Long Life
Pressure
Washer
COLD WATER DIRECT DRIVEN
VERTICAL PRESSURE WASHER
LAVADORA VERTICALE DE AQUA FRIA A
PRESION DE TRACCION DIRECTA
INSTRUCCIONES PARA EL USO
PRECAUCIÓN
¡RIESGO DE LESIONES!
LEA ESTE MANUAL ANTES
DE OPERAR!
¡Este manual es una parte importante
de la lavadora a presión y debe
permanecer con esta unidad!
Long Life Vertical LV-Series Operator's Manual
©Copyright 1997, Mi-T-M Corporation
LV-SERIES
OPERATING INSTRUCTIONS
CAUTION
RISK OF INJURY!
READ MANUAL BEFORE
OPERATING!
This manual is an important part of
the pressure washer and must
remain with this unit!
®
by Mi-T-M
Form #37-0473-050197-1C-E/S
1
Advertisement
Table of Contents
Related Manuals for Mi-T-M Long Life Vertical LV Series
Summary of Contents for Mi-T-M Long Life Vertical LV Series
- Page 1 ¡Este manual es una parte importante This manual is an important part of de la lavadora a presión y debe the pressure washer and must permanecer con esta unidad! remain with this unit! Long Life Vertical LV-Series Operator’s Manual ©Copyright 1997, Mi-T-M Corporation Form #37-0473-050197-1C-E/S...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ESPAÑOL 24-43 INTRODUCTION IMPORTANT SAFETY WARNINGS FIRE & VENTILATION PRECAUTIONS SPRAY PRECAUTIONS DETERGENT CLEANING PRECAUTIONS MISCELLANEOUS SAFETY PRECAUTIONS ADJUSTMENT PRECAUTIONS FEATURES DRAWING SAFETY DECALS INSTALLATION & PREPARATION 10-14 ATTIRE SET-UP ENGINE FUEL TANK NOZZLE REVIEW 11-12 NOZZLE CONNECTION WATER SUPPLY UNLOADER HEAT DUMP VALVE... -
Page 3: Introduction
Inspect for signs of obvious or concealed freight damage. If something appears to be damaged, file a claim with the transportation company immediately. Be sure that all damaged parts are replaced and that the mechanical problems are corrected prior to operation of the unit. If you require service, contact Mi-T-M ®... -
Page 4: Important Safety Warnings
IMPORTANT SAFETY WARNINGS FIRE & VENTILATION PRECAUTIONS: 1. Risk of asphyxiation: use this product only in a well ventilated area. This unit was designed for outdoor use only! Never operate this unit in an enclosed area; carbon monoxide produced during use can cause serious injury, illness or death within minutes! (NOTE: If indoor use of this unit is unavoidable;... -
Page 5: Spray Precautions
IMPORTANT SAFETY WARNINGS SPRAY PRECAUTIONS: DANGER RISK OF INJECTION OR SEVERE CUTTING INJURY! KEEP CLEAR OF NOZZLE! DO NOT DIRECT DISCHARGE STREAM AT PERSONS OR PETS! ONLY TRAINED OPERATORS SHOULD USE THIS PRODUCT. WHEN OPERATING THIS UNIT, BASIC PRECAUTIONS SHOULD ALWAYS BE OBSERVED INCLUDING THE FOLLOWING: 1. -
Page 6: Detergent Cleaning Precautions
DETERGENT CLEANING PRECAUTIONS: 1. DO NOT use solvents or highly corrosive detergents or acid type cleaners with ® this pressure washer. Use only MI-T-M detergents. 2. KNOW YOUR DETERGENTS! Be prepared to tell a physician exactly what you are using in the event of an emergency. Read the Material Safety Data Sheet ®... -
Page 7: Adjustment Precautions
ADJUSTMENT PRECAUTIONS: 1. NEVER alter or modify the equipment, be sure any accessory items and system components being used will withstand the pressure developed. Use ONLY genuine Mi-T-M ® parts for repair of your pressure washer. Failure to do so can cause hazardous operating conditions and will void warranty. -
Page 8: Features Drawing
LV FEATURES NOTE: This drawing is referenced through-out the manual. Locations of specific items will be noted by listing the REFERENCE # in parenthesis. Example: Engine (5) OMCV047/012297/DCE FEATURES LISTING 1. Decal-Warning/Caution/Operating 16. Detergent Hose 2. Adjustable Knuckle 17. Detergent Strainer 3. -
Page 9: Safety Decals
