INTRODUCTION ............................................ 2
RECEIVING AND STORAGE ........................ 2
DESCRIPTION OF OPERATION ................... 2
INSTALLATION ............................................. 3
VALVE CONSTRUCTION .............................. 3
MAINTENANCE ............................................. 4
TROUBLESHOOTING ................................... 5
DISASSEMBLY ............................................. 5
REASSEMBLY .............................................. 5
PARTS AND SERVICE .................................. 6
WARRANTY .................................................. 6
®
VAL-MATIC
VALVE AND MANUFACTURING CORP.
9 05 R i ver s id e D r .
Phone (630) 941-7600 ●
www.valmatic.com
1
Manual No.
WSSAV-OM1-1
●
Elmhurs t, IL 60126
Fax (630) 941-8042
Advertisement
Table of Contents
Related Manuals for Val-Matic 801SSBW
Summary of Contents for Val-Matic 801SSBW
-
Page 1: Table Of Contents
DISASSEMBLY ..........5 REASSEMBLY ..........5 PARTS AND SERVICE ........6 WARRANTY ..........6 ® VAL-MATIC VALVE AND MANUFACTURING CORP. 9 05 R i ver s id e D r . ● Elmhurs t, IL 60126 Phone (630) 941-7600 ●... -
Page 2: Wastewater Surge Suppression Combination Air Valve
WASTEWATER SURGE SUPPRESSION AIR VALVE OPERATION, MAINTENANCE AND INSTALLATION INTRODUCTION This manual will provide you with the information to properly install and maintain the valve to ensure a long service life. Wastewater Surge Suppression Air Valve has been designed with stainless steel trim to give years of trouble-free operation but regular maintenance is recommended for valves subject to fluids containing suspended... -
Page 3: Installation
INSTALLATION The installation of the valve is important for its proper operation. Valves should be installed at the system high points in the vertical position with the inlet down. For pipeline service, a vault with freeze protection, adequate screened venting, drainage should be provided. -
Page 4: Maintenance
Backwash Accessory Kits ITEM DESCRIPTION MATERIAL Type Inlet Backwash Kit Valve Models Body Cast Iron 1” SPK-301ABW 801SSBW Seat Bronze Comb. Disc Bronze 2” SPK-301ABW 802SSBW Stem Brass 3” SPK-303ABW 803SSBW Seat Ret. Screw Brass Valve *RECOMMENDED REPAIR PART KIT 4”... -
Page 5: Troubleshooting
WARNING Wear safety glasses to look into the valve outlet Valve not Venting Air: Check that operating after installation. Released fluid can cause pressure does not exceed Working Pressure on injury. nameplate. Backwash or clean valve. Inspection: Periodic inspection to verify operation can be performed. -
Page 6: Parts And Service
(17) and valve nameplate and contact: guide shaft retainer (35). Val-Matic Valve and Mfg. Corp. 4. Insert pivot pins (12) through float arm (10) and 905 Riverside Drive fasten with retainer rings (13). Thread in orifice...
