Before You Begin

This installation guide provides instructions
for installing the DAP-2610 on your network.
Additional documentation is also available on
the D-Link support website.
Nuclias Connect Manual: For additional
information and instructions on how
to configure the device using Nuclias
Connect.
DAP-2610 User Manual: For additional
information and instructions on how to
configure the device using the web user
interface.

Package Contents

This DAP-2610 package includes the following
items:
DAP-2610 Access Point
Power Adapter (Optional)
Mounting Plate and Hardware
Quick Start Guide
If any of the above items are damaged or
missing, please contact your local D-Link reseller.
Note: Using a power supply with a different
voltage than the one recommended for the
device will cause damage and void the warranty
for this product.
Note: No power adapter is supplied with this
product. To power the unit, use an 802.3af PoE
Switch or an 802.3af PoE Injector.
DAP-2610 Quick Installation Guide

System Requirements

Computers with Windows®, Macintosh®,
or Linux-based operating systems with an
installed Ethernet Adapter
Internet Explorer 11, Safari 7, Firefox 28,
or Google Chrome 33 and above (for
configuration)

Hardware Overview

LED Indicators

Figure 1: Front Panel LED
#
LED
Green (Solid) - Device operational
Red (Flashing) - Device booting
Power/
1
up/Device malfunctioned
Status
Red (Solid) - Device boot up
has failed
Table 1: LED Description
1
Description
1
