Turning the TV On for the First Time 1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the AERIAL IN socket at the rear right bottom view of your TV. -
Page 15: Target Region Setting
6. Channel tuning will commence. This operation may take up to 10 Channel Tuning minutes. The display will show the progress of the tuning and the 0 Channel number of channels found. Radio 0 Channel If you want to exit the tuning menu, press the MENU button to interrupt DATA 0 Channel the tuning process. -
Page 16: Channel Selection
Channel Selection Press the CH + / – buttons on the remote control repeatedly or the 0-9 buttons to select the channel. • Alternative Press the OK button to enter the Channel List. Then use the buttons to highlight and select the channel. Press the OK button to view the selected channel. - Page 17 Picture Mode Select among picture mode: Standard / Mild / Personal / Dynamic. Picture Mode The default setting is Standard. Select Personal if you want to adjust Dynamic the picture settings yourself. Standard Mild Personal BACK EXIT MENU Contrast Adjusts the difference between light and dark levels in the picture. (for Personal mode) Brightness Increases or decreases the amount of white in the picture.
-
Page 18: Aspect Ratio
Aspect Ratio Allows you to watch the screen in various picture formats: Auto / 4:3 / 16:9 / Zoom / Smart Zoom / Full Screen. The default setting is AUTO. 1. Press the ASPECT button to scroll through the aspect rations. The aspect Ratio can also be selected from the OPTION menu. -
Page 19: Sound Setting
Sound Setting Allows you to adjust the sound settings on your TV. 1. Press the MENU button and then press the buttons to select the SOUND menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT 2. -
Page 20: Epg (Electronic Programme Guide) (Dtv Mode)
EPG (Electronic Programme Guide) (DTV Mode) This system has an Electronic Programme Guide (EPG) to help you navigate through all the possible viewing options. The EPG supplies information such as programme listings, start and end times for all available services. In addition, detailed information about the programme is often available in the EPG (the availability and amount of programme information will vary, depending on the particular broadcaster). -
Page 21: Time Shift Recording Onto A Usb Storage Device
Time Shift Recording onto a USB Storage Device This function allows you to pause live TV. The picture will pause and the programme will begin recording so you don't miss any of the programme. You will have to have a USB storage device attached to the USB socket for Time Shift Recording to work. If the transfer rate of the USB storage device is too slow •... -
Page 22: Recording Dtv Programmes Onto A Usb Storage Device
Recording DTV Programmes onto a USB Storage Device Use this function to record the DTV programme you are watching on the main screen and save it for future viewing. The recording from timer programme or direct recording may have a little bit of delay when it starts to record the broadcast programme. -
Page 23: Timer Programming
Timer Programming This function is used to perform scheduled recording. The recording from timer programme or direct recording may have a little bit of delay when it starts to record the broadcast programme. Please make sure the USB device is inserted. If not, a warning message will pop up. 1. -
Page 24: Playing Recorded Programmes
Playing Recorded Programmes The recorded List shows a list of all the recordings that have been made. You can view all your recordings from this list and see information about each recording. 1. Press the REC List button on the remote control. The Recorded List Recorded List 18:55 21 Jan menu will appear. -
Page 25: Digital Teletext (Dtv Mode)
Digital Teletext (DTV Mode) Digital teletext can access special digital teletext services and specific services which broadcast digital teletext. You will need to turn off Subtitle Function before using teletext (refer to page 32 for details). Teletext within Digital Service 1. -
Page 26: Signal Information (Dtv Mode)
Signal Information (DTV Mode) Allows you to view the signal information. 1. Press the MENU button and then press the buttons to select the CHANNEL menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT 2. Press the buttons to select Signal Information and then press the OK button to view the signal information. -
Page 27: Software Update (Over Air Download) (Dtv Mode)
To view the module information 1. Press the MENU button and then press the buttons to select the CHANNEL menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT 2. Press the buttons to select CI Information and then press the OK button. -
Page 28: Software Update (Usb)
1. During normal DTV viewing, if the TV detects the latest firmware from the DTV signal, the Over Air Download screen will appear. Press the buttons New Fireware is available to select Yes / No for upgrade procedure. TV Version V0.01 Stream Version v0.02 Yes to upgrade No to exit the upgrade... -
Page 29: Time Settings
Time Settings Allows you to adjust time zone, sleep time, auto standby, OSD timer and summer time. 1. Press the MENU button and then press the buttons to select the TIME menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION... - Page 30 Clock (DTV mode) The clock is set automatically when receiving a digital signal. Time Zone When you select a Time Zone city, the TV time is set by Time Zone (DTV mode) the time offset information based on Time Zone and GMT Canary GMT Rabat GMT Berlin GMT+1...
