Designing, Manufacturing and Supplying WB Series Electric Isolated Sensor and Digital
Electrical Transducer since 1989
USER MANUAL
WBV332S01 DC Voltage Transducer
www.wb-my.com
wblch@wbdz.cn
Technical Service: 86 816 2278271
Quality Complain: 86 816 2278273
Fax Line: 86 816 2281934
ISO9001 ISO14000 GB/T2800 CE
Certified
Quality Warranty
Any quality problem found in WB series products, we offer
Three years free charge of repair the products, and six months guaranteed free charge of change and return the
products.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mianyang Weibo Electronic WBV332S01
Summary of Contents for Mianyang Weibo Electronic WBV332S01
- Page 1 Designing, Manufacturing and Supplying WB Series Electric Isolated Sensor and Digital Electrical Transducer since 1989 USER MANUAL WBV332S01 DC Voltage Transducer www.wb-my.com wblch@wbdz.cn Technical Service: 86 816 2278271 Quality Complain: 86 816 2278273 Fax Line: 86 816 2281934 ISO9001 ISO14000 GB/T2800 CE...
- Page 2 WBV332S01 DC Voltage Transducer Safety claim The information in the safety claim of the equipment documentation is intended to ensure that equipment is properly installed in order to maintain it in a condition. It is assumed that everyone who would be associated with the equipment should be familiar with the contents of that safety section, or this safety guide.
- Page 3 EN61000-6-4:2001 Product Description and Application WBV332S01 converts input DC pure or pulsating voltage into a load independent output signal DC voltage 0-5V or 0~10V. It has adopted modulation-demodulation isolation principle and average measurement method for real time measurement of DC voltage from electric net.
- Page 4 13. Drifting by Temperature: (0℃～50℃)100×10-6/℃， 14. Ambient Temperature: -10℃～+50℃ 15. Mounting : DIN Rail 35mm Mounting or screw moutning Mianyang Weibo Electronic Co.,Ltd No.7 Road 2 of Xianren Road Youxian District Mianyang City P.R. China Tel: 86-816-2971265 Fax: 86-816-2281934 www.wb-my.com...
- Page 5 ＜10mV, and multiple converters can share with one set auxiliary power together. When measuring dc voltage exceeds 500 volts, the circuit needs adding a resistor to divide the input dc voltage. The resistor is provided by Mianyang weibo Electronic, and only for each type of transducers special use only.
- Page 6 For product intensive installation, the space between Mianyang Weibo Electronic Co.,Ltd No.7 Road 2 of Xianren Road Youxian District Mianyang City P.R. China Tel: 86-816-2971265 Fax: 86-816-2281934 www.wb-my.com...
- Page 7 This product can’t be used to measure the pulse DC voltage signal, otherwise there will be more errors or no output. Mianyang Weibo Electronic Co.,Ltd No.7 Road 2 of Xianren Road Youxian District Mianyang City P.R. China Tel: 86-816-2971265 Fax: 86-816-2281934 www.wb-my.com...
