- Page 1 User manual Modular seat Physio Punkt Seating aids edition 26/21...
-
Page 3: Foreword
We would like to thank you for your trust extended to us and for purchasing our product. The Seating shell Physio Punkt distinguishes itself by its quality, security, easy operation and modern design. For optimal use of this aid, we ask you and possible other users to carefully read this operating manual. -
Page 4: Table Of Contents
Table of contents Table of contents Topic Page Foreword ……………………………………… Table of contents ……………………………… Safety instructions …………………………… Warranty and product liability ……………… CE sign and position ………………………… Indications and prophylaxis ………………… 10 Purpose of use ………………………………… 11 Product overview ……………………………… 12 ………………………………... -
Page 5: Safety Instructions
Safety instructions Safety instructions The Seating shell Physio Punkt is CE-marked which they gained from (for example) and fulfills the requirements of the latest training courses. directives. It was developed in line with In the event of specific or difficult most recent findings. - Page 6 • The operating manual is intended for retailers and users of the Seating shell • The Physio Punkt may only be used by Physio Punkt, (or their carers). It contains persons of a suitable stature and physical aptitude.
- Page 7 • All aspects of spatial influences (uneven, manual. wet and smooth floors, steps or similar) must be taken into consideration by the • Clean the Seating shell Physio Punkt in carer or user. accordance with the instructions given in the chapter „cleaning”.
- Page 8 Safety instructions We constantly develop new aids and improve existing products. We are happy to receive your suggestions of every description. Page 8/32 (26/21)
-
Page 9: Warranty And Product Liability
ATO FORM reserves the right to inspect the The warranty can only be sustained if the product being claimed for and the relevant ATO FORM product is in use in the same documentation before agreeing to the country where it was purchased and if... -
Page 10: Indications And Prophylaxis
Indications and prophylaxis Indications and prophylaxis The indications include the following: The following contraindications should be • Epilepsy mentioned here: • Infantile cerebral palsy and other pareses • Children with serious tonus dysregulation • Paraplegia • Children with intolerances to processed •... -
Page 11: Purpose Of Use
The device must be prescribed by a medical specialist, who has tested beforehand and • Compensation of malpositions and incor- determined if the Physio Punkt is suitable rect postures for the individual therapeutic goal of the • Support of seat stability patient. -
Page 12: Product Overview
Product overview Product overview 8.1 Basic model Seating shell with back adjustment Headrest fitting Armrest fitting Holder for base frame (accessories) Armrests (accessories) Headrest (accessories) Cushions incl. covers (accessories) Page 12/32 (26/21) -
Page 13: Accessories / Options
Upholstery insert (without fig.) Backrest extension (without fig.) only in conjunction with a headrest For a complete overview of our extensive range of accessories for the Physio Punkt see item 11.2 Types and accessories on page 20/21. Page 13/32 (26/21) -
Page 14: Initial Operation
Initial operation Initial operation The reseller is to unpack the unit, ensure that the components and accessories listed in the scope of delivery are all present and undamaged, and give the buyer the initial instructions on use of the aid. Above all the reseller should read through the complete present user manual carefully, in order to then explain it to the customer in detail. -
Page 15: Assembly And Adjustment
Assembly and adjustment 10 Assembly and adjustment 10.1 Basic model Preparation: Unpack the product and remove the pack- ing materials. The device is completely assembled. Ensure that the product is complete and undamaged. Fig. 1 Inclination of the backrest The backrest inclination can be adjusted in the range from -5 degrees to - depen- ding on the model size - between 25 and 36 degrees. -
Page 16: Accessories / Options
Assembly and adjustment 10.2 Accessories / options Adjustment height of the armrests To adjust the height of the arm rests, loo- sen the star grip (Fig. 3 – Pos. Make sure that the arm rests are set at the same height on both sides and that the star grips are tightened firmly again. - Page 17 Assembly and adjustment Assembly and adjustment of the height of the headrest The holder for the headrest is located on the back of the backrest in the upper area. (Fig. 4) Here you can also adjust the height of the headrest.
