BEFORE SETTING SURFACE CONTROLS
control locations of the gas surface burners
Your built-in range is equipped with gas surface burners
with different BTU ratings. The ability to heat food
quicker and in larger volumes increases as the burner
size increases.
The small SIMMER burner is best used for simmering
delicate sauces, etc. This burner is located at the right
rear burner position on the cooktop (see Figures 1).
The STANDARD burner can be used for most surface
cooking needs. The standard burners are located at the
left front and left rear positions on the cooktop (see
Figures 1).
The POWER burners are best used for bringing large
quantities of liquid rapidly up to temperature or when
preparing larger quantities of food. The POWER burner
is located at the right front position on the cooktop (see
Figures 1).
Regardless of size, always select cookware that is suitable
for the amount and type of food being prepared. Select a
burner and flame size appropriate to the pan. Never allow
flames to extend beyond the outer edge of the pan.
Figure 1
8
Assembly of the surface burner caps and
burner grates
It is very important to make sure that all of the Surface
Burner Caps and Surface Burner Grates are installed
correctly and at the correct locations.
1. Remove all packing material from cooktop area.
2. Discard all packing material (if applicable).
3. Unpack Burner Grates and position on the cooktop.
REMEMBER — do not alloW sPills, Food,
cleaning agents or anY otHer material
to enter tHe gas oriFice Holder oPening.
Always keep the Burner Caps and Burner Heads in place
whenever the surface burners are in use.
