ASSEMBLY INSTRUCTIONS
ITEM NO.: 695727
Part List
CASTERS
BASE
SEAT CUSHION
MECHANISM
SCREWS
4
D 1/4" x L 7/8"
WASHERS
4
BACKREST
BACKREST
SCREWS
2
D 5/16" x L 5/8"
MECHANISM
GAS LIFT
J
FOOT RING
ALLEN WRENCH
Step 1
Turn Base "B" upside down.
Insert Casters "A" into Base "B".
A
B
Step 4
Place seat assembly onto Gas Lift "I". Push firmly
on the chair seat to securely attach seat assembly
to seat post.
I
ATTENTION: Make certain that all screws are fully tightened before using chair.
Lubricate all moving parts and tighten all screws every 6 months or as needed.
Step 2
Slide Gas Lift "I" through Footring "J" and
into Base "B".
I
x 5
J
B
Step 5
Attach Backrest "F" to the rear of mechanism
with Backrest Screws "G".
NOTE: Fully tighten all screws.
F
x 2
K
G
Step 3
Attach Mechanism "H" to Seat Cushion "C" with
Mechanism Screws "D" and Washers "E".
NOTE: Fully tighten all screws.
K
x 4
D
x 4
E
H
C
