Frigidaire FRT18KG3C Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18KG3C
  6. Factory parts catalog
Frigidaire FRT18KG3C Factory Parts Catalog

Frigidaire FRT18KG3C Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18KG3C:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18KG3CW0
FRT18KG3C
MARKET
North America
ENERGY GUIDE - 240572160
OWNER'S GUIDE - 240400109
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995388468
030404
-EN/SERVICE/KHB
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KG3C
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18KG3C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT18KG3C

Summary of Contents for Frigidaire FRT18KG3C

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT18KG3CW0 FRT18KG3C MARKET North America ENERGY GUIDE - 240572160 OWNER’S GUIDE - 240400109 SERVICE DATA SHEET - 240379010 ELECTROLUX HOME PRODUCTS,INC. P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a white TOP MOUNT REFRIGERATOR FRT18KG3C Publication No.
