Summary of Contents for C-Aire S260R-LD1-115P
-
Page 2: Table Of Contents
Misuse of this valuable and helpful air-power source may shorten its expected life as well as void the warranty of the entire unit. We ask you take the time to read this manual to ensure the dependable service you can expect from your C-Aire compressor. -
Page 3: Safety
INSTALLATION SELECTING A LOCATION: C-Aire compressors are to be installed and operated in a clean, dry, well-lighted, and well-ventilated area, not less than 12 inches from walls or other equipment. Provide at least 1,000 cubic feet of fresh air per 5 hp. -
Page 4: Electrical
MOUNTING THE COMPRESSOR CAUTION: Remove the compressor from the shipping skid before mounting. ANTI-VIBRATION INSTALLATION ANTI-VIBRATION INSTALLATION Be sure your C-Aire compressor is mounted on a level, concrete floor, 1/2” LOCKNUT preferably using anti-vibration pads. (FINGER TIGHT ONL Y) 1/2” FLAT WASHER When installing anchor bolts from your installation kit, all anchor bolts should be finger tight only. - Page 5 Certain C-Aire models are equipped with a cord that has a grounding wire with a grounding plug. The plug must be plugged into an outlet that is installed and grounded in accordance with all local codes and ordinances.
- Page 6 National Electrical Wire From the Motor Code (NEC), the Canadian Electrical Code (CEC) and / or any local codes having precedence. QUESTIONS / HELP? Call C-Aire at 651.462.3440...
- Page 7 Wire From the Motor grounding between the power supply and the electrical control enclosure in accordance with the National Electrical Code (NEC), the Canadian Electrical Code (CEC) and / or any local codes having precedence. QUESTIONS / HELP? Call C-Aire at 651.462.3440...
-
Page 8: Parts Identification
S750H-HD1-115 Motor: MR EM3219T Serial Tag HP: 3 Serial # CA201200629 Pump: PM F 95W2 Oil Capacity: 2.23QT C-Aire Synthetic Compressor Oil Recommended MFG # 20120315 Replacement Parts Air Filter: 210-0952 Check Valve: BR c-7575-ST C-Aire (800) 762-2247 Serial Tag... - Page 9 Belt Guard Belt Guard Electric Motor Electric Motor Sight Glass Sight Glass Pressure Switch AUTO Pressure Switch Safety Relief Valve Safety Relief Valve Unloader Valve Unloader Valve...
-
Page 10: Lubrication
LUBRICATION ALL C-AIRE COMPRESSORS COME FACTORY FILLED WITH SYNTHETIC OIL WHICH REQUIRES NO BREAK-IN PERIOD. Oil Level: Check the oil level before each start-up. The oil level must be maintained to the center of the sight glass (unless there is an oil-level mark on the sight glass to indicate otherwise). -
Page 11: Start-Up
Change the oil. Your compressor has been shipped with C-Aire ISO 46 Compressor Oil. C-Aire recommends using C-Aire Synthetic ISO 46 and changing the oil annually or C-Aire ISO 68 and changing the oil semi-annually. See the “Performing an Oil Change” section in this manual. -
Page 12: Pulley/Sheave Alignment And Belt Tension
C-Aire offers two styles of pressure switches on its dry pipe sprinkler compressors. The standard pressure switch is on at 70psi and off at 100psi and is not to be adjusted. The adjustable pressure switch, denoted by an U at the end of the model number, can be adjusted per the instructions below. -
Page 13: Warranty
WARRANTY C-Aire Inc. warrants its compressors to be free from defects in material and workmanship subject to the following provisions: STANDARD WARRANTY DURATION: 12 months from date of purchase. WHAT THE WARRANTY COVERS DURING THE WARRANTY DURATION: All components on the compressor except for those items listed in the section titled “What is excluded from warranty coverage”. -
Page 14: Troubleshooting
TROUBLESHOOTING User not responsible to service any electrical issues. Call C-Aire Compressors or electrician - Compressor will not operate - No electrical power - Turn on power - Loose wire connections - Tighten connection - Pressure switch not making contact... -
Page 15: Installation Checklist
INSTALLATION CHECKLIST In order to validate the warranty on your compressor, C-Aire requires this checklist be completed and kept for reference. INSPECT FOR DAMAGE Carefully inspect the unit for damage that may have occurred during shipping. If damage has occurred, it should be noted on the freight carrier’s bill of lading. - Page 16 AIR COMPRESSOR BASICS Best practices: Tank mounted, oil lubricated, belt driven compressors Tank mounted = reserve supply of air Oil lubricated = greatest durability Belt drive = lower RPM System pressure Air Source On 70psi air pressure- Off 100psi air pressure controlled by air pressure maintenance device Air Pressure Maintenance Device...
