PRODUCT NO.
BASE MODEL NO.
FGF366CBB
FGF366C
FGF366CQB
FGF366C
FGF366CSB
FGF366C
SERVICE DATA SHEET - # 316218504
WIRING DIAGRAM - #316255216
OWNER'S GUIDE - # 316257503
INSTALLATION INSTRUCTIONS -# 316259315
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
30" f/s gas
black
30" f/s gas
bisque
30" f/s gas
white
Publication No.
5995389607
030429
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
MARKET
North America
North America
North America
GAS
RANGE
Model No.
FGF366C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FGF366C
Summary of Contents for Frigidaire FGF366C
- Page 1 PRODUCT NO. BASE MODEL NO. FGF366CBB FGF366C FGF366CQB FGF366C FGF366CSB FGF366C SERVICE DATA SHEET - # 316218504 WIRING DIAGRAM - #316255216 OWNER’S GUIDE - # 316257503 INSTALLATION INSTRUCTIONS -# 316259315 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917...
- Page 2 Publication No. FGF366C 5995389607 BACKGUARD 04/03...
- Page 3 A = FGF366C (FGF366CSB) B = FGF366C (FGF366CBB) C = FGF366C (FGF366CQB) POS. NO 20 # 24 # # = Fast-moving Parts * = Non-Illustrated Parts FGF366C BACKGUARD PART NO DESCRIPTION 316239900 A B C Shield,backguard ,rear wall 316051600 A B C...
- Page 4 Publication No. 5995389607 04/03 FGF366C BURNER...
- Page 5 A = FGF366C (FGF366CSB) B = FGF366C (FGF366CBB) C = FGF366C (FGF366CQB) POS. NO 2C # 10 # 10C# 11 # 11B# 11C# 13 # 14 # 16 # 17 # 18 # 19 # 22 # 23 # 24 #...
- Page 6 Publication No. FGF366C 5995389607 BODY 04/03...
- Page 7 A = FGF366C (FGF366CSB) B = FGF366C (FGF366CBB) C = FGF366C (FGF366CQB) POS. NO 12 # 18 # 37 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF366C BODY PART NO DESCRIPTION 316029416 A B C...
- Page 8 Publication No. FGF366C 5995389607 TOP/DRAWER 04/03...
- Page 9 A = FGF366C (FGF366CSB) B = FGF366C (FGF366CBB) C = FGF366C (FGF366CQB) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF366C TOP/DRAWER PART NO DESCRIPTION 316011503 A B C Drawer 316231400 A B C Liner,drawer 316231205 A - -...
- Page 10 Publication No. FGF366C 5995389607 DOOR 04/03...
- Page 11 A = FGF366C (FGF366CSB) B = FGF366C (FGF366CBB) C = FGF366C (FGF366CQB) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF366C DOOR PART NO DESCRIPTION 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil 5303935191 - B -...
-
Page 12: Wiring Schematic
Publication No. FGF366C 5995389607 WIRING SCHEMATIC 04/03... -
Page 13: Wiring Diagram
FGF366C Publication No. 5995389607 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
