Frigidaire FRT18KG3C Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18KG3C
  6. Factory parts catalog
Frigidaire FRT18KG3C Factory Parts Catalog

Frigidaire FRT18KG3C Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18KG3C:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18KG3CW2
FRT18KG3C
MARKET
North America
ENERGY GUIDE - 240572160
OWNER'S GUIDE - 240400110
SERVICE DATA SHEET - 240379011
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995398194
031103
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KG3C
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18KG3C and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18KG3C

Summary of Contents for Frigidaire FRT18KG3C

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18KG3CW2 FRT18KG3C R134a white MARKET North America ENERGY GUIDE - 240572160 OWNER’S GUIDE - 240400110 TOP MOUNT SERVICE DATA SHEET - 240379011 REFRIGERATOR Model No. FRT18KG3C ELECTROLUX HOME PRODUCTS,INC. P.O.
  • Page 2 Publication No. FRT18KG3CW2 5995398194 DOOR 11/03...
  • Page 3 FRT18KG3CW2 Publication No. 5995398194 DOOR POS. NO PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240534901 Rack-door 240534701 Rack-door,4B 240337703 Door-dairy,w/o graphics ,clear 240534801 Rack-door 240381301 Plug-button,white ,hinge brg hole ,(2) 240412501 Door,frzr ,white ,complete assy 240415201 Label-nameplate,white 240312403 Door Stop,white ,ref...
  • Page 4 Publication No. FRT18KG3CW2 5995398194 CABINET 11/03...
  • Page 5 FRT18KG3CW2 Publication No. 5995398194 CABINET POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462010 Cover-evap coil 240568601 Seal-coil cover 241520701 Harness-wiring 5303208309 Plug-hole,factory test 240366801 Plug-ice maker harness,rectangular...
  • Page 6 Publication No. FRT18KG3CW2 5995398194 SHELVES N05SAAADF11 11/03...
  • Page 7 FRT18KG3CW2 Publication No. 5995398194 SHELVES POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358002 Shelf-freezer,full width 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701 Socket-light/lamp 240352701 Control Box 17*# 240388701 Wiring Harness,control box...
  • Page 8 Publication No. FRT18KG3CW2 5995398194 SYSTEM N05CBBBAB0 11/03...
  • Page 9 FRT18KG3CW2 Publication No. 5995398194 SYSTEM POS. NO PART NO DESCRIPTION 240406406 Condenser,static 240405201 Grommet,rubber ,black ,cond tube/wire 5303208866 Spacer,condenser tube ,black 5308000296 Bracket,condenser mtg ,(4) 218944001 Drier-filter,R134a System 240581601 Harness-wiring,machine compt 241520701 Harness-wiring 6* # 240388701 Wiring Harness,control box 6* # 240581801 Harness-wiring,compressor 14 #...

  • Page 10: Wiring Schematic

    Publication No. FRT18KG3CW2 5995398194 WIRING SCHEMATIC 11/03...

  • Page 11: Wiring Diagram

    FRT18KG3CW2 Publication No. 5995398194 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
