sauder.com
Laptop Drawer
Cornerstone Collection | Model 404943
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Sit and surf.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 388874
03/09/16
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sauder 404943
Summary of Contents for Sauder 404943
- Page 1 Cornerstone Collection | Model 404943 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
- Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-18 Hammer Not actual size Français 19-21 Español 22-24 Skip the power trip. Safety 25-26 This time. Warranty Page 2 404943 www.sauder.com/services...
- Page 3 Use this part identifi cation to help identify similar parts. RIGHT UPRIGHT (1) LEFT UPRIGHT (1) KEYBOARD FRONT (1) RIGHT KEYBOARD SIDE (1) LEFT KEYBOARD SIDE (1) KEYBOARD BACK (1) KEYBOARD UPRIGHT (1) KEYBOARD SHELF (1) R2 KEYBOARD BOTTOM (1) www.sauder.com/services 404943 Page 3...
- Page 4 3S GOLD 5/16" FLAT HEAD SCREW - 8 BLACK 1-7/8" FLAT HEAD SCREW - 3 SILVER 5/8" FLAT HEAD SCREW - 8 BLACK 1-1/4" FLAT HEAD SCREW - 6 BLACK 9/16" PAN HEAD SCREW - 2 SILVER 9/16" LARGE HEAD SCREW - 2 Page 4 404943 www.sauder.com/services...
- Page 5 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push a SAUDER TWIST-LOCK® å FASTENER (7F) into the large holes in the RIGHT UPRIGHT (A) and LEFT UPRIGHT (B).
- Page 6 UPRIGHT (P). Then, insert a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow (4 used) Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. Page 6 404943 www.sauder.com/services...
- Page 7 Push the black lever in and pull the SLIDE from the RAIL. Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Short fi nished edge Open end Short fi nished edge www.sauder.com/services 404943 Page 7...
- Page 8 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 8 404943 www.sauder.com/services...
- Page 9 KEYBOARD SHELF (Q). Use four BLACK 1-1/4" FLAT HEAD SCREWS (7S). BLACK 1-1/4" FLAT HEAD SCREW (4 used in this step) These edges should be even. Long fi nished edge Short unfi nished end Long fi nished edge Short unfi nished end www.sauder.com/services 404943 Page 9...
- Page 10 Step 6 Insert the CORD TRAYS (94M) onto the å KEYBOARD SIDES (D and E). Post Post Page 10 404943 www.sauder.com/services...
- Page 11 Fasten the KEYBOARD BOTTOM (R2) to the KEYBOARD å UPRIGHT (P). Tighten two HIDDEN CAMS. Maximum Arrow 210 degrees NOTE: Be sure the POSTS in the CORD TRAYS (94M) å insert into the holes in the KEYBOARD BOTTOM. Minimum 190 degrees Rounded edge www.sauder.com/services 404943 Page 11...
- Page 12 å and E). Use two BLACK 1-1/4" FLAT HEAD SCREWS (7S). BLACK 1-7/8" FLAT HEAD SCREW (3 used in this step) This hole must be here. BLACK 1-1/4" FLAT HEAD SCREW (2 used in this step) Page 12 404943 www.sauder.com/services...
- Page 13 Fasten the HINGES (12H) to the KEYBOARD SHELF (Q). å Use two SILVER 9/16" LARGE HEAD SCREWS (54S). SILVER 9/16" LARGE HEAD SCREW (2 used in this step) SILVER 5/8" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 404943 Page 13...
- Page 14 Step 10 Fasten the EXTENSION SLIDES (T) to the å KEYBOARD SIDES (D and E). Use four GOLD 5/16" FLAT HEAD SCREWS (3S). Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Open end Page 14 404943 www.sauder.com/services...
- Page 15 Step 11 Insert the GROMMET (10P) into the large hole in the å KEYBOARD BACK (M). Then, insert a GROMMET CAP (1P) onto the GROMMET. www.sauder.com/services 404943 Page 15...
- Page 16 KEYBOARD BOTTOM (R2). NOTE: Do not completely tighten the SCREWS. å Then, slide the OUTLET (1D) onto the heads of the å SCREWS in the KEYBOARD BOTTOM (R2). SILVER 5/8" FLAT HEAD SCREW (4 used in this step) Page 16 404943 www.sauder.com/services...
- Page 17 NOTE: You have the option to install your unit to the 404972 å ® How to use the SAUDER TWIST-LOCK FASTENER Executive Desk, the 404380 65" Return, and the 404379 1. Insert the dowel end of the FASTENER into the hole of the 48"...
- Page 18 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story? 25 lbs. Page 18 404943 www.sauder.com/services...
- Page 19 Modèle 404943 Tiroir d’ o rdinateur portatif Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble Chaque étape en français correspond à...
- Page 20 TABLETTE DE CLAVIER (Q). Utiliser quatre VIS NOIRES TÊTE PLATE 32 mm (7S). Pour commencer l’ a ssemblage, enfoncer une FIXATION TWIST-LOCK® SAUDER (7F) dans les gros trous du MONTANT DROIT (A) et MONTANT GAUCHE (B). ÉTAPE 6 Insérer les PORTE-CORDONS (94M) sur les CÔTÉS DE LA ÉTAPE 2...
- Page 21 REMARQUE : Prière de lire attentivement les importantes informations concernant la sécurité qui fi gurent sur les pages arrière du manuel d’instructions. Ceci complète l’ a ssemblage. Pour nettoyer, utiliser l’encaustique pour meubles préférée ou un chiff on humide. Essuyer. www.sauder.com/services 404943 Page 21...
- Page 22 Modelo 404943 Cajón de computador portátil Use estas instrucciones de ensamblaje en español junto con las ESTAMOS AQUI PARA AYUDAR! fi guras paso-a-paso provistas en el folleto inglés. Cada paso Tratamos de asegurar que su mueble llega en condición excelente.
- Page 23 DE TECLADO (Q). Utilice cuatro TORNILLOS NEGROS DE CABEZA PERDIDA de 32 mm (7S). Para comenzar el ensamblaje, empuje un SUJETADOR TWIST-LOCK® SAUDER (7F) dentro de los agujeros grandes del PARAL DERECHO (A) y del PARAL IZQUIERDO (B). PASO 6...
- Page 24 NOTA: Por favor lea las páginas fi nales del folleto de instrucciones para información importante sobre la seguridad. Esto completa el ensamblaje. Para la limpieza, utilice el pulimento para muebles preferido. Seque con un paño. Page 24 404943 www.sauder.com/services...
- Page 25 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 404943 Page 25...
- Page 26 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 26 404943 www.sauder.com/services...
- Page 27 GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
- Page 28 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
