- Page 1 Manual for installation, use and maintenance MHG102 Gas hob year parts 1 year labour guarantee www.matrixappliances.co.uk...
-
Page 2: Table Of Contents
Contents: Important Important Notes Using Your Hob Igniting the burners Efficient use of your hob Care And Maintenance Troubleshooting What to do if you smell gas Mains Electricity Connection Technical Information Gas Supply Requirements Ventilation Natural Gas to LPG Conversion LPG to Natural Gas Conversion Fitting the hob How to install the hob... -
Page 3: Important
Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment. - Page 4 EU Declarations of Conformity This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Electrical safety (LVD) 2014/35/EU and Electromagnetic interference compatibility (EMC) 2014/30/EU. Parts intended to come into contact with food conform to 1935/2004/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
-
Page 5: Important Notes
Important Notes Please note: • Gas hobs become hot and remain hot during and immediately after use. We strongly advise that you do not touch the hob, nor any of its components, until it has been allowed to cool. If wiping away a spillage, please take every care not to burn yourself. -
Page 6: Using Your Hob
Using your hob Fig.1 Gas Burners 1. Rapid burner 2.8kW 2. Left Semi-rapid burner 1.8kW 3. Right Semi-rapid burner 1.8kW 4. Auxiliary burner 1.0kW Control knobs 5. Front left 6. Back left 7. Back right Fig.2 8. Front right... -
Page 7: Igniting The Burners
Gas burners Gas flow to the burners is controlled by the control knobs (5,6,7 and 8 on Fig.1). There are 3 positions shown on the control panel (Fig.2). Turning the control knob to the positions shown below achieves the following: Closed (switches gas valve and burner off) Maximum position (highest heat level) &... - Page 8 of the flame. Once lit, release the control knob and turn it to the desired position i.e. until the burner flame is at the required intensity. Once you have finished cooking with the burner(s) in use, return the Fig.3 control knobs to the closed (off) position.
-
Page 9: Efficient Use Of Your Hob
Efficient use of your hob The hob is equipped with burners of different sizes, designed to accommodate most sizes of pan. For best results, only use pans with flat bottoms and choose an appropriate burner depending on the size of the pan. The most efficient use of the hob is shown below, where the pan and burner are correctly chosen. -
Page 10: Care And Maintenance
Care and maintenance The hob has a stainless steel surface. Due to this you should use a non-abrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. Stainless steel can be effectively cleaned by simply using a dilute solution of water and washing up liquid and drying to a shine with a clean cloth. -
Page 11: Troubleshooting
Troubleshooting IF YOUR HOB IS NOT WORKING: 1. Check that the mains supply has not been switched off. 2. Check that the fuse or circuit breaker has not blown/tripped. 3. Check that the burner crowns and caps are fitted correctly and are not impeding the ignition candles or the flame failure devices (circled in Fig. -
Page 12: What To Do If You Smell Gas
WHAT TO DO IF YOU SMELL GAS: 1. Turn off the gas. For natural gas - Turn off the gas supply at the meter situated at the emergency control valve (ECV) unless the meter is located in a basement or cellar. - Page 13 5. Call the Gas Emergency Contact Centre In the case of natural gas, contact the Gas Emergency Service Provider (ESP) or, in the case of LPG, the Gas Supplier. Below is a list of ESPs relevant to region: England, Scotland and Wales: Natural Gas - 0800 111 999 (Gas Emergency Contact Centre) LPG - Bulk and Metered supplies - See telephone number on bulk storage vessel or at the meter.
- Page 14 Channel Islands - Jersey: Mains Gas + LPG (mains gas in the Channel Islands is an LPG and air mixture) - 01534 755555 (Jersey Gas Company Ltd.) Isle of Man: Natural gas and LPG - 0808 1624 444 (Manx Gas Ltd.) Gas Emergency contact details for the four main suppliers of LPG in the British Isles are shown below: Calor - 08457 444 999...
-
Page 15: Mains Electricity Connection
Mains Electricity Connection Warning! This appliance must be earthed. This appliance must be connected to the mains power supply by a competent person using fixed wiring via a double pole switched fuse spur outlet, having a contact separation of at least 3mm in all poles, and protected by a 3A fuse. -
Page 16: Technical Information
The wires in the mains lead of this appliance are coloured in accordance with the following code: Green & Yellow = Earth Blue = Neutral Brown = Live As the colours of the wires in the mains lead for this appliance may not correspond with the coloured markings identifying the terminals connecting to the fuse spur, proceed as follows: •... -
Page 17: Gas Supply Requirements
Gas Supply Requirements IMPORTANT: THIS APPLIANCE MUST BE FITTED BY A GAS SAFE REGISTERED FITTER OR OTHER SUITABLY QUALIFIED PERSON. • This installation must comply with the Gas Safety (installation and use) Regulations 1984. • This appliance is category II2H3+ and is designed for use in the UK and Ireland. -
Page 18: Ventilation
Ventilation All rooms require a window, or equivalent (e.g. a door), which can be opened. Some rooms require a permanent vent in addition to a window (see below). This unit must not be used in a room which is less than 5m³. The following table details the requirements based on the kitchen volume (DxWxH) in m³. -
Page 19: Lpg To Natural Gas Conversion
3. Remove the injectors and replace with the corresponding injector as shown in the table at the bottom of this page. Setting up minimum flow rates: Remove the control knobs. 2. Turn on the LPG supply, light the burners and turn the controls to the minimum position, as indicated by the small flame. -
Page 20: Fitting The Hob
Fitting the hob Unpacking the hob: Take care not to lose or mishandle any parts. Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 150mm away from any adjacent vertical surfaces, e.g. -
Page 21: How To Install The Hob
• If there is no oven to be built in below the hob it is recommended that, an isolation shelf should be fitted to protect the user from high temperatures. If the hob is to be installed above a working drawer, then a partition should be fitted to protect the contents and user from the heat generated during use. - Page 22 >61.5mm 490mm 560mm 150mm 150mm Fig. 6 Fig. 7 1 - Worktop 2 - Screw 3 - Bracket Fig. 8 4 - Hob B/B* 500x20 mm 500x10 mm 500x10 mm min 30 mm Fig. 9...
-
Page 23: Energy Efficiency Information
Energy Efficiency Information Attribute Symbol Value Units i t n c i f t l i Energy e ciency per gas burner Aux:NA / Gas burner SR:54.5 / SR:54.5 / R:54.5 Energy e ciency for the gas hob 54.5 Gas hob A) Measurement and calculation methods •... - Page 24 Serviced by For our Customer Care Department, or for Service, please contact us on: The CDA Group Ltd. Harby Road, Langar, Nottinghamshire, NG13 9HY Tel: 01949 862012 Fax: 01949 862003 Email: customer.care@cda.eu...
