- Page 1 LTE Smart Dashboard Camera UCM3300 series UCM3310S (Sprint Version) UCM3300U (Universal Version) User Manual ● Version 1.05 Alleswolke Inc. All rights reserved...
-
Page 2: Table Of Contents
Menu Disclaimer……………………………………………………………………………………………..…3 Acknowledgement………………………………………………………………………………..…….4 What’s included……………………………………………………………………………….…………5 Device Instruction ……………………………………………………………………………….……..6 Hardware Specs……………………………………………………………………………….………..7 LED Indicators……………………………………………………………………………….…………..8 Installation Instructions…………………………………………………………………………………9 ● Installation position………………………………………………………………………………9 ● Installation procedure…………………………………………………………………………..9 Operating instructions……………………………………………………………………………….…13 ● Download and Install Smartphone Application ……………………………….………….…13 ● Account Registration…………………………………..……………………………….…….…14 ● Add a camera by scanning the QR-code……………………..…………………….….….…15 ●... -
Page 3: Disclaimer
FCC ID and Document ……………………………………………….…………..…………………….38 Disclaimer Without the written authorization by Alleswolke Inc., any content that is provided in this user manual is not permitted to be published, spread, transcribed or stored in any searchable system with indices or journals, or translated into any other languages, to or via any form of media. -
Page 4: Acknowledgement
• If there is any other problems during the use of device, please read the Frequently Asked Questions at the later sections of this user manual, or contact Alleswolke Inc. for additional consultation. ... -
Page 5: What's Included
Warning: it is strongly prohibited to plug the attached power and data cables into any other electronic devices not designated to use with, such as cell phones. Alleswolke does not assume any liability of damages cased by the contradictory use against this instruction. -
Page 6: Device Instruction
Device Instruction ● Smart Dashboard Camera ● Smart LTE Hub... -
Page 7: Hardware Specs
Hardware Specification ications Product Model UCM3310 Dimensions CAM：74×43×45mm HUB：92×92×15mm LTE Module Sierra Wireless WP7504 (UCM3310) or other Main Chip Qualcomm Atheros AR9x31 Lens 6-layers glass and IR-Cut with IR LED night visions Aperture F1.9 Viewing Angle Diagonal 162°/ Horizontal129° / 360° Motorized Pan CMOS APTINA AR0230 CMOS 1/2.7 Focal Length... -
Page 8: Led Indicators
LED Indicators The LED indicators include the Power Indicator on the top of device and the series of Status Indicators on the bottom of device, with their status and colors representing the Status of Device. Device Type Color Status Device Status Green Device Starting Blue... -
Page 9: Installation Instructions
Installation Instructions ● Position of Installation For the best performance and the prevention of interfering visual coverage, it is recommended to install the camera unit at a proper position behind the driver’s sight of rear view mirror or on the top center of dashboard. - Page 10 card has been pre-installed; Pay attention to micro SIM card’s direction, make sure the chip side faces down, and the odd corner to the outside. You will hear or feel a “click” sound, the SIM card will be locked and won’t eject, which indicates the SIM card has been installed correctly. To eject the SIM card out for check purpose, simply push the SIM card toward into the slot, you will hear or feel a “tick”...
- Page 11 9) Use the Power Cable to connect OBD-II port with the Hub. The OBD-II port of vehicles is usually located underneath the dashboard, please check the manual of your vehicle or consult professionals to locate it in your vehicle. The OBD-II port generally provides constant power that supports video streaming access by smartphone application and web regardless if the car engine is on or off.
- Page 12 10) Install the Emergency Button with the Self-Grip Strap by tying the panic button around the steering wheel firmly, or anywhere else that is firm and convenient to reach. You can also use the spare double-side sticker to mount the button on the dashboard. 11) Use adhesive wire clips to keep your windshield and dashboard clean and organized.