- Page 18 Assembly and adjustment Mounting for underframe The Physio Punkt seat shell is compatible with various undercarriages. The shell is pushed onto the subframe with the adapter until the spring pin on the un- derside of the seat shell audibly engages.
- Page 19 Assembly and adjustment Mounting the abduction wedge depth adjustment The receptacle for the abduction wedge is located below the seat surface in the front area. Place the abduction wedge with the desired depth in the holder and secure the abduc- tion wedge with the clamping lever.
- Page 20 Fig. 10 For a complete overview of our extensive range of accessories for the Physio Punkt see item 11.2 Types and accessories on page 22. Page 20/32 (26/21)
- Page 21 Page 21/32 (26/21)
-
Page 22: Types And Accessories
Types and accessories 11 Types and accessories 11.1 Basic model SP1-300-1 Seating shell Physio Punkt, Size 3 SP1-400-1 Seating shell Physio Punkt, Size 4 SP1-500-1 Seating shell Physio Punkt, Size 5 11.2 Accessories / options Z50-300-1 Padding, six parts, für Size 3 Z50-400-1 Padding, six parts, für Size 4... - Page 23 Abductor wedge (pommel) with holder and fitting, black imitation leather The most up-to-date overview of our extensive range of accessories for Physio Punkt and their description as well as much more useful information can be found on our homepage www.
-
Page 24: Technical Details
-5° bis 30° -5° bis 25° Product weight 10,9 Maximum user weight 60,0 70,0 80,0 Technical changes reserved! Construction Physio Punkt seat shell is made of alumi- num, adjustable metal parts are chrome- plated, clamping levers are plastic. Page 24/32 (26/21) -
Page 25: Cleaning And Disinfection
Cleaning and disinfection 13 Cleaning and disinfection Leftovers, dirt and dust are always to be Disinfection: removed. Moving parts work easier, if you For disinfecting, use household disinfectants apply one drop of oil after cleaning. and consider the following indications: Cleaning the metal parts: The assistant must wear suitable protective The painted and chromed parts of the... -
Page 26: Maintenance And Overhaul
Please contact your specialist dealer to carry of wear • out corrective maintenance works for your No signs of wear of damage of the safety Physio Punkt. components The device should be checked by the manufacturer at the latest after 3 years. Upolstered padding •... - Page 27 Maintenance and overhaul Date Service performed Name Sign Page 27/32 (26/21)
-
Page 28: Operating Life And Re-Use
Operating life and Re-use 15 Operating life and Re-use The Physio Punkt is made from high quality The product Physio Punkt was designed so materials and is subject to a continuous it could be reused after the application of quality control in our house. Because of this various measures. -
Page 29: Faults, Repairs, Spare Parts
Only original accessories and original spare parts may be used. Non-compliance with these instructions and repairs carried out or modifications made to the Physio Punkt or its parts by unauthorized persons, voids any warranties. In these cases, any product liability granted... -
Page 30: Storage
Storage 17 Storage Keep this operating manual in a safe place, The current version of these where you or care and maintenance staff instructions for use can be have access to it. found on our homepage in the download area. You can find more informati- on about the product on our homepage at www.ato-form. - Page 31 In environmental protection matters: All packaging parts are re-useable. The cardboard packaging is to be recycled as waste paper. We therefore use paper as filler material. Possible used plastic film of the packaging are made out of PE and are therefore low in pollutant and can either be recycled or burnt.
- Page 32 Hoists ■ Customized solutions ■ Thank you for your interest in our products. For questions please contact ATO FORM GmbH or your specialist dealer. Your ATO FORM Team ATO FORM GmbH Zur Lauterhecke 34, 63877 Sailauf, Germany Tel. +49 6093 944-0, Fax +49 6093 944-444 E-Mail: info@ato-form.com...
