- Page 1 User manual Prone, supine and upright stander Size 1, 2, 3 Standing aids edition 24/21...
-
Page 3: Foreword
The Prone, supine and upright stander NOVUM distinguishes itself by its quality, security, easy operation and modern design. For optimal use of this aid, we ask you and possible other users to carefully read this operating manual. -
Page 4: Table Of Contents
Table of contents Table of contents Topic Page Foreword ……………………………………… Table of contents ……………………………… Safety instructions …………………………… Warranty and product liability ……………… CE sign and position ………………………… Indications and prophylaxis ………………… 10 Purpose of use ………………………………… 10 Product overview ……………………………… 11 ………………………………... -
Page 5: Safety Instructions
Safety instructions The prone, supine and upright stander In the event of specific or difficult NOVUM is CE-marked and fulfils the applications, the user manual represents a requirements of the lastest directive. It was guide to the most important handling. - Page 6 • Never leave the user of the aid the correct use and maintenance of this unattended. product. This operating manual is an • The NOVUM may only be operated by indispensable component of the delivery persons who have familiarized themselves and should be stored carefully for further with the standards and rules of the use.
- Page 7 NOVUM in accordance with user. the instructions given in the chapter • Do not use the NOVUM before checking „cleaning”. the wheels of the aid. • Please ensure before use the product is cleaned according to the cleaning •...
- Page 8 Safety instructions We constantly develop new aids and improve existing products. We are happy to receive your suggestions of every description. Page 8/36 (24/21)
-
Page 9: Warranty And Product Liability
ATO FORM reserves the right to inspect the The warranty can only be sustained if the product being claimed for and the relevant ATO FORM product is in use in the same documentation before agreeing to the country where it was purchased and if... -
Page 10: Indications And Prophylaxis
The tilting table/standing frame NOVUM specialist, who has tested beforehand is only intended for indoor use. It offers a and determined if the NOVUM is suitable variety of therapeutic applications such as, for the individual therapeutic goal of the standing frame, prone board, tilting table or patient. -
Page 11: Product Overview
Product overview Product overview 8.1 Basic model Upper support pad Main support pad Tilt control mechanism via electro motor Swivel wheels, with brakes Multi-adjustable discus element Split foot plates CE Label Frame 8.2 Accessories / options Extension Cushion (narrow/high) (accessory) 10. - Page 12 8. Posterior support multi adjustable Not shown: Extra belt Size 1-4, for all → models Heel supports divided → For a complete overview of our extensive range of accessories for the NOVUM see item 11.2 Types and accessories on page Page 12/36 (24/21)
-
Page 13: Initial Operation
Initial operation Initial operation The reseller is to unpack the unit, ensure that the components and accessories listed in the scope of delivery are all present and undamaged, and give the buyer the initial instructions on use of the aid. Above all the reseller should read through the complete present user manual carefully, in order to then explain it to the customer in detail. -
Page 14: Basic Model
Multi adjustable discus element To achieve greatest possible variability, multi-adjustable discus elements were inserted to the tilting table/standing frame NOVUM. Using these, height, depth, tilt and angle are adjustable. Important: When affixing the multi- adjustable discus elements vertically, viewed from the front, the head of the Allen screw must always face to the left. - Page 15 Assembly and adjustment Belts and foot supports The belts are freely guided in the rail and thereby infinitely height adjustable. Height, angle and rotation of the foot supports are set using the multi-adjustable discus element. This permits settings for foot malpositions.
-
Page 16: Accessories / Options
Assembly and adjustment 10.2 Accessories / options Thorax- and pelvis supports Insert the thoracic pads into the lateral guides and then tighten the wing screw, or (alternatively) the clamping lever, to the desired position. The thoracic and pelvic supports can be adjusted by width, height and angle. - Page 17 Assembly and adjustment Extension cushion The extension cushion (B) is inserted into the intended guides of the main support pad (C). The upper support pad (A) is inserted into the extension cushion. Please note when the desired adjustment is reached, tighten the grub screws (D), to avoid unintended disengaging of parts.
- Page 18 Assembly and adjustment Knee supports for application as a supine position board To mount the knee supports, guide the brackets (B) into the multi-adjustable discus element (A). Adjust the height using the multi-adjustable discus element (A). Push the holder of the knee supports (D) onto the brackets (B) and fasten using the Allen screws (C).
