Frigidaire FGF366D Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Ranges
  5. FGF366D
  6. Factory parts catalog
Frigidaire FGF366D Factory Parts Catalog

Frigidaire FGF366D Factory Parts Catalog

30-inch freestanding gas range
Hide thumbs

Advertisement

Quick Links

Download this manual
FGF366D.eps T24G0011.eps T24B0008.eps T24V0025.eps T24T0020.eps T24D0005.eps
316417800d.eps 316417800s.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FGF366DBA FGF366DQA FGF366DSA
Series
30" f/s gas
Color
black
Market
North America North America North America
Wiring Diagram
316417800
Owner's Guide
316417100
Installation Instructions 316259336
Service Data Sheet
316417605
Publication No.
5995420113
04/10/27
(EN/SERVICE/ECL)
369
30" f/s gas
30" f/s gas
bisque
white
316417800
316417800
316417100
316417100
316259336
316259336
316417605
316417605
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGF366D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
