- Page 1 Q UIC K INST ALLAT IO N G UIDE XR Se rie s Wire le ss Arra ys XR-2425H Fe b rua ry 11, 2014...
- Page 2 XR-2425H Q uic k Insta lla tio n G uid e is a registered trademark of Xirrus, Inc. All other trademarks and brand names are marks of their respective holders. All rights reserved. This document may not be reproduced or disclosed in whole or in part by any means without the written consent of Xirrus, Inc.
-
Page 3: You Need The Following Items
Power—XR-2425H Arrays are powered via Power over Gigabit Ethernet (PoGE) using an outdoor-rated Ethernet Cat 5e or Cat 6 cable that also carries data traffic. Only Xirrus- supplied power injectors, or 802.3at PoE-compliant switches, may be used to power the XR-... -
Page 4: Choose A Suitable Location
2425H. The XR-2425H is powered by one injector port rated at 30W or higher. See the Installation Guide for your PoE device for more information. NOTE: Xirrus-supplied PoGE Injectors and switches must be installed and used indoors. 2) Choose a Suitable Location The XR-2425H is tested to IP65 water proof and dust proof requirements to protect against severely wet and dusty environments. - Page 5 5) Mount the Array on a Pole or Wall 5a) Pole Mounting For pole mounting, Xirrus recommends using metal straps (not included with the Array). The metal straps can be obtained from BAND-IT-IDEX, Inc. (www.BAND-IT-IDEX.com). See their web site for additional contact information. Complete the following steps to mount the Array to a pole.
- Page 6 XR-2425H Q uic k Insta lla tio n G uid e Hand tighten the Band-It strap through the pole mounting bracket, thread it through the strap buckle and then bend the strap back. Using the Band-It tool, place the tool onto the strap. ...
-
Page 7: 5B) Wall Mounting
XR-2425H Q uic k Insta lla tio n G uid e Your installation should now appear as shown here. Using a hammer, bend back and flatten the remaining strap. Using a hammer, bend and flatten the two tabs on the buckle to hold the flattened strap end in place. -
Page 8: Ground To Earth Ground
All XR-2425H Arrays are powered directly via a Gigabit Ethernet connection. See the figure in Step 9 for the names of all ports. Power: These Arrays are only powered through the GIG1 POE port. Only Xirrus-supplied power injectors or 802.3at PoE-compliant switches may be used to power the XR-2425H. ... - Page 9 XR-2425H Q uic k Insta lla tio n G uid e This will not seat properly in the waterproof connector, and the assembly will not be watertight. The components of the connector are shown in the photo below in the order that they are placed onto the Ethernet cable, and also shown in more detail as a color-coded drawing.
- Page 10 XR-2425H Q uic k Insta lla tio n G uid e Snug all of the components together as shown, but leave the RJ45 connector protruding. Tighten the sealing nut lightly, making sure that the RJ45 connector is rotated so that it will seat easily in the connector body later.
-
Page 11: Connect The Antenna
Array. Thus, you must configure the Array to correspond: set each IAP to the correct frequency band using the Xirrus Management System (XMS) or the Array’s CLI or Web Management Interface (WMI). -
Page 12: Zero-Touch Provisioning And Ongoing Management
Create and configure a default profile for newly added Arrays/APs – these new devices will automatically receive the configuration defined in your default profile. If you are not using XMS, new devices can be auto-provisioned via the Xirrus Mobilize platform (pre-order required) as shown in this video: http://www.xirrus.com/TV/Training/Mobilize- Training. - Page 13 XR-2425H Q uic k Insta lla tio n G uid e Dimensions XR-2425H Dimensions Depth is 4.2 in (10.7 cm), including the mounting bracket. 11.8 in Weight: 7.5 lbs (3.4 Kg) 30 cm 11.4 in 28.9 cm Mounting Bracket Dimensions 3.2 in 8.1 cm 13.3 in...
- Page 14 Xirrus equipment. Additionally, verify that the ambient operating temperature does not exceed 65°C. Software used by the modular Arrays (APs) is covered by the Xirrus Software License and Product Warranty Agreement. Non-Modification Statement: Unauthorized changes or modifications to the device are not permitted.
- Page 15 WARNING: Ultimate disposal of this product should be handled according to all national laws and regulations. WARNING: Incorrect installation of Xirrus Arrays may invalidate FCC, CE mark, or other regulatory compliance approvals. Customers are responsible for any legal violations from operation of un-approved equipment or incorrect installation.
- Page 16 XR-2425H Q uic k Insta lla tio n G uid e CAUTION: Xirrus PoGE Injectors rely on the building’s installation for over current protection. Ensure that a fuse or circuit breaker no larger than 120 VAC, 15A (U.S.) or 240 VAC, 10A (International) is used on all current-carrying conductors.
- Page 17 The FCC with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. When used with approved Xirrus antennas, Xirrus XR products meet the uncontrolled environmental limits found in OET-65 and ANSI C95.1, 1991. Proper installation of this radio according to the instructions found in this manual will result in user exposure that is substantially below the FCC recommended limits.
-
Page 18: Industry Canada Statements And Warnings
Xirrus Arrays are certified to the requirements of RSS-210. The use of this device in a system operating either partially or completely outdoors may require the user to obtain a license for the system according to the Canadian regulations. -
Page 19: Eu Directive 1999/5/Ec Compliance Information
This declaration is only valid for configurations (combinations of software, firmware and hardware) provided and/or supported by Xirrus Inc. The use of software or firmware not supported/provided by Xirrus Inc. may result that the equipment is no longer compliant with the regulatory requirements. - Page 20 EMC: EN 301 489-1 and EN 301 489-17 Safety: EN 50371 to EN 50385 and EN 60601 CE Marking: For the Xirrus Wireless Array, the CE mark and Class-2 identifier opposite are affixed to the equipment and its packaging: - 1 8 -...
- Page 21 **France is indoor use only in the upper end of the band. The requirements for any country may change at any time. Xirrus recommends that you check with local authorities for the current status of their national regulations for both 2.4 GHz and 5 GHz wireless LANs.
- Page 22 EU member states, the EU Directive 1999/5/EC has also been implemented in those countries. RF Exposure Generic Information The Xirrus Array products are designed to comply with the following national and international standards on Human Exposure to Radio Frequencies: US 47 Code of Federal Regulations Part 2 Subpart J ...
- Page 23 XR-2425H Q uic k Insta lla tio n G uid e Only antennas provided by Xirrus for use with the product should be installed. The use of any other antennas may cause damage to the Arrays or violate regulatory emission limits and will not be supported by Xirrus.
- Page 24 XR-2425H Q uic k Insta lla tio n G uid e Industry Canada Guidelines for Exposure to Radio Waves The Xirrus Arrays include radio transmitters and receivers. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) as referenced in Health Canada Safety Code 6.
- Page 25 XR-2425H Q uic k Insta lla tio n G uid e Notes...
- Page 26 The Xirrus Customer Support Website provides online documents and tools for troubleshooting and resolving technical issues with Xirrus products and technologies. Access to all tools on the Xirrus Customer Support Website requires a login user ID and password. If you have a valid service contract but do not have a user ID or password, you can register at this URL: http://support.xirrus.com...
