Introduction - MODSTER Arrows 1100mm sky trainer Operating Manual

Introduction

After the introduction of four fantastic 1100mm warbirds, Arrows Hobby is proud to announce the first trainer aircraft in the
lineup! 6 months in the making, the 1100mm Sky Trainer is the perfect scale-looking trainer!
Like traditional trainers, the 1100mm Sky Trainer has inherently easy and stable flight characteristics. Unlike traditional
trainers, Arrows Hobby has added scale cockpit details, tricycle landing gears, struts and even functional flaps for
unmatched slow-flight performance.
Assembled using only 2 screws, 4 latches and a bit of glue, the 1100mm Sky trainer can be flight ready in as little as 5
minutes!
Don't miss one of the best trainer aircraft to ever grace the skies! Get your 1100mm Sky Trainer today!
Features:
• Electronics: 3128- 1550KV motor, 20A ESC, 6x 9g servos, 7.4v 1300mAh 20C LiPO battery (RTF)
• Functional flaps
• Robust tricycle landing gear
• Lightweight, high strength EPO foam construction.
Table of contents
Introduction
······················································3
Specifications
······················································3
Kit contents
························································3
Model assembly
···················································4
Battery installation
···············································6
Receiver diagram
········
Preflight check
·····················································6
Clevis installation
·················································7
Control horn and servo arm settings
Center of gravity(CG)
············································8
Before flying the model
·········································8
Flight tips
···························································9
Trouble shooting
················································10
Spare parts list content
········································10
Kit contents
Before assembly, please inspect the contents of the kit. The photo below details the contents of the kit with labels. If any
parts are missing or defective, please identify the name or part number (refer to the spare parts list near the end of the
manual) then contact your local shop.
A.
D. E.
A: Fuselage
B: Main wing
C: Horizontal stabilizer
····· ········· ···························6
··························8
B.
D: Vertical stabilizer
E: Propeller and spinner set
F: Supporting bar
Specifications
Wingspan
Overall length
Flying weight
Motor size
Wing load
Wing area
ESC
Servo
Recommended battery
C.
G. H.
G: Antenna
H: Screws and linkage rods
I:Y-harness
1010mm(39.7in)
805mm(31.7in)
~ 700g
3128-KV1550
47.3g/dm² (0.11oz/in²)
14.8dm² (230sq.in)
20A
9g Servo x 6
7.4V 1300mAh 20C
I.
