Alleswolke UCM3310S Quick Start Manual

Lte smart dashboard camera system
Hide thumbs Also See for UCM3310S:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
LTE Smart Dashboard Camera System
Quick Start Guide
Model: UCM3310S
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UCM3310S and is the answer not in the manual?

Questions and answers

Related Manuals for Alleswolke UCM3310S

Summary of Contents for Alleswolke UCM3310S

  • Page 1 LTE Smart Dashboard Camera System Quick Start Guide Model: UCM3310S...

  • Page 2: What's Included

    What’s Included: 1× Alleswolke Smart LTE Hub 1× Alleswolke Smart Dashboard Camera 1× Alleswolke Smart OBD-II Power/Data Cable 1× Camera USB Type-C Power Cable 1× Emergency Button with Strap 1× Camera Dashboard/Windshield Mount 1× Windshield Clean Wiper 1× Hook-and-Loop Fastener 1×...
  • Page 3 Get The App Download the free Alleswolke LTEdashcam Smartphone application to start. You may scan the QR-code and download the smartphone applications via our download guiding web page. Please follow the app’s guide to sign-up and log-in to the app.

  • Page 4: Sim Card

    SIM Card The SIM card has been already installed into your device. In any circumstance that you wish to check or install a new card yourself, push the SIM card to lock/unlock, make sure that the chip side faces down and the odd corner faces outward.
  • Page 5 Mount Your System Install camera onto the camera mount, peel the protection cover from the sticker on the mount, and press the mount firmly onto the desired place of windshield or the top center of dashboard. The default lens position is facing toward to the windshield for capturing road picture during driving.

  • Page 6: Connect Cables

    Connect Cables Connect the USB-C Cable between Hub and Camera. Connect the OBD-II Power/Data Cable on the Hub’s side (Micro- USB). Insert Micro SD card into the camera.* *Micro SD card is not included and needs to be purchased separately. Requires Class 10.
  • Page 7 Connect Cables (cont.) OBD-II Port Micro USB to OBD-II Cable USB Type-C Cable Camera Wire Connection Diagram Camera’s USB Type-C port...
  • Page 8 Insert Cable to OBD-II Port The OBD-II* port of vehicles is usually located underneath of the dashboard, please check the manual of your vehicle or consult auto specialists to locate it in your vehicle. *Smart OBD-II Power/Data Cable supports 9V-36V input and is compatible with all regular light vehicles and heavy duty commercial vehicles sold in the United States after January 1, 1996 with OBD-II port equipped.
  • Page 9 Mount And Turn On The Hub Use the Hook-and-Loop fastener to mount the hub onto the top of the dashboard. Make sure that the car ignition is turned on, and then press the power switch. Use adhesive wire clips to keep your windshield and dashboard clean and organized.

  • Page 10: System Status Led

    System Status LED After turning on the hub, you will hear a prompt sound from camera to indicate that the Power LED indicator Signal LED indicator system is starting. The signal LED indicator on the hub will blink for a few seconds and stay solid.

  • Page 11: Led Status Chart

    LED Status Chart...
  • Page 12 Install Emergency Button Install the Emergency Button Strap by with the Self-Grip tying the panic button around the steering wheel firmly, or anywhere else that is firm and convenient to reach. You can also use the spare double-side sticker to mount the button on the dashboard.
  • Page 13 Activate a System Log in the app Tap “add camera” Scan the QR-code on Camera...
  • Page 14 You Are Done! Congratulations! The system has been set up and ready to go. To view the full user manual, watch useful tutorial videos, find troubleshooting tips, or get support, please visit alleswolke.com/dashc am_support.html...

  • Page 15: Support Page

    Support Page For product FAQ, troubleshooting, user manual, feature introduction, application notes and overall support, please visit alleswolke.com/dashcam_support.html scan the QR-code. Support/Documents For watching the installation video and other introduction tutorial video clips, please visit alleswolke.com/dashcam_videos.html or scan the QR-code.
  • Page 16 ©2018 alleswolke Inc. “alleswolke” logo is trademark of alleswolke inc. App Store is a service mark of Apple inc., Registered in the U.S. and other countries, Google Play and the Google Play logo are trademark of Google inc. 3M is a trademark and company name of the 3M company or the Minnesota Mining and Manufacturing Company.
