- Page 1 User manual Indoor/outdoor frame Variabel III Seating aids edition 26/21...
-
Page 3: Foreword
We would like to thank you for your trust extended to us and for purchasing our product. The Indoor/outdoor frame Variabel III distinguishes itself by its quality, security, easy operation and modern design. For optimal use of this aid, we ask you and possible other users to carefully read this operating manual. -
Page 4: Table Of Contents
Table of contents Table of contents Topic Page Foreword ……………………………………… Table of contents ……………………………… Safety instructions …………………………… Warranty and product liability ……………… CE sign and position ………………………… Indications and prophylaxis ………………… 10 Purpose of use ………………………………… 10 Product overview ……………………………… 11 ………………………………... -
Page 5: Safety Instructions
Safety instructions Safety instructions The Indoor/outdoor frame Variabel III is In the event of specific or difficult applica- CE-marked and fulfils the requirements of tions, the user manual represents a guide to the latest directives. It was developed in the most important handling. - Page 6 • The Variabel III may only be operated by and maintenance of this product. This persons who have familiarized themselves operating manual is an indispensable...
- Page 7 • Clean the Indoor/outdoor frame user. Variabel III in accordance with the instructions given in the chapter • Do not use the Variabel III before „cleaning”. checking the wheels of the aid. Page 7/28 (26/21)
- Page 8 Safety instructions • Please ensure before use the product is cleaned according to the cleaning instructions and if indicated also disinfected. • Any serious incidents occurring in connection with the product must be reported to the manufacturer (ATO FORM GmbH) and the competent authority of the country in which the user is resident.
-
Page 9: Warranty And Product Liability
The warranty can only be sustained if the warranty claim and to decide upon whether ATO FORM product is in use in the same to replace or repair the defective product. It country where it was purchased and if is the customer’s responsibility to return the... -
Page 10: Indications And Prophylaxis
Purpose of use The flexible indoor/outdoor frame The aid is delivered via an authorised tech- Variabel III is intended for the living area. nician in compliance with the requirements Usage is however also possible in special of the country where it is being used and in nursery schools, schools and other facilities. -
Page 11: Product Overview
Product overview Product overview 8.1 Basic model Indoor frame 1. Seat adapter 2. Wheels/rolls (Indoorframe/ with lock foot brakes) 3. Seat tilt adjustment 4. Seat height adjustment 5. Push handle (Standard at In-/ outdoor frame/with parking brakes) (optional at Indoor frame/without parking brakes) 6. -
Page 12: Accessories / Options
Product overview Initial operation 8.2 Accessories / options For a complete overview of our extensive range of accessories for the Variabel III see item 11.2 Types and accessories on page Initial operation The reseller is to unpack the unit, ensure... -
Page 13: Assembly And Adjustment
Assembly and adjustment 10 Assembly and adjustment 10.1 Basic model Using the foot brakes Seat height adjustment (pic. 1) (indoor frame) Push foot switch (4) and push seat mount into the desired height (2). Push levers on the rear wheels to lock foot brakes left and right. -
Page 14: Accessories / Options
• Connection module • Recharger cable • Plug-in charger • Hand control • Cable tie You will find the most current overview of our extensive offer of Variabel III accessories and much more useful information on our homepage www.ato-form-com. Page 14/28 (26/21) - Page 15 Assembly and adjustment Preparation • Dismantle gas spring inclusive bowden cable. • Make sure that the components listed in the scope of delivery are completely available and undamaged. • Before assembly of the motor unit, ensure the grey reducing bushes 010/15 are plugged into the fork head on the lifting rod side of the motor.
- Page 16 (4) which is connection module and at the right end put on the base (5) of the Variabel III and of the connection module tied together with slight pressure to the upper side of with the cable for the connection of the the battery is locked into place.
- Page 17 Page 17/28 (26/21)
-
Page 18: Types Of Models
Types and accessories 11 Types and accessories 11.1 Basic model HP-630000-1S Indoor frame incl. seat adapter, black HP-630000-1B Indoor frame incl. seat adapter, blue HP-630300-1S Combi Indoor/Outdoor frame incl. seat adapter, black HP-630300-1B Combi Indoor/Outdoor frame incl. seat adapter, blue HP-630301-1S Combi Indoor/Outdoor frame incl. -
Page 19: Accessories / Options
Height adjustment by electric motor, compl. with control unit, battery and recharger HP-630305 Conversion to 500 N gas spring for height adjustment (in conjunction with the order of a Variabel III) HP-630010-1S Anti-tip stabiliser for indoor frame, black (Notice: 2 pieces are required) -
Page 20: Technical Details
Technical details 12 Technical details Variabel III Indoor In-/Outdoor frame frame Article number: HP-630000-1 HP-630300-1 Overall width: Overall length: Height seat moulding adapter: 18 – 53 23 – 58 Seating shell tilt forwards: degrees Seating shell tilt backward: degrees bis 35... -
Page 21: Cleaning And Disinfection
Cleaning and disinfection 13 Cleaning and disinfection Leftovers, dirt and dust are always to be Disinfection: removed. Moving parts work easier, if you For disinfecting, use household disinfectants apply one drop of oil after cleaning. and consider the following indications: Cleaning the metal parts: The assistant must wear suitable protective The painted and chromed parts of the... -
Page 22: Maintenance And Overhaul
Full brake function Please contact your specialist dealer to carry • No signs of damage or wear out corrective maintenance works for your Variabel III. Frame The device should be checked by the • Metal parts; no signs of damage or wear, manufacturer at the latest after 3 years. - Page 23 Maintenance and overhaul Date Service performed Name Sign Page 23/28 (26/21)
-
Page 24: Operating Life And Re-Use
Operating life and Re-use 15 Operating life and Re-use The Variabel III is made from high quality The product Variabel III was designed so materials and is subject to a continuous it could be reused after the application of quality control in our house. Because of this various measures. -
Page 25: Faults, Repairs, Spare Parts
Faults, repairs, spare parts 16 Faults, repairs, spare parts If your toilet seat lift Variabel III cannot be parts by unauthorized persons, voids any operated? warranties. Please ensure….. In these cases, any product liability granted by the manufacturer (ATO FORM GmbH, •... -
Page 26: Storage
17 Storage Keep this operating manual in a safe place, The current version of these where you or care and maintenance staff instructions for use can be have access to it. found on our homepage in the download area. You can find more informati- on about the product on our homepage at www.ato-form. - Page 27 Disposal of battery operated devices The battery pack must not be disposed of together with normal household waste at the end of its service life. Please observe the legal requirements in your area. Your municipal government and locally based waste disposal companies will be happy to provide you with information in this regard.
- Page 28 Hoists ■ Customized solutions ■ Thank you for your interest in our products. For questions please contact ATO FORM GmbH or your specialist dealer. Your ATO FORM Team ATO FORM GmbH Zur Lauterhecke 34, 63877 Sailauf, Germany Tel. +49 6093 944-0, Fax +49 6093 944-444 E-Mail: info@ato-form.com...