-
Page 13: Operating Instructions
You can download the Application in the following ways: 1. Scan the following QR code and download via our download guide webpage. Or visit https://www.alleswolke.com/dashcamdownload.html 2. By searching “LTEdashcam” (without the quotation marks) in Google Play Store or “LTEdashcam Pro” (without the quotation marks) in Apple App store. -
Page 14: Account Registration
3. Or scan the following QR-code to Google Play Store or Apple App Store “LTEdashcam” in Google Play “LTEdashcam Pro” in Apple App Store ● Account Registration... -
Page 15: Add A Camera By Scanning The Qr-Code
Tap to open the App “LTEdashcam” in your Android phone or “LTEdashcam Pro” in your iPhone. 2. Tap “New User Sign Up” 3. Enter a valid cell phone number. This number will become your account number 4. You will receive an SMS text message with a security code, enter the code and your information to finish sign-up. - Page 16 ID for each vehicle in the fleet, you can enter it as User Defined Vehicle ID (UDID). The UDID and license plate number is optional and used for searching the vehicle in Alleswolke fleet management tool.
-
Page 17: Navigation/Overview/Camera
● Navigation/overview/camera page Introduction... - Page 18 1. Vehicle Select List and Status Display If you have multiple devices (hubs and cameras) installed in different vehicles, you can switch the hub here. Each hub represent a vehicle. It also shows each vehicle’s status. Sleeping Mode: The vehicle’s engine is off, the camera will be facing to the inner of the vehicle.
- Page 19 5. Taking panoramic photos Tap for taking panoramic photos. Camera will rotate 360 degree to take panoramic photos. It may take up to 20 seconds to finish photo shooting and syncing back to the phone. If your car is in parking mode, it may take longer to go through prior wake-up process. You will receive a push notification when the photo is ready.
-
Page 20: Live Video
6. Add another system/camera Tap the scan button to scan the QR-code on the top of the Camera. The code is device Serial Number (SN) with an 20-digits code with alphanumerical combination. Please see page 15 for detailed adding camera introduction. 7. -
Page 21: Video Streaming And Remote Access Via Lte
● Video streaming and remote access via LTE 1. Connect remotely using LTE User can remotely access the system and watch live streaming video, take photos and videos, use two-way audio features, and adjust settings via LTE . When the engine is off, or the user is far away from the vehicle, user can use smartphone to wake up and access camera. -
Page 22: Two-Way Audio Feature
● Two-way Audio Feature The system supports two-way audio. The system must be in remote access mode to use this feature with the smartphone’s microphone and speaker enabled and accessible by the application. 1）While in remote access with the device, slide to the “Talk” panel 2）The Listen mode is default mode 3）Press the Talk button to speak and release the button to listen 4）The driver can talk freely with no distractive interactions needed... -
Page 23: Wi-Fi Connection And Sd Card Video Access
● Wi-Fi connection and SD card Video Access 1. Connecting Hub’s Hotspot Wi-Fi network The system needs to be in Active mode. ◇ Android OS: Settings – WLAN – Wi-Fi list, select Wi-Fi SSID: MP-XXXXX, the default Password is 12345678 ◇... -
Page 24: Gps Location And Route Tracking Page
● GPS Location and Route Tracking Tap “Map” in the Main Menu. The system provides 2 map features regarding to GPS. 1. The Current Vehicle Information in real-time ◇ Including Real Time Vehicle Location and Map, Local time and Speed Application will display the latest GPS location and time if the system is offline and unable to receive the real-time GPS signal 2. -
Page 25: Event History Page
● Event History Event Definition: 1.Incident/impact Detection in Active mode Event including: GPS+Photo+Video 2.Emergency Button Alert Event including: GPS+Photo+Video 3.Live Recording including photos and streamings Event including: GPS+Photo (Live Photo) GPS+Video (Live Video) 4.Shake/Impact Detection in Sleep mode. Event including: GPS+Photo+Video 5.Engine Started notification Event including: GPS+Photo Incident/impact Detection in Active mode. - Page 26 II. Emergency Button Alert ◇ When the Emergency button is short-pressed (for approximately 1 second, the camera will play a shutter sound), a panoramic photo set (with 4 photos) and a 15-second video clip will be taken with a Push Notification and GPS location sent to the user’s smart phone application, and the photo and video uploaded to cloud at the meantime.
