Summary of Contents for Matrix MHE001
- Page 1 MHE001 electric hob Manual for Installation, Use and Maintenance...
-
Page 2: Table Of Contents
Contents: 1 Important notes 2 User info 3 Using your hob 4 Efficient use of your hob 5 Fitting the hob 6 How to install the hob 8 Mains Electricity Connection 9 Care and maintenance... - Page 3 Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
-
Page 4: User Info
User information • Electric hobs become hot during and immediately after use. Do not touch the hotplates or the hob spill tray until the appliance has been allowed to cool. • Keep children away from the appliance when in use. •... -
Page 5: Using Your Hob
Using your hob Fig.1 ELECTRIC HOTPLATES: 180mm (FL) 1.5kW 145mm (BL) 1.0kW 180mm (BR) 2.0kW 145mm (FR) 1.5kW Control panel: (BR) 180mm hotplate control (BL) 145mm hotplate control (FL) 180mm hotplate control (FR) 145mm hotplate control Hob in use indicator HOTPLATE SWITCHES: The power of each hotplate can be varied using the control knob to select the required heat. -
Page 6: Efficient Use Of Your Hob
Efficient Use of your Hob The hob is equipped with hotplates of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms and choose an appropriate hotplate depending on the size of the pan. The most efficient use of the hob is shown below, where the pan and hotplate are correctly chosen. -
Page 7: Fitting The Hob
Fitting the Hob Unpacking the hob: • Take care not to lose or mishandle any parts. Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 150mm away from any adjacent vertical surfaces, e.g. -
Page 8: How To Install The Hob
How to Install the Hob How to install the hob: Overall dimensions of the hob: Width: 580mm Depth: 500mm Worktop cut-out dimensions: Width: 557mm Depth: 477mm 1. Make the required hole in the worktop. Note that before doing this, check the instructions supplied with any cooker hood to ensure that you will have the required clearance. -
Page 9: Mains Electricity Connection
Mains Electricity Connection Warning! this appliance must be earthed We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E. and local regulations. This appliance is intended to be connected to fixed wiring and is not suitable for connection to a 13a plug or 13a supply. -
Page 10: Care And Maintenance
Care and Maintenance The hob has a stainless steel or enamel surface, you should use a non-abrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. Stainless steel can be effectively cleaned by simply using a dilute solution of water and washing up liquid and drying to a shine with a clean cloth. - Page 11 Energy Efficiency Information Attribute Symbol Value Units CDA model MHE001 Type of hob 195.95 Wh/kg Number of cooking zones and/or areas Heating technology (induction cooking Solid plates zones and cooking areas, radiant cooking zones, solid plates) For circular cooking zones or area: Ø FL:18.0 / diameter of useful surface area per FR:14.5 / electric heated cooking zone, rounded RL:14.5 / to the nearest 5mm RR:18.0 For non‐circular cooking zones or areas: length and width of useful surface area per electric heated cooking zone or area, rounded to the nearest 5mm Energy consumption per cooking zone FL:199.5 / Wh/kg Electric cooking or area calculated per kg FR:205.3 / RL:184.5 / RR:194.5 Energy consumption for the hob 195.95 Wh/kg Electric hob...
- Page 12 Serviced by To contact our Customer Care Department, or for Service, please contact us on the details below. Passionate about style Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
