PRODUCT NO.
BASE MODEL NO.
FGF366AUA
FGF366A
FGF366AWA
FGF366A
SERVICE DATA SHEET - # 316259139
WIRING DIAGRAM - #316255205
OWNER'S GUIDE - # 316257503
INSTALLATION INSTRUCTIONS -# 316259304
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
This Publication Supercedes
Publication # 5995354254
COLOR
MARKET
black/bisque
North America
black/white
North America
Publication No.
5995380630
021101
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
GAS
RANGE
Model No.
FGF366A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FGF366A
Summary of Contents for Frigidaire FGF366A
- Page 1 PRODUCT NO. BASE MODEL NO. FGF366AUA FGF366A FGF366AWA FGF366A SERVICE DATA SHEET - # 316259139 WIRING DIAGRAM - #316255205 OWNER’S GUIDE - # 316257503 INSTALLATION INSTRUCTIONS -# 316259304 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 This Publication Supercedes...
- Page 2 Publication No. FGF366A 5995380630 BACKGUARD 11/02...
- Page 3 A = FGF366A (FGF366AWA) B = FGF366A (FGF366AUA) POS. NO 20 # 24 # # = Fast-moving Parts * = Non-Illustrated Parts FGF366A BACKGUARD PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316248900 Spacer,shield ,rear wall 316051600 Shield,backguard ,inner 316235100 Shield,top ,inner...
- Page 4 Publication No. 5995380630 11/02 FGF366A BURNER...
- Page 5 A = FGF366A (FGF366AWA) B = FGF366A (FGF366AUA) POS. NO 2C # 10 # 10C# 11 # 11B# 11C# 13 # 14 # 16 # 17 # 18 # 19 # 22 # 23 # 24 # 26 # # = Fast-moving Parts...
- Page 6 Publication No. FGF366A 5995380630 BODY 11/02...
- Page 7 A = FGF366A (FGF366AWA) B = FGF366A (FGF366AUA) POS. NO 12 # 18 # 37 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF366A BODY PART NO DESCRIPTION 316029416 Panel,main back 3131314 Shield,oven top...
- Page 8 Publication No. FGF366A 5995380630 TOP/DRAWER 11/02...
- Page 9 A = FGF366A (FGF366AWA) B = FGF366A (FGF366AUA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF366A TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231400 Liner,drawer 316231205 Panel,drawer ,white 316231209 Panel,drawer ,bisque 3051163 Glide,drawer ,rear 316202332 Main Top,white 316202334...
- Page 10 Publication No. FGF366A 5995380630 DOOR 11/02...
- Page 11 A = FGF366A (FGF366AWA) B = FGF366A (FGF366AUA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF366A DOOR PART NO DESCRIPTION 5303935191 Trim kit-door,3 sided ,black ,w/tape and foil 5303935200 Glass,door kit ,black ,outer ,w/foil tape 316237100 Glass,oven door ,clear ,heat barrier...
-
Page 12: Wiring Schematic
Publication No. FGF366A 5995380630 WIRING SCHEMATIC 11/02... -
Page 13: Wiring Diagram
FGF366A Publication No. 5995380630 WIRING DIAGRAM # = Fast-moving Parts 11/02 * = Non-Illustrated Parts...