- Page 27 III. Live Recording ◇ Live Video: if the user requests Live video streaming, after the live streaming is finished, the system will notify all the users associated via Push Notification along with a combination of GPS location and the entire live streaming video clips. The GPS location and video clips are uploaded onto the Cloud Storage.
-
Page 28: Push Notifications
IV. Shock/Impact Detection in Sleep Mode ◇ When the vehicle’s engine is turned off and vehicle locked, upon the detection of any shake or impact, the system will notify user via Push Notification with a combination of GPS location, reference of panoramic pictures (4 photos) and a video clip (15 seconds). The impact sensitivity can be adjusted in hub settings. - Page 29 4. Shake detected on [your cars name]. When the vehicle’s engine is turned off and vehicle locked, upon the detection of any shake or impact, the system will notify user via Push Notification with a combination of GPS location, reference of panoramic pictures (4 photos) and a video clip (15 seconds). The impact sensitivity can be adjusted in hub settings.
-
Page 30: Settings Menu Introduction
● Settings Menu In the Settings menu, the available settings for users include Wi-Fi SSID and password, vehicle information, video resolution, audio switch, wake up time durations and other options. H u b Settings Menu introduction: Vehicle Name: the vehicle nickname display. To change the name, please tap Vehicle Information. - Page 31 APN/IMEI/SIM card PTN: network reference that used for debug. Not adjustable. Service Plan: Subscribe/Unsubscribe/change the service (cloud storage) plan here. Please visit our website (https://www.alleswolke.com/serviceplan.html) for more information. Restart device: Reboot the device. Reset device: Reset the device to factory settings, this will set Wi-Fi settings, impact sensitivity settings and other settings to default value, but will not delete user/vehicle information, subscription and system activation information.
-
Page 32: Shock/Impact Detection Sensitivity Adjustment
on or off. The default value is on. Time Stamp: The time will be displayed in all video recordings as water mark in UTC (Coordinated Universal Time)/GMT (Greenwich Mean Time). The UTC/GMT does not have Time Zone/Daylight Saving Time differences and is universal to the world. Running Time Video Clips Duration: The Video Clips Duration recorded into the SD card. -
Page 33: Patrol Mode
● Patrol mode If the vehicle is left unattended in an area with elevated security concerns, before leaving the vehicle, long press the emergency button for 5 seconds. The system will switch to patrol mode, with the camera on rotating in 360-degree and recording. To cancel the patrol mode, long press the button again for 5 seconds. -
Page 34: Firmware Update
◇ Format SD card in FAT/FAT32 format (backup SD card first) in your personal computer ◇ On our support page (https://www.alleswolke.com/dashcam_support.html) find and download the lasted firmware (a .zip file) ◇ Extract the .zip file into your computer and open the extracted folders ◇... -
Page 35: Fleet Features
Fleet Features: Join a fleet. ◇ If fleet manager adds your vehicle into the fleet, you need to give permissions to the fleet manager at the device end by smartphone application. ◇ You will receive a push notification “Invitation from [fleet manager name] adding you into [fleet name] fleet, awaiting acceptance”... -
Page 36: Q&A
Q & A Please visit https://www.alleswolke.com/dashcam_support.html for more information. -
Page 37: Rohs Disclaimer
RoHS Disclaimer hazardous substance or elements PBDE Device Housing Data/Power Cable Instruction O : The content of the hazardous substance or elements meet or less than the criterion of SJ/T11363-2006 standard requirement. X : The content of the hazardous substance or elements large than the criterion of SJ/T11363-2006 standard requirement*. - Page 38 FCC ID and Document Applications Approved. https://fccid.io/2AOYPUCM3310 FCC ID 2AOYPUCM3310...
