- Page 1 32” HD Ready LED TV Instruction Manual L32HE12 • This IB add YPbPr function (all correction marked in red colour). • Waiting Supplier provide a new IB and QSG Part Number. L32HE12_IB_Running Change_120528_Annie.indd 1 12年5月28日 下午7:00...
- Page 2 L32HE12_IB_Running Change_120528_Annie.indd 2 12年5月28日 下午7:00...
-
Page 3: Table Of Contents
Contents Preparation ......................................5 Unpacking the TV ..........................................5 Installing / Removing the Base Stand ..................................6 Front / Right Side View and Controls ...................................7 Rear View and Sockets ........................................8 Installing Batteries in the Remote Control ................................9 Remote Control Operation Range ....................................9 Remote Control ..........................................10 Connections . - Page 4 Using the Features ...................................40 EPG (Electronic Programme Guide) (DTV Mode) ..............................40 − Switch On / Off EPG ......................................40 − Select a Programme ......................................40 Teletext (ATV Mode) .........................................41 − To Turn on Teletext Function....................................41 Digital Teletext (DTV Mode) ......................................42 − Teletext within Digital Service ..................................42 Entertainment ....................................43 Connecting a USB Storage Device .....................................
-
Page 5: Preparation
Preparation Thank you for purchasing your new Logik 32" HD Ready LED TV. Your new TV has many features and incorporates the latest technology to enhance your viewing experience. We recommend that you spend some time reading this instruction manual so that you fully understand these features. -
Page 6: Installing / Removing The Base Stand
Installing / Removing the Base Stand The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of the TV at any time because the screen could crack. -
Page 7: Front / Right Side View And Controls
Front / Right Side View and Controls Item Description Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby POWER LED mode. The LED will flash blue and red when the timer programming has started in standby mode. Receives IR signals from the remote control. IR (Infrared Receiver) Do not put anything near the sensor, as its function may be affected. -
Page 8: Rear View And Sockets
Rear View and Sockets YPbPr VIDEO SCART Socket Description Connects to a DVD player, Digital Set-Top-Box, or other AV devices with component YPbPr / AUDIO IN (L/R) (YPbPr) video and audio output sockets via the included component adapter cable. Connects to the Composite VIDEO and AUDIO (L/R) output sockets on external video VIDEO / AUDIO (L/R) devices. -
Page 9: Installing Batteries In The Remote Control
Installing Batteries in the Remote Control 1. Press and lift the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure the (+) and ( - ) ends of the batteries match the (+) and ( - ) ends indicated in the battery compartment. -
Page 10: Remote Control
Remote Control Switch the TV between on and standby mode. MUTE Mute and restore your TV sound. 3. 0-9 Number Button • Press to select a programme. • Select numbered items in a menu. (DVD mode) 4. LIST • Display the channel list. (ATV / DTV mode) • Display the text page on the teletext screen. - Page 11 19. FAV Display the favourite channel list. (ATV / DTV mode) SETUP Display and exit the DVD setup menu. (DVD mode) 20. i Display the present screen information such as the current channel on ATV / DTV mode and the input source except ATV / DTV mode.
- Page 12 31. Skip to the beginning of the next chapter / track / photo. (DVD / USB mode) REVEAL Reveal hidden information such as the answer to a quiz in teletext. (ATV mode) 32. To skip to the beginning of the previous chapter / track / photo.
