Before You Begin - SKLZ Pro Mini Hoop System Setup Instructions

PARTS:
Front
1 – Base
7 – Height Adjustment Pole
Locking Pin Attached
8 – Height Adjustment Handle
9 – Lower Backboard Bracket (2)
10 – Upper Backboard Bracket (2)
HARDWARE:
Rim Plate Top Base Bottom Base
Plate (2) Plate (2)
Red Base Cap Locking Pin with
Safety Chain (2)
1" Bolt, Lock Washer,
Washer –
Attaches bottom pole to base
1.5" Bolt (3),
Nut (3), Washer (3)–
Attaches rim to backboard
1.5" Bolt with Blue
adhesive (2),
Lock Washer (2)–
Attaches poles together
2 – Bottom Pole
3 – Middle Pole
5 – Base Arm (R)
4 – Top Pole 6 – Base Arm (L)
11 – Backboard
Mini Basketball
(7" in dia.)
12 – Rim Net (not shown)
TOOLS:
2-Sided
Wrenches (2)
1.25" Hex Bolt (4), 3.25" Hex Bolt (3),
Nut (4), Washer (8)– Nut (3), Washer (6)–
Attaches base arms to base Attaches brackets to
height adjustment handle
and to top pole
1.5" Hex Bolt (4),
Nut (4), Washer (8)–
Attaches backboard to brackets
1.75" Hex Bolt, 2.5" Hex Bolt,
Nut, Washers– Nut, Washers–
Attaches height adjustment Attaches arm braces to
pole to top pole bottom pole

BEFORE YOU BEGIN:

» Make sure you have all of the Pro Mini Hoop System components. Please contact SKLZ
customer service toll free at 877-225-7275 x128 if you are missing anything.
» Read all setup and usage instructions carefully.
» You will need water or up to 130 lbs of sand to fill the base.
» Do not use if base is not full of sand and/or water.
» Adult setup required.
» Do not hang on the rim.
Backboard (11)
Upper Backboard Brackets (10)
Lower Backboard Brackets (9)
Height Adjustment Handle (8)
Height Adjustment Pole (7)
Top Pole (4)
Middle Pole (3)
Locking Pin
Bottom Pole (2)
Base Arm (5)
Base Arm (6)
Base (1)
Red Base Cap
Top Base Plate
PRO MINI HOOP SYSTEM
Rim (12)
Mini Basketball
(air pump not included)
SKLZ.com
