  • Page 1 User manual Shower and toilet chair Seating aids edition 24/21...

  • Page 3: Foreword

    We would like to thank you for your trust extended to us and for purchasing our product. The shower and toilet chair TS distinguishes itself by its quality, security, easy operation and modern design. For optimal use of this aid, we ask you and possible other users to carefully read this operating manual.

  • Page 4: Table Of Contents

    Table of contents Table of contents Topic Page Foreword ……………………………………… Table of contents ……………………………… Safety instructions …………………………… Warranty and product liability ……………… Position of CE label …………………………… Indications and prophylaxis ………………… 10 Purpose of use ………………………………… 11 Product overview ……………………………… 12 ………………………………...

  • Page 5: Safety Instructions

    Safety instructions Safety instructions The shower and toilet chair TS is CE-marked In the event of specific or difficult and fulfils the requirements of the latest applications, the user manual represents a directives. It was developed in line with guide to the most important handling.
  • Page 6 • Use of the rehabilitation aid and its accessories, must be administered under • The TS may only be used by persons of a medical supervision. suitable stature and physical aptitude. Page 6/32 (24/21)
  • Page 7 • Do not use the TS before checking the wheels of the aid. • Adjust settings only in the unloaded condition.
  • Page 8 Safety instructions • Clean the shower and toilet chair TS in accordance with the instructions given in the chapter „cleaning”. • Please ensure before use the product is cleaned according to the cleaning instructions and if indicated also disinfected. • Any serious incidents occurring in connec-...

  • Page 9: Warranty And Product Liability

    ATO FORM reserves the right to inspect the The warranty can only be sustained if the product being claimed for and the relevant ATO FORM product is in use in the same documentation before agreeing to the country where it was purchased and if...

  • Page 10: Indications And Prophylaxis

    Contraindications must weigh the risks versus the expec- As a contra-indication, it should be men- ted benefits. tioned that the TS cannot be used in cases of complete immobility. Other contra-indications are not known. Page 10/32 (24/21)

  • Page 11: Purpose Of Use

    The TS may only be used for the appli- physically disabled child, young adolescent cations stated above. The manufacturer or young people. The TS can be used in the will not accept any liability for any other domestic area as well as in care homes or applications and damage of any kind arising similar institutions.

  • Page 12: Product Overview

    Product overview Product overview 8.1 Basic model 1. Seat shell 2. toilet bucket 3. Frame 4. Swivel wheels, lockable 8.2 Accessories / options 5. Parallelogram footrest 6. Headrest Page 12/32 (24/21)
  • Page 13 6. H-Belt 7. Chest and pelvic belt Not shown: – Push handle – Foot straps For a complete overview of our extensive range of accessories for the TS see item 11.2 Types and accessories on page 19. Page 13/32 (25/21)

  • Page 14: Initial Operation

    Initial operation Initial operation The reseller is to unpack the unit, ensure that the components and accessories listed in the scope of delivery are all present and undamaged, and give the buyer the initial instructions on use of the aid. Above all the reseller should read through the complete present user manual carefully, in order to then explain it to the customer in detail.

  • Page 15: Assembly And Adjustment

    Assembly and adjustment 10 Assembly and adjustment 10.1 Basic model Preparation: Adjusting the seat height Unpack the product and remove the pack- The height adjustment of the toilet seat ing materials. shell is carried out on the legs. Three legs have a hole grid, the fourth leg can be ad- The device is completely assembled.
  • Page 16 Assembly and adjustment Adjusting the seat tilt The seat shell can be tilted steplessly from +15° to -30°. To adjust the tilt, loosen lever A, set the tilt desired and tighten the lever again. Page 16/32 (24/21)

  • Page 17: Accessories / Options

    Assembly and adjustment 10.2 Accessories / options Adjusting the footrest The height of the footrest can be set with the C screw. With the A screw, the depth of the footrest is adjusted. You can adjust the knee angles with the B screw. Page 17/32 (25/21)
  • Page 18 Assembly and adjustment Fitting the support table The table is fitted as follows: first, fit the holder A on the base frame. Then mount the spacer with the tilt adjustment B. Finally, push the table into the insert of the spacer. Please ensure the maximum extraction length MAX.
  • Page 19 Lateral or length MAX. central adjustment of the head rest cushion via screw A. For a complete overview of our extensive range of accessories for the TS see item 11.2 Types and accessories on page 19. Page 19/32 (25/21)

  • Page 20: Types Of Models

    Types and accessories 11 Types and accessories 11.1 Basic model Item No. Size Description TS-400 shower and toilet chair TS-400 TS-500 shower and toilet chair TS-500 TS-600 shower and toilet chair TS-600 TS-700 shower and toilet chair TS-700 11.2 Accessories / options Item No.
  • Page 21 Padded upholstery for TS-600 mint TS-127-4 Padded upholstery for TS-700 mint The most up-to-date overview of our extensive range of accessories for TS and their description as well as much more useful information can be found on our homepage www.ato-form.com.

  • Page 22: Technical Details

    Technical details 12 Technical details Article number TS-400 TS-500 TS-600 TS-700 Overall width Seat width in front Seat width in back Seat depth Length of backrest without headrest Backrest width above Backrest width below Seat height min. Seat height max.

  • Page 23: Cleaning And Disinfection

    Cleaning and disinfection 13 Cleaning and disinfection Leftovers, dirt and dust are always to be Disinfection: removed. Moving parts work easier, if you For disinfecting, use household disinfectants apply one drop of oil after cleaning. and consider the following indications: Cleaning the metal parts: The assistant must wear suitable protective The painted and chromed parts of the...

  • Page 24: Maintenance And Overhaul

    Maintenance and overhaul 14 Maintenance and overhaul For the protection of the warranty and Maintenance Checklist safety, it is especially important that the Castors • shower and toilet chair is serviced regularly No damage or wear once a year from the date of purchase. •...
  • Page 25 Maintenance and overhaul Date Service performed Name Sign Page 25/32 (25/21)

  • Page 26: Operating Life And Re-Use

    Operating life and Re-use 15 Operating life and Re-use The TS is made from high quality materials The product TS was designed so it could and is subject to a continuous quality con- be reused after the application of various trol in our house.

  • Page 27: Faults, Repairs, Spare Parts

    Only original accessories and original spare parts may be used. Non-compliance with these instructions and repairs carried out or modifications made to the TS or its parts by unauthorized persons, voids any warranties. In these cases, any product liability granted...
  • Page 28 Page 28/32 (24/21)
  • Page 29 Page 29/32 (25/21)

  • Page 30: Storage

    Storage 17 Storage Keep this operating manual in a safe place, The current version of these where you or care and maintenance staff instructions for use can be have access to it. found on our homepage in the download area. You can find more informati- on about the product on our homepage at www.ato-form.
  • Page 31 In environmental protection matters: All packaging parts are re-useable. The cardboard packaging is to be recycled as waste paper. We therefore use paper as filler material. Possible used plastic film of the packaging are made out of PE and are therefore low in pollutant and can either be recycled or burnt.
  • Page 32 Hoists ■ Customized solutions ■ Thank you for your interest in our products. For questions please contact ATO FORM GmbH or your specialist dealer. Your ATO FORM Team ATO FORM GmbH Zur Lauterhecke 34, 63877 Sailauf, Germany Tel. +49 6093 944-0, Fax +49 6093 944-444 E-Mail: info@ato-form.com...
