Summary of Contents for Daniela DAN90AFS
- Page 1 DAN90AFS 90CM BUILT IN 11 FUNCTION ELECTRIC OVEN WITH ROTSSERIE A p p l i a n c e U s e r M a n u a l danielaappliances.com.au...
- Page 2 From an Italian heritage our brand Daniela was then established in 2005 from a father’s love to a daughter and naming it after Daniela, now the new proprietor. Daniela has worked closely with her father for many years learning from his decades of industry experience.
- Page 3 DAN90AFS 90CM BUILT IN 11 FUNCTION ELECTRIC OVEN WITH ROTISSERIE PA G E 3 02 9604 1226 sales@danielaappliances.com.au danielaappliances.com.au...
- Page 4 Commercial warranty on Daniela Appliances are strictly 3 months from date of purchase. Daniela Appliances Pty Ltd will not be held responsible for any damage due to: Incorrect installation, improper, incorrect and irrational use. Before using the appliance, read the user manual carefully. Always keep this user manual close to hand since you may need to refer to it in the future.
- Page 5 The user must not replace the supply cable of this appliance. Always call an after-sales servicing centre authorized by Daniela Appliances in the case of cable damage or replacement. This appliance must be used for the purpose for which it was expressly designed. Any other use is considered to be improper and consequently dangerous.
- Page 6 PLEASE ENSURE YOU READ THESE INSTALLATION GUIDES, RULES, TERMS AND CONDITIONS BEFORE CALLING FOR A SERVICE. FAILURE IN DOING SO MAY RESULT IN DAMAGES TO THE APPLIANCE AND JOINERY – CHARGES MAY BE APPLICABLE AND WARRANTY WILL BE VOIDED. • Never allow the Mains Cable to be stretched, pulled or damaged if the appliance is moved for cleaning etc.
- Page 7 Only a qualified person in compliance with the instructions provided must install the appliance. Appliance are fully assembled as in normal operation without any parts removed. Daniela Appliances Pty Ltd declines all responsibility for improper installation, which may harm persons and animals and damage property.
-
Page 8: Installation
INSTALLATION • Remove all packaging, protective film and securing tape from the appliance. • Position the appliance in a dry atmosphere. • The following dimensions are provided as a guide for installation – your installer will carry out the installation in accordance with the current regulations. •... -
Page 9: Electrical Connection
ELECTRICAL CONNECTION Those ovens equipped with a three-pole power supply cable are designed to operate with an alternating current. The wire for earthling the appliance is yellow-green in colour. FITTING ON A POWER SUPPLY CABLE Opening the terminal board: • Using a screwdriver, prize the bolt on the side tabs of the terminal board cover;... - Page 10 The supply cable should be positioned so that it does not reach a temperature of more than 50ºC with respect to the room temperature, anywhere along its length, or protected by insulation sleeping having an appropriate rating. Before making the connection, check that: •...
-
Page 11: Technical Specifications
• All guards must be firmly fixed into place so that it is impossible to remove them without using special tools. • Remove the back of the kitchen unit to ensure an adequate current of air circulates around the oven. The hob must have a rear gap of at least 45 mm. TECHNICAL SPECIFICATIONS MODEL F948-100STMR, F948-101STIX... -
Page 12: How To Use Your Oven
Control Panel Oven Rack Side Support Rails Baking Tray with Grill Insert HOW TO USE YOUR OVEN This multifunction oven combines the advantages of traditional convection oven with those of the more modern fan assisted models in a single appliance. It is an extremely versatile appliance that allows you to choose easily and safely between different cooking modes. - Page 13 Notice: to use the oven in manual mode (not using the end cooking time programmer); the symbol must be aligned with the reference mark on the control panel. ROTISSERIE To start the rotisserie, proceed as follows: • Insert the rotisserie rod “A” into the drive unit and groove “B” into bend “C”; •...