-
Page 31: Option Setting
Option Setting OSD Language Allows you to select your desired on screen menu language. 1. Press the MENU button and then press the buttons to select the OPTION menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT 2. -
Page 32: Subtitle Language (Dtv Mode)
Subtitle Language (DTV Mode) Allows you to select your desired subtitle language or turn off the subtitle. (Available for digital channels if multiple subtitle languages are broadcast.) 1. Press the buttons to select the Primary / Secondary Subtitle Subtitle language Primary Language. -
Page 33: Pvr File System (Dtv Mode)
PVR File System (DTV Mode) Allows you to select your preferences in the PVR File System. 1. Press the MENU button and then press the buttons to select the OSD Language English OPTION menu and then press the OK button. TT Language West Audio Language... -
Page 34: Blue Screen
Blue Screen Allows the blue background to turn On or Off during weak or no signal conditions. 1. Press the MENU button and then press the buttons to select the OSD Language English OPTION menu and then press the OK button. TT Language West Audio Language... -
Page 35: Restore Factory Default
Restore Factory Default Restores all settings to the factory defaults. 1. Press the MENU button and then press the buttons to select the OSD Language English OPTION menu and then press the OK button. TT Language West Audio Language English 2. -
Page 36: Lock Setting
Lock Setting To access all the LOCK menu options, you must enter the password. Enter the default password “0000” for first time use. To change the password, refer to “Change Password”. Lock System The Lock System is designed to prevent accidental re-tuning of the TV / losing of channels and to prevent children from watching unsuitable programmes. -
Page 37: Set Password
Set Password 1. Press the MENU button and then press the buttons to select the LOCK menu and then press the OK button. Lock System Set Password 2. Press the buttons to select Set Password and then press the OK Block Channel button. -
Page 38: Parental Guidance
Parental Guidance This function allows you to set up blocking schemes to block specific channels and ratings. It operates according to information from the broadcasting station, therefore if the signal has incorrect information, this function will not operate. This TV is programmed to remember the last option set even if the TV is switched off. When a programme is locked or rated, a valid password must be entered. -
Page 39: Key Lock
Key Lock Key Locked is designed to prevent children from pressing the buttons on the TV. The Lock System must be set to On for this function to operate. If the Key Locked is set to On, all buttons on the TV will be locked. All TV operations can be controlled by the remote control only. -
Page 40: Viewing Photos
Viewing Photos 1. Press the USB button on the remote control. 2. Press the buttons to select PHOTO and then press the OK button. 3. Press the buttons to select your storage device and then press the OK button. PHOTO 4. -
Page 41: Listening To Music
Listening to Music 1. Press the USB button on the remote control. 2. Press the buttons to select MUSIC and then press the OK button. 3. Press the buttons to select your storage device and then press the OK button. 4. -
Page 42: Viewing Movies
Viewing Movies 1. Press the USB button on the remote control. 2. Press the buttons to select MOVIE and then press the OK button. 3. Press the buttons to select your storage device and then press the OK button. 4. Press the buttons to navigate in the movie folder/file and then press the OK button. -
Page 43: My Text
My Text 1. Press the USB button on the remote control. 2. Press the buttons to select TEXT and then press the OK button. 3. Press the buttons to select your storage device and then press the OK button. 4. Press the buttons to navigate in the text folder/file and then press the OK button. -
Page 44: Play Recorded Programme
Play Recorded Programme You can play a recorded programme from the recorded programme list or from a USB Storage Device. 1. Press the USB button on the remote control. 2. Press the buttons to select MOVIE and then press the OK button. 3. -
Page 45: Maintenance
Maintenance Maintenance Careful and regular cleaning can prolong the life of your TV. Be sure to press the button on the remote control and disconnect the mains cable from the mains socket before any cleaning. 1. Use a soft dry cloth to wipe away the dust from the screen and surfaces. 2. -
Page 46: Hints And Tips
Hints and Tips Hints and Tips The following table contains various hints and tips to get the best performance from your TV. If you require additional assistance please call our UK Call Centre on 0344 561 1234. Our Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm. - Page 47 There is a problem in PC mode. The signal is out of range (Invalid • Adjust the resolution, horizontal frequency, or vertical frequency. format) Vertical bar or stripe on background • Use Auto configure or adjust clock, phase, or H/V position. &...
-
Page 48: Ypbpr Mode
Display Modes The screen resolution has been optimised during production for the display modes listed below. Although this TV is compatible with a 1080i/1080p input, it is possible that the screen may not display the exact resolution this resolution and consequently the picture quality will be adjusted accordingly. YPbPr Mode Resolution Vertical Frequency (Hz) -
Page 49: Specifications
Specifications Specifications Model L32HE13A Panel System 32 inch LED Panel Display Resolution 1366 pixels (horizontal) x 768 pixels (vertical) PAL I / BG / DK SECAM I / BG / DK DVBT (VIDEO: MPEG-2 MP@ML, Television System SOUND: MPEG-1 LAYER 1/2, MPEG-2 LAYER 2) - Page 50 L32HE13A_IB.indd 50 16/06/2014 18:15...
- Page 51 L32HE13A_IB.indd 51 16/06/2014 18:15...
- Page 52 SRS Labs, Inc. All trademarks are the property of their respective owners and all rights are acknowledged. DSG Retail Limited (Registered in England No. 504877) Maylands Avenue, Hemel Hempstead, Hertfordshire HP2 7TG. UK (IB-L32HE13A-140616V1) L32HE13A_IB.indd 52 16/06/2014 18:15...