- Page 19 Fit the adjustable pelvic support using the same procedure as for the knee pads (see page 18). For a complete overview of our extensive range of accessories for the NOVUM see item 11.2 Types and accessories on page Page 19/36 (24/21)
-
Page 20: Types Of Models
11 Types and accessories 11.1 Basic model NOVUM size 1 NV-1000 Basic model NOVUM, orange NV-1000-E Basic model NOVUM incl. electric motor, orange 11.2 Accessories / options NV-0110 Therapy table for prone and supine position NV-0111 Heel support, divided, pair... - Page 21 11 Types and accessories 11.1 Basic model NOVUM size 2 NV-2000 Basic model NOVUM, blue NV-2000-E Basic model NOVUM incl. electric motor, blue 11.2 Accessories / options NV-0210 Therapy table for prone and supine position NV-0211 Heel support, divided, pair...
- Page 22 11 Types and accessories 11.1 Basic model NOVUM size 3 NV-3000 Basic model NOVUM, grey NV-3000-E Basic model NOVUM incl. electric motor, grey 11.2 Accessories / options NV-0310 Therapy table for prone and supine position NV-0311 Heel support, divided, pair...
- Page 23 Types of models The most up-to-date overview of our extensive range of accessories for NOVUM and their description as well as much more useful information can be found on our homepage www.ato- form.com. For special problems, or if it seems the accessories you require are not demons- trated nor described, please contact us.
-
Page 24: Technical Details
Technical details 12 Technical details Prone supine and upright stander Size 1 Size 2 Size 3 Armpit height 70 – 101 83 – 121 115 – 153 Overall width Overall length Overall height including all accessories Overall height, horizontal Etry height from 3 from 3 from 3... - Page 25 Technical details Construction Operating conditions The prone, supine and upright stander (only electric model) consists of: a powder-coated steel-tube Temperature: +5 °C to +40 °C frame, chrome-plated adjustable metal Relative humidity: 20% to 90% – parts, foam-padded baseplate with noncondensing pleasant and easy-to-clean imitation- leather upholstery, therapy table of Air pressure:...
-
Page 26: Cleaning And Disinfection
Cleaning and disinfection 13 Cleaning and disinfection Leftovers, dirt and dust are always to be Disinfection: removed. Moving parts work easier, if you For disinfecting, use household disinfectants apply one drop of oil after cleaning. and consider the following indications: Cleaning the metal parts: The assistant must wear suitable protective The painted and chromed parts of the... - Page 27 Page 27/36 (24/21)
-
Page 28: Maintenance And Overhaul
No signs of damage or wear Please contact your specialist dealer to carry out corrective maintenance works for your Frame NOVUM. • Metal parts; no signs of damage or wear, The device should be checked by the especially for adustable parts manufacturer at the latest after 5 years. - Page 29 Maintenance and overhaul Date Service performed Name Sign Page 29/36 (24/21)
-
Page 30: Operating Life And Re-Use
Maintenance and overhaul Operating life and Re-use 15 Operating life and Re-use The NOVUM is made from high quality The product NOVUM was designed so it materials and is subject to a continuous could be reused after the application of quality control in our house. -
Page 31: Faults, Repairs, Spare Parts
Faults, Repairs, Spare parts 16 Faults, repairs, spare parts If your toilet seat lift NOVUM cannot be Spare parts operated? Only original accessories and original spare Please ensure….. parts may be used. Non-compliance with these instructions and repairs carried out or •... -
Page 32: Storage
Storage 17 Storage Keep this operating manual in a safe place, The current version of these where you or care and maintenance staff instructions for use can be have access to it. found on our homepage in the download area. You can find more informati- on about the product on our homepage at www.ato-form. - Page 35 Disposal of battery operated devices The battery pack must not be disposed of together with normal household waste at the end of its service life. Please observe the legal requirements in your area. Your municipal government and locally based waste disposal companies will be happy to provide you with information in this regard.
- Page 36 Hoists ■ Customized solutions ■ Thank you for your interest in our products. For questions please contact ATO FORM GmbH or your specialist dealer. Your ATO FORM Team ATO FORM GmbH Zur Lauterhecke 34, 63877 Sailauf, Germany Tel. +49 6093 944-0, Fax +49 6093 944-444 E-Mail: info@ato-form.com...
