Hoffrichter point 2 CPAP Brief Instructions

ACCESSORIES (OPTIONAL)

Therapy air humidifier Filter system
aquapoint 2 filtersystempoint 2
020
122
JAB
Please refer to the respective user's manual for further information.

CHANGING THE FILTER

Pull out the filter on the back of the device and replace it with a
new or cleaned one.
Always use the device with the filter element inserted and
clean the filter element regularly. If the filter element is heav-
ily soiled or not inserted, this may damage the device and
result in unpleasant odors.

TECHNICAL DATA

power supply
Main power 100 ... 240 V AC, 50 ... 60 Hz/ max. 1,0 A
DC power 24 V DC / max. 2.01 A

CLEANING

Cleaning the filter
1. Pull out the filter on the back of the device.
2. Clean the filter with mild soapy water (do not use any other agents), rinse the filter thor-
oughly with clear water and let the filter dry completely.
Cleaning the mask daily
Battery pack 1. Disconnect the mask with the exhalation valve from the therapy tube.
powerpackpoint 2
2. Use mild soapy water for cleaning (do not use any other agents), rinse thoroughly with
clear water and let the mask dry completely, protected from direct sunlight.
Cleaning the therapy tube weekly
1. Disconnect the therapy tube from the device and the mask.
2. Use mild soapy water for cleaning, rinse the tube thoroughly with clear water and let
the vertically suspended therapy tube dry completely.
Cleaning the device weekly
1. Unplug the mains plug.
2. Wipe the device with a cloth slightly moistened with soapy water and then rub dry.
JAB122020
Cleaning the headgear
If necessary, the headgear must be cleaned as follows:
1. Remove the headgear from the mask.
Removing the filter
2. Clean the headgear in accordance with the information in the headgear manufactur-
er's user's manual.
HOFFRICHTER GmbH
Mettenheimer Straße 12 / 14
19061 Schwerin
Germany
Telephone: +49 385 39925 - 0
Fax: +49 385 39925 - 25
Email: info@hoffrichter.de
www.hoffrichter.de
point 2 kurz ENG_2019-08-09_6.0
5 0 0 0 0 5 1 9
1

Therapy tube connection

2 Humidifier lock
3 Selection keys
4 Enter key
5 Display
6 ON/OFF key
7 Contact socket for humidifier
(optional equipment variant)
8 Control panel for humidifier
(optional equipment variant)
9 Rating plate
10 SD card slot
11 Filter or connection port for
the filtersystempoint 2
12 Air inlet for baro sensor
0
02
22
B1 13 RS232 interface
JA
14 DC power connection
Brief instructions
point 2 CPAP • point 2 AUTOCPAP •
point 2 BILEVEL S20 • point 2 BILEVEL ST20 •
point 2 BILEVEL ST25 • aquapoint 2 •
powerpackpoint 2
as of device software 3.400