-
Page 13: Connections
Connections Making Video and Audio Connections Not all AV devices have the ability to connect to a TV, please refer to the owner’s manual of your AV device for compatibility and connection procedures. When connecting any external AV device, do not connect the mains cable to the mains socket until all other connections are complete. -
Page 14: Connecting A Computer Using A Vga Cable
Connecting a Computer Using a VGA Cable Rear Right Side View of TV 1. Use a VGA cable to connect the TV’s PC IN input socket to a computer’s VGA output socket. Use an COMMON INTERFACE (CI) HDMI2 HDMI1 PC IN PC AUDIO audio cable to connect the TV’s PC AUDIO input HEADPHONE socket to the computer’s audio output socket. -
Page 15: Connecting An Av Device Using A Scart Cable
Connecting an AV Device Using a SCART Cable Rear Bottom View of TV 1. Use a SCART cable to connect the TV’s SCART input socket to an external AV device’s SCART output socket. YPbPr VIDEO SCART 2. Plug the connected devices into the mains socket before switching on the TV. 3. Press the button on the right side bottom panel of the TV or on the remote control to turn on your TV. -
Page 16: Connecting Headphones
Connecting Headphones Rear Right Side View of TV Connect your headphones to the TV’s HEADPHONE COMMON INTERFACE (CI) socket. HDMI2 HDMI1 PC IN PC AUDIO HEADPHONE Before putting on the headphones, turn the volume down then put the headphones on and slowly increase the volume until you reach a comfortable listening level. -
Page 17: Initial Setup
Initial Setup Turning the TV On for the First Time 1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the RF (75Ω) socket at the rear right side of your TV. Do not connect the TV to the mains supply until you have completed all the connections. -
Page 18: Target Region Descriptor
7. Channel tuning will commence. This operation may take up to 6 minutes. Channel Tuning The display will show the progress of the tuning and the number of channels found. : 3 Channel(s) 8. If you want to skip the ATV tuning, press the MENU button on the : 0 Channel(s) remote control to interrupt the tuning half way. -
Page 19: Channel Selection
Channel Selection • Press the CH / on the right side bottom panel of the TV or the CH + / – buttons on the remote control repeatedly or the 0-9 buttons to select the channel. Alternative Press the LIST button to enter the Channel List. Then use the buttons to highlight and select the channel. -
Page 20: Customising Tv Settings
Customising TV Settings Channel Setting (TV, DTV or Radio Mode) Auto Tuning Use this to automatically find and store all available channels. This is normally recommended if some channels have been added or removed by the broadcaster or if you have moved house. 1. Press the MENU button on the remote control and then press the buttons to select the CHANNEL menu and then press the OK button. -
Page 21: Dtv Manual Tuning
DTV Manual Tuning Allows you to make manual fine tuning adjustments to the channel under DTV mode. 1. Press the MENU button on the remote control and then press the buttons to select the CHANNEL menu and then press the OK button. CHANNEL PICTURE SOUND... -
Page 22: Channel Edit (Atv / Dtv Mode)
3. The ATV Manual Tuning screen will pop up. Use the buttons to select ATV Manual Tuning the following options and the buttons to adjust the setting. Storage To 1 Storage To Presets the channel number. Sound System I Selects the sound system: I / DK / BG / L (for Sound System SECAM). -
Page 23: Signal Information (Dtv Mode)
c. Move Press the YELLOW button and then press the buttons to move to the selected channel. Press the YELLOW button or the OK button to confirm. d. Skip Press the BLUE button to skip the selected channel. Press the BLUE button again to undo it. -
Page 24: Ci (Common Interface) (Dtv Mode)
CI (Common Interface) (DTV Mode) The common interface allows the use of a Common Access Module to enable you to view scrambled (pay to view) services. These services are provided by TopUp TV (UK only) and others. The Common Access Module and viewing card can be obtained from the service provider. -
Page 25: Software Update (Over Air Download)
Software Update (Over Air Download) The TV auto detects the latest firmware through the DTV signal and allows you to accept or refuse the firmware upgrade service. 1. Press the MENU button on the remote control and then press the buttons to select the CHANNEL menu and then press the OK button. CHANNEL PICTURE SOUND... -
Page 26: Picture Setting
Picture Setting Allows you to set your preferred picture mode. 1. Press the MENU button on the remote control and then press the buttons to select the PICTURE menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT EXIT 2. Press the... - Page 27 Aspect Ratio Allows you to watch the screen in various picture formats: Auto / 4:3 / 16:9 / Zoom / Subtitle / Smart Zoom. Input Signal 4:3 Input Signal 16:9 Auto This selection will display This selection will display the picture according to the picture according to the aspect ratio of the the aspect ratio of the input source.
