Designing, Manufacturing and Supplying WB Series Electric Isolated Sensor and Digital
Electrical Transducer since 1989
USER MANUAL
WBV415S01 AC voltage transducer （TRUE RMS）
www.wb-my.com
wblch@wbdz.cn
Technical Service: 86 816 2778271
Quality Complain: 86 816 2278273
Fax Line: 86 816 2281934
ISO9001 ISO14000 ISO18000
Certified
Quality Warranty
Any quality problem found in WB series products, we offer
Three years free charge of repair the products, and six months guaranteed free charge of change and return the
products.
Advertisement
Table of Contents
Related Manuals for Mianyang Weibo Electronic WBV415S01
Summary of Contents for Mianyang Weibo Electronic WBV415S01
- Page 1 Designing, Manufacturing and Supplying WB Series Electric Isolated Sensor and Digital Electrical Transducer since 1989 USER MANUAL WBV415S01 AC voltage transducer （TRUE RMS） www.wb-my.com wblch@wbdz.cn Technical Service: 86 816 2778271 Quality Complain: 86 816 2278273 Fax Line: 86 816 2281934...
- Page 2 WBV415S01 AC Voltage Transducer （TRUE RMS） Safety claim The information in the safety claim of the equipment documentation is intended to ensure that equipment is properly installed in order to maintain it in a condition. It is assumed that everyone who would be associated with the equipment should be familiar with the contents of that safety section, or this safety guide.
- Page 3 Product Description and Application WBV415S01 converts AC input voltage into a load independent output signal RMS 0~5V. It has adopted electromagnetic isolation principle and RSM measurement method for real time measurement of AC voltage (in any wave form) from electric net or electric circuit.
- Page 4 Product Terminal Identification Drawing DC voltage output (Uz ) Power supply and output ground (GND) AC voltage input (U+) Power supply positive (+E) AC voltage input (U-) Non Identified Terminals Cannot Used Key Technical Data: 1. Input: AC 0~10V; 0-50V; 0-100V; 0-250V;0-300V; 0-500V; 2.
- Page 5 Instruction of Installation and Use 1. The product has adopted structure compliance with EN50022; suitable for DIN rail mounting NS35/7.5, NS35/15. Installation steps are as following (please reference to dimensional drawing): Step 1: Immobilize one side of product‘s mounting trough to the DIN mounting rail; Step 2: Pull out the spring clasp;...
- Page 6 (5) Using output monitoring meter V2 to measuring the output voltage U0 of the transducer, the basic introduced errorγof the transducer should be calculated γ= (Uo－Uz)/5V×100 Repeating (4) (5), if calculated absolute value is less than the given accuracy value of the transducer; it shows the transducer’s accurate grade is qualified. Caution: Pay attention to the auxiliary power information, especially the auxiliary power grade, and polarity, other wise will damage the product.