SAFETY DECALS & PLACEMENT FOR LV-SERIES. !!!DO NOT REMOVE SAFETY DECALS FROM UNIT UNLESS REPLACING WITH MOST CURRENT SAFETY DECAL!!! REFER TO PAGE 8 FOR PLACEMENT Reference #3 Decal: Caution-Engine Fuel (Part #34-0599) Reference #4 Decal: Warning-Muffler Hot (Part #34-0598) Reference #1 Decal: Warning/Caution/Operating Statements (Part #34-0793) Long Life Vertical LV-Series Operator’s Manual... -
Page 10: Installation & Preparation
Make certain the oil level is in the center of the sight glass before THE EXHAUST FROM THE ENGINE ® CONTAINS CARBON MONOXIDE, each use. If the level appears low, use Mi-T-M pump oil #AW-4085-0016. A POISONOUS, ODORLESS AND DO NOT OVERFILL! INVISIBLE GAS. -
Page 11: Nozzle Review
INSTALLATION & PREPARATION WARNING NOZZLE REVIEW: RISK OF INJECTION CAUSING SEVERE INJURY! 1. Your pressure washer will come with one of the following types of nozzle assemblies: Adjustable, Quick-Connect or High/Low. Review the nozzle NEVER LOOK DIRECTLY AT THE assembly instructions listed below or on the following page which pertain to NOZZLE ORIFICE UNLESS IT IS your unit. -
Page 12: Nozzle Connection
INSTALLATION & PREPARATION NOZZLE REVIEW (CONT'D): CONNECTION OF Q.C. NOZZLES C. QUICK CONNECT NOZZLE: Various nozzles may be quick- connected into the end of the wand to change the spray pattern or use the detergent feature. When using Quick Connects (Q.C.), be certain the connection is securely locked. -
Page 13: Water Supply
NOTE 2 : If there is a high mineral content in your water, it is highly ® recommended that an additional water strainer (Mi-T-M #851-0207) be added to the water inlet to help reduce mineral content. Clean both strainers before starting your pressure washer. -
Page 14: Pre-Start Inspection Procedures
INSTALLATION & PREPARATION PRE-START INSPECTION PROCEDURES: 1. Before starting the unit, perform the following procedures: a. Check the oil level in the pump (12) and engine (5). b. Inspect the water inlet strainer (11). Clean or replace if necessary. See "Water Supply", #2, pg. 13. c. - Page 15 WARNING THE FOLLOWING PAGES CONTAIN OPERATING AND MAINTENANCE INSTRUCTIONS DO NOT ATTEMPT TO OPERATE THIS PRESSURE WASHER UNTIL YOU HAVE READ AND UNDERSTOOD ALL SAFETY PRECAUTIONS AND INSTRUCTIONS LISTED IN THIS MANUAL. INCORRECT OPERATION OF THIS UNIT CAN CAUSE SERIOUS INJURY!! DO NOT ALTER OR MODIFY THIS EQUIPMENT IN ANY MANNER! Long Life Vertical LV-Series Operator’s Manual...
-
Page 16: Operating Instructions
OPERATING INSTRUCTIONS PRIMING THE PUMP: 1. It is essential to prime the pump on initial start-up and each time the water supply is disconnected from the unit after initial use. 2. Lay the high pressure discharge hose (22) out to remove any loops. Water flow will constrict the hose, creating tight loops if the hose is not straight. -
Page 17: Cleaning With Detergents
® pressure washer cleaning industry, it is recommended to use only Mi-T-M detergents with this unit. 3. This unit is equipped with an adjustable detergent knob. Locate the clear vinyl hose which leads to the pump head. -
Page 18: Storage & Maintenance
3 months or 200 hour intervals. If oil appears dirty or milky, changes may be required at a greater frequency. Use Mi-T-M ® pump oil #AW-4085-0016 and fill only to the center of the oil sight glass (15) Approximately 7 oz. -
Page 19: Winterizing
If you must store your unit in an area where the temperature may fall below 32°F, you can protect your unit by following the procedure outlined below. 1. Gather the following items: a. Two 5 gallon containers. b. One gallon of antifreeze. (Mi-T-M ® recommends an environmentally safe antifreeze.) c. -
Page 20: Troubleshooting
Oil appears milky or foamy. Water in oil. Change pump oil. Fill to proper level. Oil leaking from unit. DO NOT USE!!!!! Contact Mi-T-M ® Customer Service. Detergent will not siphon into Detergent strainer is not completely Check, submerge if necessary.