-
Page 14: Before Using For The First Time
BEFORE USING FOR THE FIRST TIME SETTING AND CHANGING THE CURRENT TIME The oven only operates when the time has been set. When the appliance is connected to the electrical supply or when there has been a power cut, the symbol for Time flashes automatically. •... -
Page 15: Thermometer Symbol
THERMOMETER SYMBOL • The slowly rising thermometer symbol indicates how hot the oven is as it heats up. • The three segments of the thermometer symbol show that Fast Warm Up is working. CHANGING THE OVEN FUNCTION To change the oven function, Press the button repeatedly until the desired oven function is displayed. -
Page 16: Memory Function
IMPORTANT Do not put the food to be cooked into the oven, until the power boost is complete and the oven is operating using the desired function. • Select your desired function and If necessary, change the pre-programmed intuitive cooking temperature. -
Page 17: General Instructions
END TIME To set when the oven is to switch off again. TIME To set, change or check the time (See also section “Before Using for the First Time”) GENERAL INSTRUCTIONS • After a clock function has been selected, the corresponding symbol flashes for approx. 5 seconds. -
Page 18: Other Functions
END TIME • Select oven function and using button select temperature. • press the Clock Function button repeatedly until the symbol for End time flashes. • Using the button set the desired switch-off time. • The symbols for End time and Cook time light up. -
Page 19: Button Beep
SWITCHING ON THE DISPLAY • If required, switch on the appliance using the On/Off button. • Press the Clock Functions button and the button at the same time until the display comes on again. CHILD SAFETY DEVICE As soon as the child safety device is engaged, the appliance can no longer be switched on. ACTIVATING THE CHILD SAFETY DEVICE •... - Page 20 FUNCTION LIGHT This function turns the light on in your oven. Useful for when cleaning. DEFROST This function operates by using the fan only. The air is distributed inside the oven allowing for food to defrost at a quicker rate, and without protein alteration. CONVECTION The top and lower heating element is switched on.
- Page 21 FUNCTION BOTTOM ELEMENT WITH FAN This function utilises both the bottom element and the rear fan at the same time. For best results use the bottom 3 shelf positions when using this function. Perfect for any foods that require a crunchy base. Perfect for pizza (both fresh and frozen), quiche, pizza etc.
-
Page 22: Pizza Mode
FUNCTION Alternatively, this mode can also be used to quickly thaw white or red meat and bread by setting the temperature to 60ºC. To prove dough, set the thermostat to its lowest temperature possible while using this function PIZZA MODE The bottom and circle heating elements, as well as the fan, will come on. -
Page 23: How To Clean Your Oven
HOW TO CLEAN YOUR OVEN WARNING!! • NEVER USE STEAM CLEANERS OR PRESSURE CLEANERS TO CLEAN YOUR APPLIANCE, AS THEY CAN CAUSE MOISTURE BUILD UP! • NEVER USE CAUSTIC OR ABRASIVE CLEANERS OF ANY KIND AS THEY WILL DAMAGE YOUR OVEN! •... - Page 24 HOW TO REMOVE THE OVEN DOOR For a more thorough clean, you can remove the oven door. Proceed as follows: • Open the door fully; • Lift up and turn the small levers situated on the two hinges; • Grip the door on the two external sides, shut it slowly but not completely; •...
-
Page 25: Repair, Or Adjustment
WARNING!! Do not operate appliance with damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner, please contact Daniela Appliances Pty Ltd. REPAIR, OR ADJUSTMENT During operation, the oven glass door and adjacent parts of the appliance become hot. - Page 26 DO NOT INSTALL OR USE THE APPLIANCE. In this instance please contact your retailer or Daniela Appliances direct. Keep packing material such as plastic bags, polystyrene, nails or screws out of the reach of children, as they are a choking hazard.
-
Page 27: Terms And Conditions
If your goods remain boxed and in an unopened condition, they may be returned with in 30 days of the invoice date for a full refund. A collection fee of $50 will be charged should you require Daniela Appliances Pty Ltd to collect the stock. - Page 28 02 9604 1226 sales@danielaappliances.com.au A 6/9 Hume Road, Smithfield NSW 2164 danielaappliances.com.au...
