- Page 1 MHC201FR Ceramic Hob Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
- Page 2 Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
- Page 3 (EMC) 2004/108/EC. Parts intended to come into contact with food conform to 89/109/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 • Do not place hot lids flat on the hob top. A “suction” effect could cause damage to the hob. • Do not drag cookware across the hob top: in the long term, this could cause damage to the hob. •...
-
Page 5: Using Your Hob
Using your hob Zones: 1. Front left 2.3kW 210 mm 2. Back left 1.2kW 145 mm 3. Front right 1.2kW 145mm 4. Back right 1.8kW 180 mm fig. 1 fig. 2 Control panel: 1. On/off sensor 4. Plus setting selector 2. - Page 6 Using Your Hob To switch the hob on • To switch the power on, touch and hold the "On/off sensor" (1) approximately two seconds. The hob will beep and all four cooking zone indicators will show “0”. Please note: When switching the hob on after the appliance has been switched off at the mains, the cooking zone indicators may show, an "...
- Page 7 • If switching off multiple zones, the above step needs to be taken for each zone. When all the zones are at "0", the hob will switch off automatically after approximately ten seconds. • To switch off the hob immediately, touch and hold the "On/off sensor"...
- Page 8 Auto-heat Function All zones are equipped with an auto-heat function, which reduces the warming up time for the zone. Each power level has a limited time for which the auto-heat function can be used. A table showing these times is shown at the bottom of this page. To activate the auto-heat function on a zone •...
-
Page 9: Keep Warm Function
Please note: The auto-heat function is not compatible with power level 9 or the keep warm function. Keep Warm Function Each zone is equipped with a keep warm function that is designed to keep food at a stable temperature. This allows the serving of food to be delayed and also for the melting of butter or chocolate. -
Page 10: Safety Key Lock
Safety Key Lock To prevent accidental use, the hob has a safety key lock which switches controls off temporarily or completely. The safety key lock can be activated when the hob is turned on but not when power has been switched off at, or the appliance disconnected from, the mains. The safety key lock is automatically activated after mains power supply has been restored. -
Page 11: Residual Heat Indicators
Residual Heat Indicators The hob is equipped with residual heat indicators to warn when any of the zones are still hot to the touch after use. An “ ” will show in a zone’s indicator if the relevant zone is between 45°c and 60°c. An “... -
Page 12: Efficient Use Of Your Hob
Efficient Use of Your Hob The hob is equipped with zones designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms. The most efficient use of the hob is shown below, where the pan and zone are correctly chosen. -
Page 13: Care And Maintenance
Care and Maintenance Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. Important: • Steam cleaners must not be used when cleaning this appliance. • You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. - Page 14 Type of residue Clean with Cleaning advice Wipe over the zone to be cleaned with Cleaning sponge Light a sponge and hot water, and then wipe and soft cloth off with a soft dry cloth. Wipe over the zone to be cleaned Accumulated baked- Cleaning sponge with a sponge and hot water, using a...
-
Page 15: Troubleshooting
Troubleshooting Problem Possible Causes Possible Remedy The appliance does not You observe that Possible Causes What should you do? The appliance has no Check the fuse and work and no indicators are power replace if blown. The hob is not lit. - Page 16 Problem Possible Causes Possible Remedy Residual heat indicator The appliance has no Check the fuse and has extinguished despite power or the residual heat replace if blown. zone(s) still being hot. timer has expired (page 11). Stop using the appliance immediately and switch the Hob top is broken, cracked appliance off at the mains.
-
Page 17: Fitting The Hob
Fitting the Hob Unpacking the hob: Installation above a cupboard unit Take care not to lose, drop or mishandle any parts. 25mm Fitting position of the hob: 35mm This appliance must be installed a 500 x 10mm minimum of 50mm from any back wall and a minimum of 55mm away from any adjacent vertical surfaces, e.g. - Page 18 If fitting a cooker hood above the hob: If a cooker hood is to be installed above the hob, the height of the hood above the hob must be at least 600mm (650mm is recommended) (Fig.6). If the instructions supplied with the hood dictate that the hood must be installed at a height greater than 600mm, Fig.6...
-
Page 19: How To Install The Hob
How to Install the Hob Overall dimensions of the hob: Width: 576 mm Depth: 518 mm Worktop cut-out dimensions: Width: 560 mm Depth: 490 mm 1 - Worktop 2 - Hob seal 1. Make the required hole in the worktop. 3 - Ceramic hob Fig.7 Before doing this, you must check the... - Page 20 If fitting the hob into a 28-40mm worktop: The four fixing clips supplied should be used. If fitting the hob into a thin worktop (i.e. 28mm), then we recommend using four 15x15x50mm wooden batons in addition to the brackets (as per figs. 9 and 10). Position the fixing brackets perpendicularly to the hob’s edge and tighten firmly.
-
Page 21: Mains Electricity Connection
Mains Electricity Connection Warning! This appliance must be earthed. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T. and local regulations. Live L: BN - brown Neutral N: BU - blue Earth PE: GNYE -green/yellow This appliance is intended to be... - Page 22 • This appliance is intended to be connected to the mains supply with a cable of cross sectional area 4mm 2 . • The current rating of the fuse or circuit breaker protecting this appliance should be marked on the socket outlet. •...
- Page 23 Energy E ciency Information Attribute Symbol Value Units Matrix model MHC201FR Type of hob Built in Number of cooking zones and/or areas Heating technology (induction cooking Radiant zones and cooking areas, radiant cooking zones cooking zones, solid plates) For circular cooking zones or area: Ø...
- Page 24 Serviced by To contact our Customer Care Department, or for Service, please contact us on the details below. Passionate about style Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY Customer Care Department • The Group Ltd.