-
Page 28: Sound Setting
Sound Setting Allows you to select an audio-enhancement technique. 1. Press the MENU button on the remote control and then press the buttons to select the SOUND menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT EXIT 2. Press the buttons to select the following sound options and then... -
Page 29: Stereo / Dual Sound Reception (Atv Mode)
Stereo / Dual Sound Reception (ATV Mode) When a programme is selected, press the AD button to display the sound information for the selected station. Broadcast On Screen Display MONO / NICAM MONO Mono MONO / NICAM STEREO Stereo Dual MONO / NICAM DUAL I, NICAM DUAL II, NICAM DUAL I+II Mono sound selection If the stereo signal is weak, you can switch to mono by pressing the AD button. -
Page 30: Option Setting
3. Press the buttons to select the options. Press the OK button and then press the buttons to adjust each option’s setting. Clock The clock is set automatically when receiving a digital signal. Off Time Allows you to set the off time that will automatically switch off the TV. Cycle through and select from the following off time options: Off / Once / Every Day / Mon.~Fri. -
Page 31: Audio Language (Dtv Mode)
2. Press the buttons to select OSD Language and then press the OK button. The default on-screen menu language is English. OSD Language English Audio Language Subtitle Language Hearing Impaired Country PVR File System Backlight Restore Factory Default 3. Press the buttons to navigate the menu and change the OSD Language settings. -
Page 32: Subtitle Language (Dtv Mode)
Subtitle Language (DTV Mode) Allows you to select your desired subtitle language or turn off the subtitle. (Available for digital channels if multiple subtitle languages are broadcast.) 1. Press the MENU button on the remote control and then press the buttons to select the OPTION menu and then press the OK button. CHANNEL PICTURE SOUND... -
Page 33: Pvr File System (Dtv Mode)
PVR File System (DTV Mode) Allows you to select your preferences in the PVR File System. 1. Press the MENU button on the remote control and then press the buttons to select the OPTION menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK... -
Page 34: Cec (Consumer Electronics Control)
CEC (Consumer Electronics Control) Allows you to command and control two or more CEC-enabled devices, that are connected through HDMI, by using only one of the TV remote controls (e.g. controlling a TV set, set-top box and DVD player using only the remote control of the TV). CEC also allows individual CEC-enabled devices to command and control each other without user intervention. -
Page 35: Restore Factory Default
2. Press the buttons to select Backlight and then press the buttons. The backlight control bar will display on the screen. Press OSD Language buttons to select your desired backlight level (1-10) of your TV. Audio Language English Subtitle Language English Hearing Impaired On Increasing the backlight setting will increase the brightness and Country... -
Page 36: Lock Setting
Lock Setting To access the LOCK menu, you must enter the password. Enter the default password “6666” for first time use. To change the password, refer to “Change Password” (see below). Lock System The Lock System is designed to prevent accidental retuning of the TV / losing channels and prevent children watching unsuitable programmes. -
Page 37: Set Password
Set Password 1. Press the MENU button on the remote control and then press the buttons to select the LOCK menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT EXIT 2. Press the buttons to select Lock System and then press the OK button. -
Page 38: Block Channel
Block Channel Block Channel is designed to prevent children watching unsuitable programmes. When a channel is blocked, a valid password must be entered. 1. Press the MENU button on the remote control and then press the buttons to select the LOCK menu and then press the OK button. CHANNEL PICTURE SOUND... -
Page 39: Parental Guidance
Parental Guidance This function allows you to set up blocking schemes to block specific channels and ratings. It operates according to information from the broadcasting station, therefore if the signal has incorrect information, this function will not operate. This allows you to set up blocking schemes to block specific channels and ratings. -
Page 40: Using The Features
Using the Features EPG (Electronic Programme Guide) (DTV Mode) This system has an Electronic Programme Guide (EPG) to help you navigate through all the possible viewing options. The EPG supplies information such as programme listings, start and end times for all available services. In addition, detailed information about the programme is often available in the EPG (the availability and amount of programme information will vary, depending on the particular broadcaster). -
Page 41: Teletext (Atv Mode)
Teletext (ATV Mode) Teletext is a free service broadcast by some TV stations which gives up-to-the-minute information on news, weather, television programmes, share prices and many other topics. Using the Teletext control buttons you can view pages of information that are listed in the teletext index. To Turn on Teletext Function Make sure the TV channel you are watching transmits teletext. -
Page 42: Digital Teletext (Dtv Mode)
Digital Teletext (DTV Mode) Digital teletext can access special digital teletext services and specific services which broadcast digital teletext. You will need to turn off Subtitle Function before using teletext (refer to page 32 for details). Teletext within Digital Service 1. In DTV mode, press the LIST button to display the Channel List. Press the buttons and then press the OK button to select the teletext channel. -
