LITHIUM
CHARGING PROGRAMS
Settings are made by pressing the MODE-button. After about two seconds the charger
activates the selected program. The selected program will be restarted next time the
charger is connected.
The table explains the different Charging Programs:
Program Explanation
Lithium program 13.8V/15A
LITHIUM
Only for Lithium batteries
(Li-FePO , Li-Fe, Li-iron, LFP).
4
Supply program 13.6V/15A
Use as a 12V power supply or use for float maintenance charging when
SUPPLY
100% capacity of the battery is required. The Supply program activates
the Float step without time or voltage limitation.
on the battery charger is disabled during the SUPPLY program.
BATTERIES WITH "UNDER VOLTAGE PROTECTION"
Some Lithium-ion batteries have an on-board UVP (under voltage protection) that
disconnects the battery to avoid it becoming too deeply discharged. This prohibits the
charger from detecting that there's a battery connected. To bypass this, the battery
charger needs to open the UVP. There are two options available to "wake up" the
battery - automatic and manual.
During the automatic "wake up" period the LED
is started and LED is lit with a steady light. Automatic "wake up" will be active for
maximum 5 minutes.
If the charger is in Standby mode after 10 minutes (
automatic wake up did not succeed. Try the manual wake up.
To use the manual "wake up", press the Mode button for approximately 10 seconds
to bypass the UVP. During the "wake up" period the LED
program is started and the LED is lit with a steady light. If the manual wake up is
unsuccessful the power LED will start to flash after latest 10 minutes. Disconnect any
parallel loads from the battery and try again. If the charging does not start after that, the
battery may need to be replaced.
6 • EN
Temp range
0°C–+40°C
(32ºF–104ºF)
Read the battery manual
for charging outside this
temperature range.
The spark protection
will flash until the charge program
power led is flashing) the
will flash until the charge
MODE
POWER LAMP
If the power lamp is lit with a:
1. STEADY LIGHT
The mains cable is connected to the wall socket.
2. FLASHING LIGHT:
NORMAL LITHIUM SUPPLY
The charger has entered the energy save mode. This happens if the
charger isn´t connected to the battery within 2 minutes.
ERROR LAMP
If the error lamp is lit, check the following:
1. Is the chargers red clamp connected to the battery's
positive pole? Connect the charger according to the
vehicles manual.
2. Is the charger connected to a 12V battery?
3. Are the terminals short circuited?
4. Has charging been interrupted in
Restart the charger by pressing the MODE-button. If charging is still
being interrupted, the battery...
MODE
...can not accept charge or paralell loads may be connected to
the battery. Remove the paralell loads and restart the charging by
pressing the MODE-button.
...restart the charger maximum 3 times. If the charger doesn´t
continue to Bulk after that, the battery may need to be replaced.
...can not keep charge and may need to be replaced.
NORMAL LITHIUM SUPPLY
RECOND
or ?
RECOND
