LED
Power/Status LED - Dual color (Red/green)
. Flash Red during booting up or malfunction
. Static Green while it's ready/working
. Solid Red while boot up fail
Interfaces
* PoE kit (injector and adapter) is NOT include in the package and it can be purchased
with the model name "DPE-301GI".
2
2. Hardware Overview
Power Receptor
(*Note no longer
used, replaced
by PoE)
LAN Port (PoE)
D-Link DAP-2680 Quick Install Guide
