PRODUCT NO.
BASE MODEL NO.
FGF363MXASA
FGF363MXA
WIRING DIAGRAM - # 316255216
SERVICE DATA SHEET - # 316218504
OWNER'S GUIDE - # 316257503
INSTALLATION INSTRUCTIONS -# 316259315
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
30" f/s gas
white
Publication No.
5995390423
030512
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
MARKET
North America
GAS
RANGE
Model No.
FGF363MXA
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FGF363MXA
Summary of Contents for Frigidaire FGF363MXA
- Page 1 PRODUCT NO. BASE MODEL NO. FGF363MXASA FGF363MXA WIRING DIAGRAM - # 316255216 SERVICE DATA SHEET - # 316218504 OWNER’S GUIDE - # 316257503 INSTALLATION INSTRUCTIONS -# 316259315 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 SERIES COLOR 30" f/s gas...
- Page 2 Publication No. FGF363MXASA 5995390423 BACKGUARD 05/03...
- Page 3 POS. NO 20 # # = Fast-moving Parts * = Non-Illustrated Parts FGF363MXASA BACKGUARD PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316051600 Shield,backguard ,inner 316235100 Shield,top ,inner 316220214 Support,backguard ,white ,RH 316220215 Support,backguard ,white ,LH 316232647 Panel,backguard ,white 316207500 Clock/Timer,electronic ,ES300 316220804 Overlay,clock ,white ,ES300 316220900...
- Page 4 Publication No. FGF363MXASA 5995390423 BURNER 05/03...
- Page 5 POS. NO 2C # 10C# 11 # 11C# 13 # 14 # 16 # 17 # 18 # 19 # 22 # 23 # 24 # 26 # # = Fast-moving Parts * = Non-Illustrated Parts FGF363MXASA BURNER PART NO DESCRIPTION 316204000 Pipe,manifold...
- Page 6 Publication No. FGF363MXASA 5995390423 BODY 05/03...
- Page 7 POS. NO 12 # 18 # 37 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF363MXASA BODY PART NO DESCRIPTION 316029416 Panel,main back 3131314 Shield,oven top 316216402 Panel,bodyside ,white ,RH 316216403 Panel,bodyside ,white ,LH 316021131 Screw,bodyside ,8-18 X 11/16 ,white 316201402...
- Page 8 Publication No. FGF363MXASA 5995390423 TOP/DRAWER 05/03...
- Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF363MXASA TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231400 Liner,drawer 316231205 Panel,drawer ,white 3051163 Glide,drawer ,rear 316202317 Main Top,white 316202401 Grate,gray 316213501 Cap,9.5K burner ,gray 316099500 Pin,guide ,(2) 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome 316021109 Screw,8-18 x 0.5 ,chrome 316021110...
- Page 10 Publication No. FGF363MXASA 5995390423 DOOR 05/03...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF363MXASA DOOR PART NO DESCRIPTION 5303935192 Trim kit-door,3 sided ,white ,w/tape and foil 5303935201 Glass,door kit ,white ,outer ,w/foil tape 316237000 Glass,oven door ,air wash 316222707 Shield,wool ,oven door 316236700 Insulation,oven door 316237100 Glass,oven door ,clear ,heat barrier...
-
Page 12: Wiring Schematic
Publication No. FGF363MXASA 5995390423 WIRING SCHEMATIC 05/03... -
Page 13: Wiring Diagram
FGF363MXASA Publication No. 5995390423 WIRING DIAGRAM # = Fast-moving Parts 05/03 * = Non-Illustrated Parts...
