Frigidaire FRS26ZNJS Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26ZNJS:
Table of Contents

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FRS26ZNJSB1
FRS26ZNJS
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218987800
SERVICE DATA SHEET - # 218909401
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
BLACK/S.STEEL
Publication No.
5995343901
000922
-EN/SERVICE /DJH
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZNJS
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26ZNJS

Summary of Contents for Frigidaire FRS26ZNJS

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. FRS26ZNJSB1 FRS26ZNJS MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218987800 SERVICE DATA SHEET - # 218909401 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR R134a BLACK/S.STEEL REFRIGERATOR Publication No.

  • Page 2: Freezer Door

    Publication No. FRS26ZNJSB1 5995343901 FREEZER DOOR 09/00...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 FREEZER DOOR PART NO DESCRIPTION 215734323 Gasket-frzr door,black ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 218807028 Rack-door,w/end caps 215474052 Rack-door 218510401 Panel-inner door,frzr 5303918179 Panel-ext frzr door,stainless w/foam insulatn 5303289522 Door Stop...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZNJSB1 5995343901 REFRIGERATOR DOOR 09/00...
  • Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 REFRIGERATOR DOOR PART NO DESCRIPTION 215734324 Gasket-refr door,black ,magnetic 215403201 Panel-inner door,refr 5303304563 Door-dairy 5303289522 Door Stop 5303918180 Panel-ext refr door,stainless steel ,w/foam insulatn 218762708 Handle-door,gunmetal 218578600 Screw-door stop mtg,phl truss hd ,10-16 x 3/4...
  • Page 6 Publication No. FRS26ZNJSB1 5995343901 CABINET 09/00...
  • Page 7 POS. NO 10A* 30A* 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 CABINET PART NO DESCRIPTION 215637602 Cover-air duct 5303209814 Nut,"U" type ,8-15A ,fan mtr mtg 215637402 Cover-evap coil,lower 5308009617 Washer,ext tooth lock ,#10 ,grounding 5303208309 Plug-hole,factory test 215230400 Plug-harness hole 5303289043...
  • Page 8 Publication No. FRS26ZNJSB1 5995343901 SHELVES 09/00...
  • Page 9 POS. NO 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 SHELVES PART NO DESCRIPTION 5303298147 Trim-basket 218298003 Shelf-freezer,sliding ,wire 5304405879 Shelf-freezer,fixed wire 240324101 Shelf-pizza 215029009 Shelf-"Spill-Safe",cantilever ,sliding 215124343 Cover-storage pan 5303301393 Control-humidity 5304412757 Trim-storage pan cvr,uppr w/humidity hole 218015302 Trim-storage pan cvr,snap-on ,front 218015402...
  • Page 10 Publication No. FRS26ZNJSB1 5995343901 CONTROLS 09/00...
  • Page 11 POS. NO 13 # 15 # 16 # 17A* 21 # 23 # 114# 125# 141* 143# 143* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 CONTROLS PART NO DESCRIPTION 215028605 Knob-damper control 5308000010 Fan Blade,red ,evaporator fan 5308000124 Ring-fan orifice 5300157666 Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS26ZNJSB1 5995343901 SYSTEM 09/00...
  • Page 13 POS. NO 5* # 5* # 13 # 14 # 15 # 21 # 29 # 30 # 54A* 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 SYSTEM PART NO DESCRIPTION 218787900 Condenser 5303208866 Spacer-cond tube,black 5303289026 Spacer-tube 5304406721...
  • Page 14 Publication No. FRS26ZNJSB1 5995343901 DISPENSER 09/00...
  • Page 15 POS. NO 12A* 17A* 35 # 38 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 DISPENSER PART NO DESCRIPTION 218832301 Tube-water inlet,inlet valve ,to filter 218859901 Tube-water inlet,inlet valve ,to filter 218505303 Deflector-ice disp,black 215484300 Heater-door housing 218852405 Housing-dispenser,gunmetal 218284800...

  • Page 16: Ice Container

    Publication No. FRS26ZNJSB1 5995343901 ICE CONTAINER 09/00...
  • Page 17 POS. NO 16 # 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 ICE CONTAINER PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. FRS26ZNJSB1 5995343901 ICE MAKER 09/00...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNJSB1 ICE MAKER PART NO DESCRIPTION 218832301 Tube-water inlet,inlet valve ,to filter 218859901 Tube-water inlet,inlet valve ,to filter 3206348 Spring,shut-off arm 3206299 Label,ID plate 3206301...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZNJSB1 5995343901 WIRING SCHEMATIC 09/00...

  • Page 21: Wiring Diagram

    FRS26ZNJSB1 Publication No. 5995343901 WIRING DIAGRAM # = Fast-moving Parts 09/00 * = Non-Illustrated Parts...
