- Page 1 LTE Smart Dashboard Camera UCM3300 Series UCM3310S (Sprint Version) UCM3300U (Universal Version) OBD-II Compatibility ● Verison 1.01 Alleswolke Inc. all right reserved...
-
Page 2: Table Of Contents
Index Disclaimer……………………………………………………………………………………………..…3 Acknowledgement………………………………………………………………………………..…….4 OBD-II feature introduction……………………………………………………………………..……..5 Device Introduction………………………………………………………………………………….….6 Picture Overview…………………………………………………………………………………6 Models and Specs…….…………………………………………………………………………7 Adapters and Compatibility……………………………………………………………………………..9 FAQ for OBD-II and adapters…………………………………………………………………………..12 Contact Information……………………………………………………………………………………..14... -
Page 3: Disclaimer
Alleswolke Inc. exerts our utmost to ensure the accuracy and integrity of contents within this user manual. We are sincerely thankful should you discover and notify any errors or misses to us. -
Page 4: Acknowledgement
• If there is any other problems during the use of device, please read the Frequently Asked Questions at the later sections of this user manual, or contact Alleswolke Inc. for additional consultation. ... -
Page 5: Obd-Ii Feature Introduction
The OBD-II or equivalent On-Board Diagnostics ports provide uninterruptible 12V (or 24V for heavy trucks and pickups) power supply. With capability to read vehicle data from vehicle’s Electronic Control Unit or ECU. The protocols utilized by OBD-II ports that are fully supported by Alleswolke are: ISO 9141-2 ISO 14230... -
Page 6: Device Introduction
Device Instruction 1. Picture Overview 9V-36V OBD-II cable for heavy trucks and commercial vehicles + regular light vehicles: 9V-16V OBD-II cable for regular light vehicles only:... -
Page 7: Models And Specs
Models and Specs Output Micro USB Specs The output micro USB is Different from normal micro USB port that provide 5V, it provides 9-36V instead, and have different wire assignment. Warning: it is strongly prohibited to plug the attached power and data cables into any other electronic devices not designated to use with, such as cell phones. - Page 8 3. 9V-36V OBD-II cable for heavy trucks and commercial vehicles + regular light vehicles: OBD-II port Circuit Box Micro USB port Part Number AW-OBDII-0936 Inout (OBD-II) 9V ~ 36V Output (micro USB) 12V or 24V depends on battery Current Running<2A, (or 25mA in sleep mode) Cable Length 2M or 6.5ft Features...
-
Page 9: Adapters And Compatibility
2. SAE J1939 (9-Pin - OBD II) Some heavy trucks and pickups and other heavy duty and commercial vehicles may use 9-pin ports or SAE J1939 ports. Alleswolke supports all its features that have described in our datasheet with the correct adapter. - Page 10 3. SAE J1708 (6 Pin OBD) Some heavy Trucks and Pickups and other heavy duty vehicles and commercial vehicle may use 6- pin port or SAE J1708 port, with correct adapter, Alleswolke supports all its features that have described in our datasheet. J1708 Port Diagram:...
- Page 11 All-in-one Adapter: For information about the adapters listed above, please contact us. ...
-
Page 12: Faq For Obd-Ii And Adapters
FAQ: Power Supply/OBD-II Q1: Can the system use in any vehicles including regular cars and heavy duty commercial trucks? A: Yes, the hub supports the power input range variable from 9V to 36V, but please confirm that the OBD-II power supply model is suited in your vehicles. If you are driving heavy pickups, trucks, or other commercial vehicles equipped with 24V-28V battery system, please check the OBD-II power supply model as the voltage range needs to be with 9V and 36V, which is printed on our OBD-II cable. - Page 13 (4). If possible, please try to install the system (you may install OBD-II cable and Hub only) in another vehicle. If the system works properly in other vehicle, check the circuit and fuse box of your own vehicle for any damages, especially if the OBD-II fuse is intact and working properly. Power Supply Issue (Cont.) Q3: If my vehicle only has 6-pin or 9-pin power On-Board Diagnostics ports, can I use the system?
-
Page 14: Contact Information
Contact Information For contact our support team, please visit https://www.alleswolke.com/customersupport.html Or send us an email to support@alleswolke.com, you will receive response within next business day. Please include the product SN (serial number) and your question in the email.
