MODEL S33
Fire Protection Air Compressor
Owner's Manual
REV. A
Dec/2/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S33 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for C-Aire S33

  • Page 1 MODEL S33 Fire Protection Air Compressor Owner’s Manual REV. A Dec/2/21...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������2 INSTALLATION �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������2 ELECTRICAL ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������4 START UP ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������5 DIGITAL PRESSURE SWITCH PROGRAMMING AND INSTRUCTIONS FOR S33 MODEL ����������������������������������������������������������������������������������������5 SYSTEM INSTALLATION DIAGRAM �����������������������������������������������������������������������������������������������������������������������������������������������������������������������7 MAINTENANCE ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������8 VALVES AND SWITCHES ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������8 TROUBLESHOOTING �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������9 WARRANTY �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������10 PARTS IDENTIFICATION / PART NUMBERS OF REPLACEABLE PARTS 1.
  • Page 3 Misuse of this valuable and helpful air-power source may shorten its expected life as well as void the warranty of the entire unit� We ask you take the time to read this manual to ensure the dependable service you can expect from your C-Aire compressor�...
  • Page 4: Safety

    INSTALLATION SELECTING A LOCATION: C-Aire compressors are to be installed and operated in a clean, dry, well-lighted, and well-ventilated area� Mounts to risers 2�5”-4”, concrete or cinder block walls or studs on a drywall� Provide at least 200 cubic feet of fresh air per 1 hp�...
  • Page 5 MOUNTING THE COMPRESSOR CAUTION: Remove the compressor from the shipping packaging before mounting� CAUTION: Do not mount unit horizontally� MOUNTING INSTRUCTIONS Riser INSTALL HANG Drywall MOUNTING UNIT ON BRACKET MOUNTING BRACKET Cinder block/Concrete RISER: Mounts to 2.5” riser or larger DRYWALL: Use 2x4s attached to studs in the drywall to attach the mounting bracket...
  • Page 6: Electrical

    WARNING: The compressor must be grounded� Grounding reduces the risk of electric shock� Certain C-Aire models are equipped with a cord that has a grounding wire with a grounding plug� The plug must be plugged into an outlet that is installed and grounded in accordance with all local codes and ordinances�...
  • Page 7: Start

    START UP NOTE: There is no need to “break-in” your compressor� It has been tested and run at the factory by qualified personnel� When operating the compressor for the first time, do the following: 1� Perform an inspection of the compressor to ensure there are no obstructions that might interfere with moving parts� 2�...
  • Page 8 DIGITAL AMD OPERATING INSTRUCTIONS (CONTINUED) To unlock, repeat the previous process until the SETTINGS Pressing the mode button a fourth time, the 7DAYS LOCKED light turns off� indicator will display the total number of starts in the last 7 days STARTS (The counter will not measure time if the unit has no power)�...
  • Page 9: System Installation Diagram

    SYSTEM INSTALLATION DIAGRAM S33R-LD1-115PD No AMD Permitted System pressure varies Air Source depending on size of system Check Valve Adjustable: 5-55 PSI Dry Pipe Valve Water in system Braided Flex Hose (Included) Low Pressure...
  • Page 10: Maintenance

    Pressure switches are standard on all C-Aire compressors� The pressure switch detects the demand for compressed air and allows the motor to start� When the demand is satisfied, the motor stops� Pressure switches are preset at the factory by C-Aire and do not require adjustment�...
  • Page 11: Troubleshooting

    • Pressure switch not making contact • See pressure switch adjustment • Knocking noise or internal pump issue • Internal pump problem • Call C-Aire for assistance • Check all fittings • WARNING: Bleed tank� Disassemble Check • Tank does not hold pressure when •...
  • Page 12: Warranty

    WARRANTY OIL FREE COMPRESSOR C-Aire Inc� warrants its compressors to be free from defects in material and workmanship subject to the following provisions: STANDARD WARRANTY DURATION: 12 months from date of install� WHAT THE WARRANTY COVERS DURING THE WARRANTY DURATION: All components on the compressor except for those items listed in the section titled “What is excluded from warranty coverage”�...
  • Page 14 380 West 1st Street, Dresser, WI 54009 800�762�2247 - 651�462�3440 www�cairecompressors�com...