Page 43: Entertainment
Entertainment Connecting a USB Storage Device 1. Switch off the TV before connecting any USB Rear Right Side View of TV storage device. COMMON INTERFACE (CI) HDMI2 HDMI1 PC IN PC AUDIO 2. Connect your USB storage device to the USB port HEADPHONE of your TV. 3. Plug the connected devices into the mains socket before switching on the TV. -
Page 44: Listening To Music
4. Press the buttons to navigate in the picture folder and then press the OK button. If you want to select the specified photos, press the buttons to select the picture file and then press the OK button. A tick box will be displayed. -
Page 45: Viewing Movies
6. Select the music you want to play, it will show the music information (Album / Title / Bit Rate / Artist / Sampling / Year / Size). Then press the PLAY button to play. 7. Press the buttons and then press the OK button to select the function: Pause / FB / FF / Prev / Next / Stop / Repeat All / Playlist / Goto Time. -
Page 46: My Text
My Text 1. Press the button on the right side bottom panel of the TV or the INPUT button on the remote control then press the buttons to select the USB mode and then press the OK button. 2. Press the buttons to select TEXT and then press the OK button. -
Page 47: Pvr (Personal Video Recorder)
PVR (Personal Video Recorder) Time Shift Function This function allows the TV to virtually record the live viewing broadcast programme. If the transfer rate of the USB storage device is too slow • Time Shift Mode and Recording functions for recording or time shift function, a warning statement may not work if the signal strength is weak. -
Page 48: Recording Dtv Programme Onto A Usb Storage Device
Recording DTV Programme onto a USB Storage Device Use this function to record the DTV programme you are watching on the main screen and save it for future viewing. The recording from timer programme or direct recording may have a little bit of delay when it starts to record the broadcast programme. -
Page 49: Timer Programming
Timer Programming This function is used to perform scheduled recording. The recording from timer programme or direct recording may have a little bit of delay when it starts to record the broadcast programme. Please make sure the USB device is inserted. If not, a warning message will pop up. 1. Press the GUIDE button on the remote control. -
Page 50: Play Recorded Programme
Play Recorded Programme You can play a recorded programme from the recorded programme list or from a USB Storage Device. 1. Press the button on the right side bottom panel of the TV or the INPUT button on the remote control and then press the buttons to select the USB mode and then press the OK button. -
Page 51: Maintenance
Maintenance Maintenance Careful and regular cleaning can prolong the life of your TV. Be sure to press the button at the front right side of the TV or on the remote control to turn off the TV. Disconnect the mains cable from the mains socket before any cleaning. - Page 52 The audio function does not work. • Press the VOL + / – buttons. Picture OK but no sound • Sound muted? Press the MUTE button. • Try another channel. The problem may be caused by the broadcaster. No output from one of the speakers • Adjust the Balance settings in the SOUND menu. • A change in ambient humidity or temperature may result in an unusual noise when Unusual sound from Inside the TV the TV is switched on or off and does not indicate a fault with the TV.
-
Page 53: Display Modes
Display Modes Display Modes The screen resolution has been optimised during production for the display modes listed below. Whilst the TV is capable of accepting a 1080p input, it is not capable of displaying this screen resolution and therefore the display will be scaled to fit the native resolution of the screen automatically. YPbPr Mode Resolution Vertical Frequency (Hz) -
Page 54: Specifications
Specifications Specifications Model L32HE12 Panel System 32 inch LED Backlit LCD Panel Display Resolution 1366 pixels (horizontal) x 768 pixels (vertical) Television System PAL I / BG / DK SECAM L / BG / DK Brightness 300 cd/m Contrast Ratio 3000 : 1 Power Source... - Page 55 ENERG L32HE12 64.5 kWh/annum Watt inch - 2011 2010/1062 L32HE12_IB_Running Change_120528_Annie.indd 55 12年5月28日 下午7:02...
-
Page 56: Safety Warnings
Safety Warnings Safety Warnings Safety • Read all the instructions carefully before using the unit and keep them for future reference. • Always disconnect the unit from the mains supply before connecting / disconnecting other devices or • Retain the manual. If you pass the unit onto a third moving the unit. - Page 57 Service Standby button on the remote control does not switch • To reduce the risk of electric shock, do not remove • screws. The unit does not contain any user-serviceable off the unit completely. The unit will continue to draw parts.
- Page 58 If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number TV Stand Support 115Q3201101 TV Base 102Q3201111 Remote Control 504C1961101 AAA Batteries 32200007158 Component Adapter Cable XXXXX Screw A 209100422B1 Screw B 209060410B1 Visit Partmaster.co.uk today for the easiest way to buy electrical...
- Page 59 L32HE12_IB_Running Change_120528_Annie.indd 59 12年5月28日 下午7:02...
- Page 60 L32HE12_IB_Running Change_120528_Annie.indd 60 12年5月28日 下午7:02...
