- Page 1 Alleswolke LTE Dashcam UCM3300 series User Manual ● Verison 1.01 Alleswolke Inc. all right reserved...
- Page 2 Menu Disclaimer Acknowledgement what’s included Device Instruction Hardware Specs LED Indicators Installation Instructions ● Installation position ● Installation procedure Operating instructions ● Download and Install Smartphone Application ● Registration, log-in and pairing ● Connect Wi-Fi Hotspot ● Input SIM card’s phone number for system wake-up* ●...
- Page 3 Disclaimer Without the written authorization by Alleswolke Inc., any content that is provided in this user manual is not permitted to be published, spread, transcribed or stored in any searchable system with indices or journals, or translated into any other languages, to or via any form of media.
- Page 4 • If there is any other problems during the use of device, please read the Frequently Asked Questions at the later sections of this user manual, or contact Alleswolke Inc. for additional consultation.
-
Page 5: What's Included
Warning: it is strongly prohibited to plug the attached power and data cables into any other electronic devices not designated to use with, such as cell phones. Alleswolke does not assume any liability of damages cased by the contradictory use against this... -
Page 6: Device Instruction
Device Instruction ● Smart Dashboard Camera ● Smart LTE Hub... -
Page 7: Hardware Specs
Hardware specs Product Model UCM3310 Dimensions CAM：74×43×45mm HUB：92×92×15mm LTE Module Sierra Wireless WP7504 Main Chip Hisilicon Hi3516C-V200 Lens 6-layers glass and IR-Cut with IR LED Aperture F1.9 Viewing Angle Diagonal 162°/ Horizontal129° CMOS APTINA AR0230 CMOS 1/2.7 Focal Length 2.9mm... -
Page 8: Led Indicators
LED Indicators The LED indicators include the Power Indicator on the top of device and the series of Status Indicators on the bottom of device, with their status and colors representing the Status of Device. Device Type Color Status Device Status Green Device Starting Blue... -
Page 9: Installation Instructions
Installation Instructions ● Position of Installation For the best performance and the prevention of interfering visual coverage, it is recommended to install the camera unit at a proper position behind the driver’s sight of rear view mirror. At the meantime, to avoid the obstruction of camera’s lens visual coverage when it rotates toward the inside of vehicle, it is recommended to keep the camera lens exposed within the sight of passengers and drivers below the rear view mirror. - Page 10 For video link of installation, please scan: https://www.youtube.com/watch?v=y8FeVaIuL3o The OBD-II port generally provides constant power that supports video streaming access by smartphone application and web no matter car engine is on/off. Exceptions may exist, please consult automobile professionals for further questions. The device switches to sleep mode 3 minutes after the ignition turns off, which consumes very little power and generally does not drain the vehicle battery in a short while.
- Page 11 Operating instructions ● Download and Install Smartphone application At present the smartphone application is only available for Android OS. The iOS application will be published soon. You can download the Application in the following ways: 1. Scan the following QR code: 2.
- Page 12 Scan the QR code under the Hub or Camera. After Login your account, Tap the button “My device”, Tap “Add a device”, Tap the scan button to scan the QR code under the Hub or Camera. The code is an 20-digits code with alphanumerical combination.
- Page 13 ● Input SIM card’s phone number for system activation User needs to manually input the phone number linked to the SIM card. please use the 11-digit format: 14151234567 This step only applies to model UCM3310 that uses Sierra Wireless WP7504 module.
- Page 14 ● Video streaming, playback and download via local Wi-Fi Connect with local WiFi, When engine is started and other Wi-Fi devices are inside or close to the vehicle, user can using Wi-Fi local connection feature to connect the device for browsing and downloading the recorded video.
- Page 15 Device in Normal Mode, ready for remote access Device in Sleep Mode, ready for wake-up for remote access. For model UCM3310 with WP7504 module, the offline mode may also display as Sleep Mode. Offline mode, cannot wake up for remote access Offline mode does not apply for model UCM3310 with WP7504 module.
- Page 16 When connected remotely via LTE, ◇ The smartphone can stream the video real-time ◇ Smartphone can control camera 360 degree rotation ◇ Take pictures and recording15s video, the picture and video will recording to smartphone via Wi-Fi ◇ Two-Way audio ◇...
