UNDERCARRIAGE LUBRICATION SCHEDULE

10 Hr
Weekly
Tie Rod End (Both Sides)
**
R.H. King Pin - Top & Bottom
**
Steer Cylinder
(Barrel End)
L.H. King Pin - Top & Bottom
OAD0730
82104002
Section 5 - Lubrication & Maintenance
*
**
**
Slip Joint & Middle U-Joint
**
**
Tie Rod at Steer Arm
**
**
Rear U-Joint
Steer Cylinder Rod End
**
5-7
